GE GTS18ICSR Manual
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information (in inches)
Specification Created 6/07
310382
GTS18ICS
GE® 18.0 Cu. Ft. Top-Freezer Refrigerator with Icemaker
Overall
Dimensions
Height to top of hinge (in.) A 66-5/8
Height to top of case (in.) B 66-1/8*
Case depth without door (in.) C 27-1/2
Case depth less door handle (in.) D 30-1/4
Case depth with door handle (in.) E 32-1/8
Depth with fresh food door open 90° (in.) F 58-1/8
Width (in.) G 29-1/2
Width with door open 90° inc. door handle (in.) H 32
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
*Height to mid-freezer (in.): 54-1/2
Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors:
As you face the front of the refrigerator, the handle is on your left
and the hinges are on your right.
All Top-Freezer No-Frost Left-Hand Refrigerator Doors:
As you face the front of the refrigerator, the handle is on your right
and the hinges are on your left.
Listed by
Underwriters
Laboratories
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
Front View Top View
A
G
E
C
F
'94 TMNF Refer
B
D
H
Features and Benefits
• Factory-Installed Icemaker - Makes ice automatically ensuring a ready supply
• Adjustable Glass Shelves - Lets consumers maximize usable storage space
• Upfront Temperature Controls - Are positioned up front, close at hand,
for maximum convenience and ease of use
• Vegetable/Fruit Crispers - For easy storage of your fruits and vegetables
• Gallon Door Storage - Makes room for gallon-size containers
• Snack Pan - Helps keep everyday foods like muffins and carrot sticks fresh
• Freezer Step Shelf - Creates an extra space for stacking frozen foods and
can be easily removed for tall items
• Model GTS18ICSRWW - White on white
• Model GTS18ICSRCC - Bisque on bisque
• Model GTS18ICSRBB - Black on black
GTS22IBS/GTS22ICS
Specification Created 6/07
310382
GTS18ICS
GE® 18.0 Cu. Ft. Top-Freezer Refrigerator with Icemaker
*
