Fein JHM Magforce User manual

FEIN Service

USA

FEIN Power Tools Inc.

1030 Alcon Street

Pittsburgh, PA 15220

Telephone: (412) 922-8886

Toll Free: 1-800-441-9878

www.feinus.com

Headquarter

C. & E. FEIN GmbH

Hans-Fein-Straße 81

D-73529 Schwäbisch Gmünd-Bargau

www.fein.com

 JHM Magforce 7 272 53

OBJ_DOKU-0000001870-002.fm Page 1 Thursday, October 4, 2012 4:14 PM

Instruction Manual

Instrucciones de uso

OBJ_BUCH-0000000058-002.book Page 2 Thursday, October 4, 2012 4:11 PM

For your safety.

Read all safety warnings and

all instructions. Failure to fol-

low the warnings and instructions may result

in electric shock, fire and/or serious injury.

Save all warnings and instructions for future-

reference.

Do not use this power tool before you

have thoroughly read and completely

understood this Instruction Manual, including

the figures, specifications, safety regulations

and the signs indicating DANGER, WARN-

ING and CAUTION.

Only carry out such operations with this

power tool as intended for by the manufac-

turer. Only use cutting tools and accessories

that have been approved by the manufac-

turer.

Please also observe the relevant national

industrial safety regulations.

Non-observance of the safety instructions in

the said documentation can lead to an electric

shock, burns and/or severe injuries.

This Instruction Manual should be kept for

later use and enclosed with the power tool,

should it be passed on or sold.

SAVE THESE INSTRUCTIONS.

The term “power tool” in the warnings refers

to your mains-operated (corded) power tool

or battery operated (cordless) power tool.

General safety rules.

1) Work area safety

a)Keep work area clean and well lit. Clut-

tered or dark areas invite accidents.

b)Do not operate power tools in explosive

atmospheres, such as in the presence of

flammable liquids, gases or dust. Power

tools create sparks which may ignite the

dust or fumes.

c) Keep children and bystanders away

while operating a power tool. Distrac-

tion can cause you to lose control.

2) Electrical safety

a)Power tool plugs must match the outlet.

Never modify the plug in any way. Do not

use any adapter plugs with earthed

(grounded) power tools. Unmodified

plugs and matching outlets will reduce

risk of electric shock.

b)Avoid body contact with earthed or

grounded surfaces such as pipes, radia-

tors, ranges and refrigerators. There is

an increased risk of electric shock if

your body is earthed or grounded.

c) Do not expose power tools to rain or wet

conditions. Water entering a power tool

will increase the risk of electric shock.

d)Do not abuse the cord. Never use the

cord for carrying, pulling or unplugging

the power tool. Keep cord away from

heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase

the risk of electric shock.

e) When operating a power tool outdoors,

use an extension cord suitable for out-

door use. Use of a cord suitable for out-

door use reduces the risk of electric

shock.

f) If operating a power tool in a damp loca-

tion is unavoidable, use a residual cur-

rent device (RCD) protected supply. Use

of an RCD reduces the risk of electric

shock.

3) Personal safety

a)Stay alert, watch what you are doing

and use common sense when operating

a power tool. Do not use a power tool

while you are tired or under the influ-

ence of drugs, alcohol or medication. A

moment of inattention while operating

power tools may result in serious per-

sonal injury.

b)Use personal protective equipment.

Always wear eye protection. Protective

equipment such as dust mask, non-skid

safety shoes, hard hat, or hearing pro-

tection used for appropriate conditions

will reduce personal injuries.

c) Prevent unintentional starting. Ensure

the switch is in the off-position before

connecting to power source and/or bat-

tery pack, picking up or carrying the

tool. Carrying power tools with your

finger on the switch or energising

power tools that have the switch on

invites accidents.

d)Remove any adjusting key or wrench

before turning the power tool on. A

wrench or a key left attached to a rotat-

ing part of the power tool may result in

personal injury.

WARNING

OBJ_BUCH-0000000058-002.book Page 3 Thursday, October 4, 2012 4:11 PM

4en

e) Do not overreach. Keep proper footing

and balance at all times. This enables

better control of the power tool in

unexpected situations.

f) Dress properly. Do not wear loose cloth-

ing or jewelery. Keep your hair, clothing

and gloves away from moving parts.

