Flexispot F3B User manual
Model：F3B
Installation Guide
08 01
Keyboard Tray Weight Capacity ≤4.4 Ibs (2 KG)
Height Adjustable Range 6.7" - 17" (170 - 430mm)
≤33 Ibs (15 KG)
Desktop Weight Capacity
Specifications
Please do not place your hand near the scissor lift.
The scissor lift angle will change when lifting or lowering
the desktop and it may hurt your hands.
Warning!
Please make sure to install all equipment
on a level surface.
Cable management tie is included to help organize
your cables. When organizing cables, make sure you
have sufficient cord length to reach the top height
when the desktop unit is fully extended upwards.
Failure to do so may result in damage to corded device.
If the device placed on your desktop weighs less
than 6.6 lbs, press the handle grips and force down
the desktop to prevent the workstation from bouncing
up. Failure to do so may result in damage to the
device of physical injury.
Warning!
Warning!
Warning!
Warning!
Website: www.flexispot.com
Tel: 1-855-421-2808
Hand Pinching
Do not place your hands near the "scissor" part of
the desk. The lifting mechanism will change when
raising or lowering the desktop. Please be aware
of all moving parts to avoid hurting your hands.
Warnin g!
Warning!
No Climbing
No Climbing
Parts Included: Step 1: Place the desktop body on an even surface
02 03
The diagram shown is for reference only and may not accurately depict all parts. Please contact
customer service if there is any part missing.
Body Part
Part# Part Name Qty Part# Part Name Qty Part# Part Name Qty
Keyboard Tray
Qty
Part Name
Part#
Connecting
Plate
Part# Part Name Qty Part# Part Name Part# Part Name Qty
5X5 Wrench
Stickers
Cable Sleeve
Attach the connecting plate to the keyboard tray and tighten with 6pcs screws.
30" (761mm)
20.9" (530mm)
Max
33 Ibs
5.7" (144mm)
24.3" (616mm)
Max
4.4Ibs
26.5" (673mm)
9.2" (233mm)
0-55°
6.7" - 17" (170 - 430mm)
26.8" (680mm)
16.5" (420mm)
18" (460mm)
Screws
Step 2: Unlock the handle to release the main body part
04 05
Step 3: Connect the Keyboard Tray
Unlock the handle to release the main body part.
Caution: Be careful when unlocking the handle
because the surface will bounce up.
1
2
Unlock
Lock
Connect the keyboard tray (2) to the desktop plate.
Note: The keyboard tray can be added or removed
depending on your preference. It is not required for
proper functioning of the unit.
Unlock the handle grips on both sides then attach the keyboard tray as shown in the
diagram. Lock the handles down to finish assembly.
Step 4: Place Your Devices Onto The Workstation
06 07
Caution: Please make sure the desk surface is bigger than the
base plate of the workstation. Failure to do so may result in
damage to the device or physical injury.
Press the handle grips on both sides simultaneously, and adjust the workstation to the
proper height. The height adjustable range is 6.7" - 17" (170 - 430mm).
Adjust the keyboard tray angle to suit your personal requirements.
The adjustable range of the keyboard tray is 0° - 8 °.
A
B
Use stickers to attach monitor to your desktop unit.
Stickers can be reused after cleaning with water
Stickers A
Stickers B
According to the need to clip stickers B
6.7" - 17" (170 - 430mm)
Step 5: Use stickers to attach monitor to your desktop unit
Manage the cables using cable sleeve.
