Fisher-Price K3799 User manual

K3799

• Please keep this instruction sheet for future reference,

as it contains important information.

• Requires three "D" (LR20) alkaline batteries for the

mobile and two "AA" (LR6) alkaline batteries for the

remote (batteries not included).

• Adult assembly required.

• Tool required for assembly: Phillips screwdriver

(not included).

WARNING

Prevent Entanglement Injury

• Keep mobile out of baby's reach

• Remove mobile portion of product from crib or playpen when baby

begins to push up on hands and knees.

• This product may not attach to all crib designs. Do not add additional

strings or straps to attach to crib or playpen.

• Use ONLY attached to a crib or playpen.

IMPORTANT! Always attach with all provided fasteners tightly to a crib or

playpen according to the instructions. Do not add additional strings or straps

to attach to a crib. Check frequently. The mobile portion of this product may be

used from birth until 5 months. The base portion of this product may be used

from birth until 24 months. A crib mobile is intended for visual stimulation and

is not to be grasped by a child.

Consumer Information

Care

• Wipe this toy with a clean cloth dampened with a mild soap and water solution.

Do not immerse this toy.

• This toy has no consumer serviceable parts. Do not take this toy apart.

• Protect the environment by not disposing of this product with

household waste (2002/96/EC). Check your local authority for

recycling advice and facilities.

Battery Safety Information

In exceptional circumstances, batteries may leak fluids that can cause a chemical

burn injury or ruin your product. To avoid battery leakage:

• Do not mix old and new batteries or batteries of different types: alkaline,

standard (carbon-zinc) or rechargeable (nickel-cadmium).

• Insert batteries as indicated inside the battery compartment.

• Remove batteries during long periods of non-use. Always remove exhausted

batteries from the product. Dispose of batteries safely. Do not dispose of this

product in a fire. The batteries inside may explode or leak.

• Never short-circuit the battery terminals.

• Use only batteries of the same or equivalent type, as recommended.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the product before charging.

• If removable, rechargeable batteries are used, they are only to be charged

under adult supervision.

Remote

3 Leaves

3 Soft Toys

Clamp

Base

Arm

Crib

Adaptor

Mobile Hub

Note: All of the screws used to assemble this toy are attached to the product.

Follow these instructions carefully to fully secure the screws.

Tighten and loosen all screws with a Phillips screwdriver. Do not overtighten.

Parts

Battery Installation

Hint: We recommend using alkaline batteries for longer battery life.

• Loosen the screws in mobile base battery compartment door with Phillips

screwdriver and remove the door.

Hint: If the crib adaptor is attached to the base, loosen the screws in the crib

adaptor and remove it first.

• Insert three "D" (LR20) alkaline batteries.

• Loosen the screw in the remote battery compartment door with a Phillips

screwdriver and remove the door.

• Insert two "AA" (LR6) alkaline batteries.

• Replace each battery compartment door and tighten the screws.

IMPORTANT! Under normal use conditions, the batteries in the base will require

replacement more often than the batteries in the remote. When sounds or light

become faint or movement of the mobile is sluggish, it's time for an adult to

replace the batteries in the base.

PRINTED IN CHINA K3799b-0920

1,5V x 3

“D” (LR20)

1,5V x 2

“AA” (LR6)

IMPORTANT! If the mobile does not respond to the remote, it does not mean that

the battery power in the remote is low. Replace the batteries in the remote if the

LED signal indicator on the remote is dim when the button is pressed. If the LED

signal indicator does not light after installing new batteries in the remote, check

the orientation of the batteries in the battery compartment to make sure they are

properly installed.

Mobile Base Remote

Assembly

Crib Adaptor

• Fit the crib adaptor to the base.

• Tighten the four screws in the crib adaptor.

• First press the button next to the socket and then slide the socket

door open .

• Fit the arm into the socket in the base.

• Tighten both screws in the arm.

Arm

Base

 PRESS

Socket



SLIDE

• Fit the mobile hub onto the end of the arm.

• Tighten both screws in the arm to secure the mobile hub.

Hint: You may want to attach the soft toys to the mobile hub before assembling

the arm to the mobile hub. Please refer to assembly step 5 for instructions to

assemble the soft toys.

Mobile Hub

Assembly

• “Snap” the leaves into the slots in the mobile hub.

Leaves

• Fit the soft toys to the pegs on the underside of the mobile hub.

• Tighten the screw in each toy to secure each to the mobile hub.

Soft Toys

Assembly

Crib Attachment

Base Crib Top Rail

Clamp

• Fit the base onto the crib top rail, so that the threaded peg extends

outside the crib.

• Fit the clamp onto the threaded peg and turn the clamp clockwise to

secure the base to the crib.

• Do not over-tighten the clamp.

Mattress

Bottom of Base

At least 7 inches

• If the distance between the bottom of the base and the mattress is less than

7 inches (18 cm), lower the crib mattress.

Remote Use

• Press the button on the remote to activate music, lights and motion.

• Press again to stop.

• In the unlikely event that use of the remote interferes with normal use

of other remote controlled equiment, such as televisions or stereos, or use of

other electronic or battery powered appliances interfere with operation of the

mobile, do not use both at the same time.

• You may notice a loss of range between the remote and the mobile when using

in bright light. For best performance, avoid using the remote in areas of bright

light. Move the mobile, or reduce the amount of light to improve performance.

• Position the mobile so that the receiver arrow points towards the area that the

remote will be used. Make sure there is a clear path between the remote and

the mobile. Point the end of the remote toward the mobile receiver and

press the button.

Note: The remote will remain active for about one hour. When the LED goes out,

you will need to slide the power/volume switch on the mobile off, then on again

to reactivate.

Classical Music, Rainforest Sounds,

Lights and Motion

Power/Volume Switch

Choose from three settings:

ON with low volume

ON with higher volume

OFF

Lights and M

otion Select Switch

Lights and Music

Lights, Music and Motion

Motion and Music

Music and Sound Select Buttons

Choose classical music from Bach,

Beethoven and Mozart or soothing

sounds of the Rainforest.
