Fostex P800K User manual

P800K P1000K

Thank you for purchasing P800K / P1000K. A light-weight cone paper and a high-loss rubber edge realize a bright and

clear mid-to-high range and reasonably damped low range reproduction. You can enjoy an excellent stereo image and

sound field achieved by a small-diameter speaker unit.

Main features

Banana pulp blended light-weight cone paper / High-loss

foamed rubber edge

Blending a banana pulp with two wooden pulps holding

different physicality realizes a sufficient stiffness and

high-loss. A high-loss foamed edge with an up-roll shape is

employed.

“Mechanical” 2-way center cap

The same material as the cone paper is employed on the

center cap for improving the sound unification. A mechanical

2-way structure which directly connects the center cap with

the voice coil bobbin extends a high range sound reproduction

further.

Faston 205 terminal

A Faston 205 type is used for the speaker input terminal.

Dimensions

79.5 + Terminal

(RED MARKING)

ø90

4 - ø5 hole

ø55

(47.4)

16.5

1.7

ø70

+ Terminal

(RED MARKING)

107

4 - ø5 hole

ø116

ø65

ø93.2

25.818

1.8

(48.2)

• P800K

• P1000K

Frequency Response

• P800K • P1000K

100

110

100 1k 10k

20 50(Hz) 200 500 2k 5k 20k 50k

(dB)

Impedance

100

110

100 1k 10k

20 50(Hz) 200 500 2k 5k 20k 50k

(dB)

Impedance

PRINTED IN CHINA SEPTEMBER 2012 562657

Specifications & Thiele/Small Parameters

Model

Size

Overall Diameter

Baffle Hole Diameter

Depth

Voice Coil Diameter

Cast / Stamped

Impedance

Reproduction Freq. Response

Sound Pressure Level

Rated Input

Music Power

Magnet Weight

Net Weight

Equivalent Diaghram Radius

Effective Cone Diameter

Surface Area of Cone

Nominal Impedance

Resonance Frequency

DC Resistance

Coil Inductance

Mechanical Q

Electromagnetic Q

Total Q

Equivalent Mass

BL Product (Factor Force)

Compliance Equivalent Volume

Voice Coil Overhang

Reference Efficiency n0

Mechanical Compliance of Suspension

Efficiency Bandwidth Product

Qms

Qes

Qts

Mms

Vas

Xmax

Eff/n0

Cms

EBP

79.5

47.4

Stamped

fs-18

84.5

261

0.0028

115

7.2

0.037

3.79

1.334

0.99

2.2

2.98

1.043

0.5

0.117

0.873

86.2069

P800K

ohm

kHz

dB/W (m)

ohm

Tesla/m

m/N

3.2

2.9

2.0

0.8

0.163

0.575

100

107

48.2

Stamped

fs-16

120

405

0.005

6.8

0.04

0.6

0.53

3.1

4.29

4.84

0.35

0.414

1.241

136.667

P1000K

ohm

kHz

dB/W (m)

ohm

Tesla/m

m/N

4.0

4.3

3.8

2.0

0.8

0.265

0.893
