Introduction

Thank you for purchasing the fi-5650C fi-5650C duplex color scanner product.

The fi-5650C is a high-performance duplex color scanner product, equipped with ADF (Automatic Document Feeder) for automatically

scanning documents.

Features:

●Basic High Resolution: 600 dpi.

●High Speed Scanning:

Simplex (One-sided page): 55 pages per minute (Standard A4, 200/300 dpi)

Duplex (Two-sided page): 110 pages per minute (Standard A4, 200/300 dpi)

●Scanner automatically reads images just with the touch of the [Scan] and [Send] to buttons.

●Ultrasonic sensor can detect double feeding of pages.

●Automatically switches the background color (black / white), corrects the images of skewed pages, and detects automatically the page

sizes.