Loose clothes, jewelry or long hair can

be caught in moving parts.

g)If devices are provided for the connec-

tion of dust extraction and collection

facilities, ensure these are connected

and properly used. Use of dust collec-

tion can reduce dust-related hazards.

4) Power tool use and care

a)Do not force the power tool. Use the cor-

rect power tool for your application. The

correct power tool will do the job bet-

ter and safer at the rate for which it was

designed.

b)Do not use the power tool if the switch

does not turn it on and off. Any power

tool that cannot be controlled with the

switch is dangerous and must be

repaired.

c) Disconnect the plug from the power

source and/or the battery pack from the

power tool before making any adjust-

ments, changing accessories, or storing

power tools. Such preventive safety

measures reduce the risk of starting the

power tool accidentally.

d)Store idle power tools out of the reach of

children and do not allow persons unfa-

miliar with the power tool or these

instructions to operate the power tool.

Power tools are dangerous in the hands

of untrained users.

e) Maintain power tools. Check for mis-

alignment or binding of moving parts,

breakage of parts and any other condi-

tion that may affect the power tool’s

operation. If damaged, have the power

tool repaired before use. Many accidents

are caused by poorly maintained power

tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with

sharp cutting edges are less likely to

bind and are easier to control.

g)Use the power tool, accessories and tool

bits etc. in accordance with these

instructions, taking into account the

working conditions and the work to be

performed. Use of the power tool for

operations different from those

intended could result in a hazardous sit-

uation.

5) Service

a)Have your power tool serviced by a qual-

ified repair person using only identical

replacement parts. This will ensure that

the safety of the power tool is main-

tained.

Special safety instructions.

Wear personal protective equipment. Depend-

ing on application, use face shield, safety

goggles or safety glasses. Where appropriate,

wear dust mask, hearing protectors, gloves

and workshop apron capable of stopping

small abrasive or workpiece fragments. The

safety glasses must be capable of protecting

against flying particles generated by the vari-

ous operations. Prolonged exposure to high

intensity noise may cause loss of hearing.

Secure the power tool with the safety strap

supplied at all times, especially for work car-

ried out at elevated heights, when drilling

horizontally or above the head. If there is a

power loss, or the power plug is pulled out,

the magnetic holding power is not main-

tained.

When working overhead or on vertical sur-

faces, the coolant container must not be used.

Use Slugger Cutting Paste instead. Liquids

penetrating your electric power tool may-

cause electric shock.

Avoid touching the drilled core that is auto-

matically ejected by the pilot pin when the

working procedure is finished. Contact with

the core when it is hot, or if it falls, can cause

personal injuries.

Operate the power tool only from grounded

contact sockets that comply with the specifi-

cations. Do not use any connection cables

that are damaged; use extension cables with

a grounded contact that are checked at regu-

lar intervals. A ground conductor without

continuity can cause an electric shock.

OBJ_BUCH-0000000058-002.book Page 4 Thursday, October 4, 2012 4:11 PM

To prevent injuries, always keep your hands,

clothing, etc. away from rotating swarf. The

swarf can cause injuries. Always use the chip-

ping protector.

Do not attempt to remove the cutting tool if it

does not turn. This can lead to serious injuries.

Hold power tool by insulated gripping sur-

faces when performing an operation where

the cutting accessory may contact hidden

wiring or its own cord. Cutting accessory con-

tacting a “live” wire will make exposed metal

parts of the power tool “live” and shock the

operator.

Beware of any concealed electric cables, gas

or water conduits. Check the working area

before commencing work, e.g. with a metal

detector.

Do not rivet or screw any name-plates or signs

onto the power tool. If the insulation is damaged,

protection against an electric shock will be inef-

fective. Adhesive labels are recommended.

Do not use accessories which are not specifi-

cally designed and recommended by the

power tool manufacturer. Safe operation is

not ensured merely because an accessory fits

your power tool.

Clean the ventilation openings on the power

tool at regular intervals using non-metal

tools. The blower of the motor draws dust

into the housing. An excessive accumulation

of metallic dust can cause an electrical hazard.

Before putting into operation, check the

power connection and the power plug for

damage.

Recommendation: The tool should always be

supplied with power via a residual current

device (RCD) with a rated current of 30 mA or

less.

Handling hazardous dusts.

When working with power

tools, such as when grinding,

sanding, polishing, sawing or for other work

procedures where material is removed, dusts

develop that are both hazardous to one’s

health and can spontaneously combust or be

explosive.

Contact with or inhaling some dust types can

trigger allergic reactions to the operator or

bystanders and/or lead to respiratory infec-

tions, cancer, birth defects or other reproduc-

tive harm.

Examples of such materials which contain

chemicals that can produce hazardous dusts,

are:

–Asbestos and materials containing asbestos

–Lead-containing coatings, some wood

types such as beech and oak

–Minerals and metal

–Silicate particles from bricks, concrete and

other materials containing stone

–Solvent from solvent-containing paint/var-

nish

–Arsenic, chromium and other wood pre-

servatives;

–Materials for pesticide treatment on boat

and ship hulls

–Stainless steel dust, metal dust and non-

ferrous metal dust

To minimize the unwanted intake of these

materials:

–Use dust extraction matched appropriately

for the developing dust.

–Use personal protective equipment, such

as a P2 filter-class dust protection mask.

–Provide for good ventilation of the work-

place.

The risk from inhaling dusts depends on how

often these materials are worked. Materials

containing asbestos may only be worked by

specialists.

Wood and light-metal dust can

cause spontaneous combus-

tion or explosions.

Hot mixtures of sanding dust and paint/varnish

residuals or other chemical materials in the fil-

ter bag or the vac filter can self-ignite under

unfavourable conditions, such as sparking from

sanding metal, continuous sunlight or high

ambient temperatures. To prevent this:

–Avoid overheating the material being

sanded and the power tool.

–Empty the dust collector/container rou-

tinely.

–Observe the material manufacturer’s

working instructions.

–Observe the relevant regulations for the

materials being worked.

WARNING

CAUTION

OBJ_DOKU-0000001885-002.fm Page 5 Thursday, October 4, 2012 4:30 PM

6en

Emission values for sound (Two-figure – specifications as per ISO 4871)

Extension cable.

If the use of an extension cord

is required, its length and con-

ductor cross-section must be adequate for the

application in order to prevent a voltage drop

in the extension cord, power loss and over-

heating of the power tool. Otherwise, the

extension cable and power tool are prone to

electrical danger, and the working efficiency is

decreased.

Recommended dimensions of extension cords

at an operating voltage of 120 V – single-

phase a. c., with only JHM Magforce con-

nected:

Intended use of the power tool:

Magnetic base drill for drilling with annular

cutting tools on ferrous materials in con-

trolled environments using the cutting tools

and accessories recommended by the manu-

facturer.

Operation of the power tool off power generators.

This power tool is also suitable for use

with AC generators with sufficient power

output that correspond to the Standard

ISO 8528, design type G2. This Standard is

particularly not complied with when the so-

called distortion factor exceeds 10 %. When

in doubt, please refer to the generator

instruction/specification guide.

Operating the power tool off

power generators whose no-

load speed exceeds the voltage value on the

type plate of the power tool is prohibited.

Sound emission

A-weighted emission pressure power level measured at the workplace LpA

(re 20 μPa), in decibels 87

Measuring uncertainty KpA, in decibels 3

Measured A-weighted sound power level LwA (re 1 pW), in decibels 98

Measuring uncertainty KwA, in decibels 3

C-weighted peak sound pressure level measured at the workplace LpCpeak,

in decibels 99

Measuring uncertainty KpCpeak, in decibels 3

REMARK: The sum of the measured emission value and respective measuring inaccuracy

represents the upper limit of the values that can occur during measuring.

Wear hearing protection!

Measured values determined in accordance with the corresponding product standard.

WARNING

Max. cable length, ft Max. cable length, m

≤ 100 100

–200 200

–300 ≤ 30 30

– 60 60

–100

Min. conductor size

A.W.G. Min. conductorcross-

section, mm2

16 14 12 1.5 2.5 4

WARNING

OBJ_DOKU-0000001885-002.fm Page 6 Thursday, October 4, 2012 4:30 PM

Symbols.

Symbol, character Explanation

Do not touch the rotating parts of the power tool.

Observe the instructions in the text or graphic opposite!

Make sure to read the enclosed documents such as the Instruction Man-

ual and the General Safety Instructions.

Before commencing this working step, pull the power plug out of the-

socket. Otherwise there will be danger of injury if the power tool

should start unintentionally.

Use eye protection during operation.

Use ear protection during operation.

This symbol confirms the certification of this product for the USA and

Canada.

This sign warns of a directly imminent, dangerous situation. A false reac-

tion can cause a severe or fatal injury.

This sign indicates a possible dangerous situation that could cause severe

or fatal injury.

This sign warns of a possible dangerous situation that could cause injury.

Worn out power tools and other electrotechnical and electrical prod-

ucts should be sorted separately for environmentally-friendly recycling.

Product with basic insulation and exposed, conductive parts additionally

connected to the ground conductor.

~ or a. c. Alternating current

1 ~ Alternating current, single-phase

DANGER

WARNING

CAUTION

OBJ_BUCH-0000000058-002.book Page 7 Thursday, October 4, 2012 4:11 PM

8en

Character Unitofmeasurement,

national Explanation

nrpm;/min;min

-1;

r/min Rated speed

P W Electrical power

° Angle width

UV Electric voltage

fHz Frequency

I A Electric current intensity

mlbs Mass

lft, in Length, width, height, depth, diameter or thread

Ø ft, in Diameter of a round part

m, s, kg, A, mm, V,

W, Hz, N, °C, dB,

min, m/s2

Basic and derived units of measurement from the

international system of units SI.

OBJ_BUCH-0000000058-002.book Page 8 Thursday, October 4, 2012 4:11 PM

Technical description and specifications.

Before mounting or replacing cutting tool or accessories, pull the power plug.

This preventive safety measure rules out the danger of injuries through acciden-

tal starting of the power tool.

All accessories described or shown in this instruction manual will not be included with your-

power tool.

WARNING

Chip guard

Magnetic base

Spoke handle

Coolant container

Coolant Bottle Cap

Safety strap attachment

Type JHM Magforce

Order number 7 272 53

Current consumption 9.8 A

Rated speed 450 /min

Weight according to EPTA-Procedure 01/2003 28.9 lbs (13.1 kg)

Class of protection /I

OBJ_BUCH-0000000058-002.book Page 9 Thursday, October 4, 2012 4:11 PM

10 en

Assembly instructions.

Before mounting or replacing cutting tool or accessories, pull the power plug.

This preventive safety measure rules out the danger of injuries through acci-

dental starting of the power tool.

Mounting the spoke handles

(figure 2).

Thread the three spoke handles into the hub

assembly.

The hub assembly can be mounted on either side. (figure 3)

WARNING

Spoke handle

Hub assembly

Spoke handle

OBJ_BUCH-0000000058-002.book Page 10 Thursday, October 4, 2012 4:11 PM

Table of contents

Languages:

Popular Power Tools manuals by other brands

AEG

AEG OMNI-JS Original instructions

SIP

SIP 01533 manual

Ribimex

Ribimex PRS499 quick start guide

3M Fiber Optic Connector Crimp Tool instructions

Ryobi

Ryobi P524 Operator's manual

ROJEK

ROJEK FSN 300A manual

Kemper

Kemper 1740PRO manual

WABCO

WABCO OptiTire installation manual

EINHELL

EINHELL TE-MS 18/210 Li Original operating instructions

Orgapack

Orgapack OR-T 85 Operating and safety instructions

TOUGHCUT

TOUGHCUT Diamond 400 instruction manual

Yaros

Yaros PB-3603 user manual

Baileigh Industrial

Baileigh Industrial SS-2725 Operator's manual

Milwaukee

Milwaukee 2674-20 Operator's manual

Princess

Princess Electric Multi Sharpener user manual

FOREDOM

FOREDOM K.1050 Operation & maintenance manual

Blaupunkt

Blaupunkt TIF 30 DA manual

Silca

Silca MARKER 2000 operating manual
