Fisher-Price W9913 User manual

www.fisher-price.com

Please keep this instruction sheet for future reference,

as it contains important information.

Adult assembly is required.

Tool required for assembly: Phillips screwdriver (not included).

W9913

Important Information

WARNING

Prevent Entanglement Injury

Crib Mobile Use

•Keepoutofbaby'sreach.

•Removemobilefromcriborplaypenwhenbabybeginstopush

up on hands and knees.

•Thisproductmaynotattachtoallcribdesigns.Donotadd

additionalstringsorstrapstoattachtoacriborplaypen.

Stroller Toy Use

•Donotattachlinkdirectlytocriborplaypen.

CAUTION

Thispackagecontainssmallpartsinanunassembledstate.

Adult assembly is required.

•Useasamobilefrombirthuntil5months.

•Amobileisintendedforvisualstimulationandnottobegraspedbyachild.

Assembled PartsImportant Information

Arm

(Upper)

Mobile

Mobile Link

Giraffe

Screw is shown actual size.

Tighten all screws with a Phillips screwdriver.

Do not over-tighten the screws.

M3,5 x 15 mm Screw – 5

Mobile Link Cover

Arm

(Lower)

Base

Assembly

•Fitthelowerarmintothesocketinthebackofthebase.

Hint: You may need to pull the attachment strap on the base down to fit the arm

in the base.

Arm

(Lower)

Base Socket

•Insertascrewintothelowerarmandtighten.

Assembly

•Fittheupperarmtothelowerarm.

Arm

(Upper)

Arm

(Lower)

Assembly

•Insertfourscrewsintothearmassemblyandtighten.

•First,alignthetabsontheendofthearmwiththeslotsinthebackofthegiraffe.

•Then,turnthegiraffeto"snap" in place on the end of the arm.

•Fittheupperarmtothelowerarm.

FisherPrice,Inc.,asubsidiaryofMattel,Inc.,EastAurora,NY14052U.S.A.

PRINTED IN CHINA W9913a-0920

Arm Tabs

Giraffe Slots

•Fittheflatendofthemobilelinkintothegrooveinthemobile.

•Fitthemobilelinkcoverontothetopofthemobile.

•Tightenthescrews.

Hint: The screws are assembled to the mobile link cover.

Mobile Link

Mobile Groove

Mobile Link Cover

Mobile Link

Assembly

•Fittheendsofthemobilelinkontothemobilearm.

•Pushto“snap” the link in place.

Mobile Arm

Mobile Link

Assembly

Mobile Use Crib Attachment

IMPORTANT! Always attach all provided fasteners (strings, straps, clamps, etc.)

tightly to a crib or playpen according to the instructions. Do not add additional

strings or straps to attach to a crib. Check frequently.

•Positionthetoyinsidethecrib.

•Wrapthetoy’sattachmentstraparoundthecribtophorizontalrail.

•Slidetheendoftheattachmentstrapthroughtheslotonthebackofthetoy.

•Pulltheendoftheattachmentstrapupandfastentotheslotonthepegonthe

back of the toy.

Note:Thistoyshouldbesnugagainstthecribrailandspindles.Usethestrap

slotthatprovidesthetightestfit.

•Ifyouhaveexcessstrap,slidethefreeendoftheattachmentstrapunderthe

slot at the top of the attachment strap.

Crib Rail

Attachment Strap

Slot

Peg

Mobile Use Crib Attachment

•Makesurethedistancebetweenthebottomoftheproductandthecrib

mattress is at least 7 inches (18 cm).

•Ifthedistanceislessthan7inches(18cm):readjusttheattachmentstrapsto

lift the product; or lower the crib mattress.

Mattress

Crib Spindle

Bottom of Base At Least 7 Inches (18 cm)

•Tiethetoy’sstringstoacribspindle.

Note:Itisbettertotiethestringsinaknotthanabow,sinceabowmaybe

easily untied.
