GE GTH18JBR Manual
Dimensions and Installation Information
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Front View Top View
A
G
E
C
F
'94 TMNF Refer
B
D
H
Dimension and installation information are shown in inches.
GTS17JBW
GE® 16.6 Cu. Ft. Top-Freezer Refrigerator
Overall
Dimensions
Height to top of hinge (in.) A 64-3/4
Height to top of case (in.) B 64-1/4*
Case depth without door (in.) C†25-7/8
Case depth less door handle (in.) D†29-1/8
Case depth with door handle (in.) E†31
Depth with fresh food door open 90° (in.) F†54-7/8
Width (in.) G 28
Width with door open 90° incl. door handle (in.) H 30-1/2
Air
Clearances
Each side (in.) 3/4
Top (in.) 1
Back (in.) 1
*Height to mid-freezer (in.): 54-3/8
Specification Created 6/07
310479
Listed by
Underwriters
Laboratories
Features and Benefits
• Spillproof Glass Shelves - Help contain spills for ease of cleaning
• Upfront Temperature Controls - Are positioned up front, close at hand,
for maximum convenience and ease of use
• Adjustable Humidity Vegetable/Fruit Crispers - Provide easy storage
environment for fruits and vegetables
• Gallon Door Storage - Makes room for gallon-size containers
• NeverClean™ Condenser - Condenser coils are encased, so they don't
require cleaning in normal operating environments
• Deluxe Quiet Design - Significantly reduces operating noise
• Model GTS17JBWWW - White on white
• Model GTS17JBWBB - Black on black
GTS17JBW
GE® 16.6 Cu. Ft. Top-Freezer Refrigerator
Specification Created 6/07
310479
GTS18DBP / GTH18DBR / GTH18DCR / GTS18DC
P
GTS18JBP / GTH18JBR / GTS18JCP
