Foscam X5 User manual

User

User Manual

Manual

Wireless IP Camera

Model: X5

V3.0

Table of Contents

1 Overview............................................................................................................................................................................. 3

1.1 Key Features...........................................................................................................................................................3

1.2 Read before Use.................................................................................................................................................... 3

1.3 Packing Contents................................................................................................................................................... 3

1.4 Physical Description.............................................................................................................................................. 4

1.5 SD Card Management...........................................................................................................................................4

1.6 Add Device: Connection via the Foscam App................................................................................................... 4

1.7 Installation............................................................................................................................................................... 5

2 Default Parameters........................................................................................................................................................... 5

3 Specification....................................................................................................................................................................... 6

1 Overview

1.1 Key Features

5.0Megapixels Pan/Tilt Wireless IP Camera

H.264+/H.264 video Compression

Support 2.4GHz WiFi

Supports Human detection, Motion Detection and Sound Detection

Compatible with free Foscam Video Management Software

Compatible with free Foscam iOS and Android APP

Supports Full Duplex two-way Audio

Supports voice prompt

Supports 256GB Micro SD Card storage(External)

IR Range up to 8m(26ft)

P2P Feature for Easy Remote Access

Supports image snapshot

Supports dual-stream

Supports remote viewing & record from anywhere anytime

Multi-level users management with password protection

Supports multiple network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP

Supports Alexa

Supports Google Assistant

1.2 Read before Use

Please first verify that all contents received are complete according to the Package Contents listed below.

Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup

Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly

as intended.

1.3 Packing Contents

● IP Camera × 1

● Mounting Platet × 1

● AC Adapter × 1

● USB Power Cable× 1

● Quick Setup Guide × 1

● Ethernet Cable× 1

● Expansion Screws × 1

1.4 Physical Description

Lens: Fixed focus lens

Microphone: Built-in Microphone.

Speaker: Built-in speaker

LAN: 10/100 Mbps RJ-45 port for wired connection

Power : : DC 5V/1A or DC 5V/1.5A Power supply.

Reset: Press and hold on the reset button for 3 seconds. Releasing the reset button, the password will back to

the factory default administrator password.

Micro SD Card slot: Supports up to 256GB SD card for storing the video.

1.5 SD Card Management

This camera supports Micro SD Card.

When you plug in the SD card during the camera work process, please reboot the camera again, or else the

SD card might not work well.

On Foscam app go to the SettingsDevice StatusDevice Status page, you can see the SD card status.

1.6 Add Device: Connection via the Foscam App

Scan the QR code below to download and install the Foscam APP.

Please refer to the Quick Setup Guide.

1.7 Installation

Please refer to the Quick Setup Guide.

1.Place the camera directly on a desk.

2.Install the mounting plate on a wall or ceiling with the supplied fixing screws.

Note: Align points a and b to insert the camera base to the mounting plate. Rotate so that points a and b are

aligned, which attaches the camera securely to the base.

2 Default Parameters

Default network parameters

IP address: obtain dynamically

Subnet mask: obtain dynamically

Gateway: obtain dynamically

3 Specification

ITEMS

Image Sensor

Sensor Type

High Definition Color CMOS Sensor

Display Resolution

5.0Megapixels(2560*1920)

Min. Illumination

0 Lux (With IR Illuminator)

Lens

Lens Type

f.3.6mm; F2.4

Angle of view

Diagonal: 89°, Horizontal: 71°, Vertical: 52°

Video

Image Compression

H.264+/H.264

Image Frame Rate

Max15fps (5MP), downward adjustable

Resolution

5MP(2560*1920) 15 fps,1080P(1600*1200) 25fps,

720P(1024*768)25fps

Stream

Dual stream

Image Adjustment

The hue, brightness, contrast, saturation, sharpness are adjustable

Pan/Tilt Angle

Horizontal:350° & Vertical:70°

Flip Image

Flip and mirror

Infrared Mode

4pcs SMD IR-LEDs

Night Mode

Automatic modes

Night Visibility

Audio

Input/Output

Two-way audio,build-in microphone and speaker

Audio Compression

PCM/ AAC

Network

Ethernet

Yes

Wireless Standard

IEEE802.11b/g/n

Data Rate

IEEE802.11b: 11Mbps(Max.);

IEEE802.11g: 54Mbps(Max.);

IEEE802.11n: 150Mbps(Max.).

Wireless Security

WPA, WPA2

Remote Access

P2P

Wifi Configuration Mode

Support scan QR code

Network Protocol

IP, TCP, UDP, DHCP,RTSP

System

Requirements

Operating System

Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android

(Foscam app), iOS (Foscam app)

Other Features

Motion Detection

Alarm via E-Mail, FTP and Foscam app when an event is detected

Sound Detection

Alarm via E-Mail, FTP and Foscam app when an event is detected

Human Detection

Alarm via E-Mail, FTP and Foscam app when an event is detected

Privacy Block

Yes

WDR

Improve image clarity in complex scenario

Zoom

6X digital zoom function

Storage

Support max. 256GB Micro SD card, local and FTP storage,Foscam

cloud storage

User Accounts

Three levels user role

Power

Power Supply

Micro USB 5V/1.5A or 5V/1A

Power Consumption

7.5Watts (Max.)

Physical

Dimension(LxWxH)

83(L)x76 (W)x114 (H) mm

Net Weight

206g

Environment

Operating Temperature

-10°C~ 50°C (14°F ~ 122°F)

Operating Humidity

20% ~ 85% non-condensing

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Storage Humidity

0% ~ 90% non-condensing

Certification

CE, FCC, RoHS,WEEE

For other parts, please refer to the “FOSCAM Camera User Manual”
