Fujitsu AUXG24KVLA User manual

AIR CONDITIONER

Cassette type

SERVICE MANUAL

INDOOR

AUXG24KVLA

OUTDOOR

AOHG24KATA

SR_AU018EG_01

2019.10.24

Notices:

• Product specifications and design are subject to change without notice for future improvement.

• For further details, please check with our authorized dealer.

Trademarks

FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.

Google Play™ is trademark of Google Inc.

App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.

CONTENTS

1. GENERAL INFORMATION

2. TECHNICAL DATA AND PARTS LIST

1. GENERAL INFORMATION

2019.10.24

SR_CH01_AU017EG_01

CONTENTS

1. GENERAL INFORMATION

1. Specifications..............................................................................................01-1

1-1. Indoor unit ......................................................................................................................01-1

1-2. Outdoor unit....................................................................................................................01-4

2. Dimensions..................................................................................................01-5

2-1. Indoor unit ......................................................................................................................01-5

2-2. Outdoor unit....................................................................................................................01-7

1. Specifications

1-1. Indoor unit

Type

Cassette

Inverter heat pump

Model name AUXG24KVLA

Power supply 230 V ~ 50 Hz

Power supply intake Outdoor unit

Available voltage range 198—264 V

Capacity

Cooling

Rated kW 6.80

Btu/h 23,200

Min.—Max. kW 0.90—7.40

Btu/h 3,100—25,200

Heating

Rated kW 7.50

Btu/h 25,600

Min.—Max. kW 0.90—8.60

Btu/h 3,100—29,300

Input power

Cooling Rated

2.26

Max. 2.79

Heating Rated 2.08

Max. 2.70

Current Cooling Rated A 10.0

Heating 9.1

Power factor Cooling %98.4

Heating 98.9

EER Cooling kW/kW 3.01

COP Heating 3.61

Moisture removal L/h (pints/h) 2.7 (4.8)

Maximum operating current *1 Cooling A12.6

Heating 12.6

Fan

Airflow rate

Cooling

HIGH

m3/h

930

MED 830

LOW 600

QUIET 450

Heating

HIGH 930

MED 860

LOW 700

QUIET 530

Type × Q'ty Turbo × 1

Motor output W 54

Sound pressure level *2

Cooling

HIGH

dB (A)

MED 44

LOW 36

QUIET 30

Heating

HIGH 49

MED 45

LOW 40

QUIET 33

Heat exchanger type

Dimensions

(H × W × D)

Main1: 210 × 1,360 × 13.3

Main2: 210 × 1,295 × 13.3

Main3: 210 × 1,235 × 13.3

Fin pitch

Main1: 1.45

Main2: 1.45

Main3: 1.45

Rows × Stages

Main1: 1 × 10

Main2: 1 × 10

Main3: 1 × 10

Pipe type Copper tube

Fin type Aluminum

Dimensions

(H × W × D)

Net mm 245 × 570 × 570

Gross 265 × 730 × 625

Weight Net kg 16

Gross 20

Connection pipe Size Liquid mm (in) Ø 6.35 (Ø 1/4)

Gas Ø 12.70 (Ø 1/2)

Method Flare

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Cassette grille

(Grid type: Option)

Material Polystyrene

Color White

Approximate color of Munsell 9PB 9.1/0.2

Dimensions

(H × W × D)

Net mm 49 × 620 × 620

Gross 120 × 765 × 755

Weight Net kg 2.3

Gross 4.5

Remote control (Option) Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair™)

Drain hose Material PVC

Size mm VP25 [Ø 25(I.D.),Ø 32(O.D.)]

1-1. Indoor unit - (01-1) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

Type

Cassette

Inverter heat pump

Model name AUXG24KVLA

NOTES:

• Specifications are based on the following conditions:

– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.

– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.

– Pipe length: 5.0 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)

• Protective function might work when using it outside the operation range.

• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.

• *2: Sound pressure level:

– Measured values in manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

• *3: Available on Google Play™ store or on App Store®. Optional WLAN adapter is also required. For details, refer to the setting manual.

1-1. Indoor unit - (01-2) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

Specifications for ErP Lot10

Model name AUXG24KVLA

Energy efficiency

class

Cooling A+

Heating (Average) A

Pdesign Cooling kW 6.8 (35°C)

Heating (Average) 5.4 (-10°C)

SEER Cooling kWh/kWh 5.90

SCOP Heating (Average) 3.80

Annual energy con-

sumption

QCE kWh/a 403

QHE (Average) 1,988

Sound power level Cooling HIGH dB (A) 59

Heating 61

1-1. Indoor unit - (01-3) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

1-2. Outdoor unit

Type Inverter heat pump

Model name AOHG24KATA

Power supply 230 V ~ 50 Hz

Power supply intake Outdoor unit

Available voltage range 198—264 V

Starting current A 10.0

Fan

Airflow rate Cooling m3/h 2,885

Heating 2,350

Type × Q'ty Propeller × 1

Motor output W 49

Sound pressure level *1 Cooling dB (A) 54

Heating 55

Sound power level Cooling dB (A) 66

Heating 67

Heat exchanger type

Dimensions

(H × W × D) mm

Main1: 588 × 881 × 18.19

Main2: 588 × 851 × 18.19

Fin pitch Main1: 1.3

Main2: 1.3

Rows × Stages Main1: 1 × 28

Main2: 1 × 28

Pipe type Copper

Fin Type (Material) Aluminum

Surface treatment PC fin

Compressor Type × Q'ty DC Twin rotary × 1

Motor output W 1,060

Refrigerant Type (Global warming potential) R32 (675)

Factory charge g 1,250

Refrigerant oil Type RmM68AF

Amount cm3400

Enclosure

Material Steel sheet

Color Beige

Approximate color of Munsell 10YR 7.5/1.0

Dimensions

(H × W × D)

Net mm 632 × 799 × 290

Gross 692 × 940 × 375

Weight Net kg 38

Gross 42

Connection pipe

Size Liquid mm (in) Ø 6.35 (Ø 1/4)

Gas Ø 12.70 (Ø 1/2)

Method Flare

Pre-charge length

Max. length 25

Max. height difference 20

Operation range Cooling °C -10 to 46

Heating -15 to 24

Drain hose Material PP

Size mm Ø13.0 (I. D.), Ø16.0 to Ø16.8 (O. D.)

NOTES:

• Specifications are based on the following conditions:

– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.

– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.

– Pipe length: 5.0 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)

• Protective function might work when using it outside the operation range.

• *1: Sound pressure level

– Measured values in manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-2. Outdoor unit - (01-4) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION
