Fein KBM 32Q User manual

© C. & E. FEIN GmbH. Printed in Germany. Abbildungen unverbindlich. Technische Änderungen vorbehalten. 3 41 01 011 21 0 BY 2010.02 DE.
FEIN Service
USA
FEIN Power Tools Inc.
1030 Alcon Street
Pittsburgh, PA 15220
Telephone: (412) 922-8886
Toll Free: 1-800-441-9878
www.feinus.com
Canada
FEIN Canadian Power Tool
Company
323 Traders Boulevard East
Mississauga, Ontario L4Z 2E5
Telephone.:(905) 8901390
Toll Free: 1-800-265-2581
FEIN Canadian Power Tool
Company
2810 De Miniac
St. Laurent, Quebec H4S 1K9
Telephone: (514) 331-7390
Toll Free: 1-800-789-8181
www.fein.com
Headquarter
C. & E. FEIN GmbH
Hans-Fein-Straße 81
D-73529 Schwäbisch Gmünd-Bargau
www.fein.com
KBM32Q
7 270 27
3 41 01 011 21 0 - Umschlag.fm Seite 1 Donnerstag, 4. Februar 2010 4:12 16

2
English _____________ Instruction manual___________________
Français ____________ Mode d'emploi______________________
Español _____________ Instrucciones de uso _________________
3
17
32
3 41 01 011 21 0.book Seite 2 Montag, 8. Februar 2010 11:51 11

3
en
For your safety.
Read all safety warnings and
all instructions.
Failure to fol-
low the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
Do not use this power tool before you
have thoroughly read and completely
understood this Instruction Manual, including
the figures, specifications, safety regulations
and the signs indicating DANGER, WAR-
NING and CAUTION.
Only carry out such operations with this
power tool as intended for by FEIN. Only use
application tools and accessories that have
been released by FEIN.
Please also observe the relevant national
industrial safety regulations.
Non-observance of the safety instructions in
the said documentation can lead to an electric
shock, burns and/or severe injuries.
This Instruction Manual should be kept for
later use and enclosed with the power tool,
should it be passed on or sold.
SAVE THESE INSTRUCTIONS.
General Safety Rules.
1) Work area safety
a)
Keep work area clean and well lit.
Clut-
tered or dark areas invite accidents.
b)
Do not operate power tools in explosive at-
mospheres, such as in the presence of
flammable liquids, gases or dust.
Power
tools create sparks which may ignite the
dust or fumes.
c)
Keep children and bystanders away while
operating a power tool.
Distraction can
cause you to lose control.
2) Electrical safety
a)
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs
and matching outlets will reduce risk of
electric shock.
b)
Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges and refrigerators.
There is an in-
creased risk of electric shock if your body
is earthed or grounded.
c)
Do not expose power tools to rain or wet
conditions.
Water entering a power tool
will increase the risk of electric shock.
d)
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts.
Damaged or
entangled cords increase the risk of elec-
tric shock.
e)
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use re-
duces the risk of electric shock.
f)
If operating a power tool in a damp location
is unavoidable, use a residual current de-
vice (RCD) protected supply.
Use of an
RCD reduces the risk of electric shock.
3) Personal safety
a)
Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alco-
hol or medication.
A moment of inatten-
tion while operating power tools may re-
sult in serious personal injury.
b)
Use safety equipment. Always wear eye
protection.
Safety equipment such as dust
mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate
conditions will reduce personal injuries.
c)
Avoid accidental starting. Ensure the switch
is in the off-position before plugging in.
Carrying power tools with your finger on
the switch or plugging in power tools that
have the switch on invites accidents.
d)
Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a
key left attached to a rotating part of the
power tool may result in personal injury.
WARNING
3 41 01 011 21 0.book Seite 3 Montag, 8. Februar 2010 11:51 11

4
en
e)
Do not overreach. Keep proper footing and
balance at all times.
This enables better
control of the power tool in unexpected
situations.
f)
Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts.
Loose
clothes, jewelry or long hair can be caught
in moving parts.
g)
If devices are provided for the connection of
dust extraction and collection facilities, en-
sure these are connected and properly
used.
Use of these devices can reduce
dust-related hazards.
4) Power tool use and care
a)
Do not force the power tool. Use the correct
power tool for your application.
The cor-
rect power tool will do the job better and
safer at the rate for which it was designed.
b)
Do not use the power tool if the switch does
not turn it on and off.
Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c)
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools.
Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
d)
Store idle power tools out of the reach of
children and do not allow persons unfamil-
iar with the power tool or these instructions
to operate the power tool.
Power tools are
dangerous in the hands of untrained users.
e)
Maintain power tools. Check for misalign-
ment or binding of moving parts, breakage
of parts and any other condition that may
affect the power tools operation. If dam-
aged, have the power tool repaired before
use.
Many accidents are caused by poorly
maintained power tools.
f)
Keep cutting tools sharp and clean.
Prop-
erly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g)
Use the power tool, accessories and tool
bits etc., in accordance with these instruc-
tions and in the manner intended for the
particular type of power tool, taking into
account the working conditions and the
work to be performed.
Use of the power
tool for operations different from those in-
tended could result in a hazardous situation.
5) Service
a)
Have your power tool serviced by a quali-
fied repair person using only identical re-
placement parts.
This will ensure that the
safety of the power tool is maintained.
Special safety instructions.
Wear personal protective equipment. Depen-
ding on the application, use a face shield,
safety goggles or safety glasses. Wear ear pro-
tection.
The safety glasses must be capable of
protecting against flying particles generated
by the various different operations. Prolon-
ged exposure to high intensity noise may
cause loss of hearing.
Secure the power tool with the clamping strap
supplied if there is danger of it falling, espe-
cially for work carried out at a height, on verti-
cal construction elements or above the head.
If
there is a power cut, or the mains plug is
pulled out, the magnetic holding power is not
maintained.
When working overhead or on vertical sur-
faces, the coolant container must not be used.
Use a coolant spray instead.
Liquids penetra-
ting your electric power tool may cause elec-
tric shock.
Avoid touching the drilled core that is automati-
cally ejected by the centering pin when the
working procedure is finished.
Contact with
the core when it is hot, or if it falls, can cause
personal injuries.
Operate the power tool only from earthing con-
tact sockets that comply with the specificati-
ons. Do not use any connection cables that are
damaged; use extension cables with an eart-
hing contact that are checked at regular inter-
vals.
A earth conductor without continuity
can cause an electric shock.
3 41 01 011 21 0.book Seite 4 Montag, 8. Februar 2010 11:51 11

5
en
Do not machine any material containing asbes-
tos.
Asbestos is cancerogenic.
To prevent injuries, always keep your hands,
clothing, etc. away from rotating swarf.
The
swarf can cause injuries. Always use the chip-
ping protector.
Do not attempt to remove the application tool if
it does not turn.
This can lead to serious injuries.
Do not rivet or screw any name-plates or signs
onto the power tool.
If the insulation is dama-
ged, protection against an electric shock will be
ineffective. Adhesive labels are recommended.
Do not use accessories which are not specifi-
cally designed and recommended by the power
tool manufacturer.
Safe operation is not ensu-
red merely because an accessory fits your
power tool.
Clean the ventilation openings on the power
tool at regular intervals using non-metal tools.
The blower of the motor draws dust into the
housing. An excessive accumulation of metal-
lic dust can cause an electrical hazard.
Hold power tool by insulated gripping surfaces,
when performing an operation where the cut-
ting accessory may contact hidden wiring or its
own cord.
Cutting accessory contacting a “live”
wire will make exposed metal parts of the
power tool ‘“live” and shock the operator.
With a tool inserted, the motor may not move
downward by itself.
Readjust hexagon nut
(790) as required. Before readjusting, pull the
mains plug from the socket outlet and
remove the cover (950). Pay attention to the
sensitive electronics below the cover!
See exploded view.
Before putting into operation, check the mains
connection and the mains plug for damage.
Handling hazardous dusts
When working with power
tools, such as when grinding,
sanding, polishing, sawing or for other work pro-
cedures where material is removed, dusts deve-
lop that are both hazardous to one’s health and
can spontaneously combust or be explosive.
Contact with or inhaling some dust types can
trigger allergic reactions to the operator or
bystanders and/or lead to respiratory infec-
tions, cancer, birth defects or other repro-
ductive harm.
Examples of such materials and therein con-
tained chemicals, where hazardous dusts can
develop when working them, are:
– Asbestos and materials containing asbestos;
– Lead-containing coatings, some wood types
such as beech and oak;
– Minerals and metal;
– Silicate particles from bricks, concrete and
other materials containing stone;
– Solvent from solvent-containing paint/varnish;
– Arsenic, chromium and other wood pre-
servatives;
– Materials for pesticide treatment on boot
and ship hulls.
To minimise the unwanted intake of these
materials:
– Use dust extraction matched appropriately
for the developing dust.
– Use personal protective equipment, such as
a P2 filter-class dust protection mask.
– Provide for good ventilation of the workplace.
The risk from inhaling dusts depends on the
frequency how often these materials are wor-
ked. Materials containing asbestos may only
be worked by specialists.
Wood and light-metal dust can
causespontaneous combustion
or explosions.
Hot mixtures of sanding dust and paint/varnish
remainders or other chemical materials in the
filter bag or the vac filter can self-ignite under
unfavourable conditions, such as sparking from
sanding metal, continuous sunlight or high
ambient temperatures. To prevent this:
– Avoid overheating the material being san-
ded and the power tool.
– Empty the dust collector/container in time.
– Observe the material manufacturer’s wor-
king instructions.
Observe the relevant regulations in your
country for the materials being worked.
WARNING
CAUTION
3 41 01 011 21 0.book Seite 5 Montag, 8. Februar 2010 11:51 11

6
en
Emission values for sound and vibration
(Two-figure – specifications as per ISO 4871)
Extension cord
If the use of an extension cable
is required, its length and con-
ductor cross-section must be adequate for the
applicational case, in order to prevent a volt-
age drop in the extension cable, power loss and
overheating of the power tool.
Otherwise, the
extension cable and power tool are liable to
electrical danger, and the working efficiency is
impaired.
Recommended dimensions of extension cords
at an operating voltage of 120 V – single-phase
a. c., with only one power tool KBM32Q con-
nected:
Intended use of the power tool.
core drill for drilling with core and solid drill
bits, on materials with surfaces suitable for
magnets in weather-protected environments
using the application tools and accessories
recommended by FEIN.
Sound emission
Measured A-weighted sound power level L
wA
(re 1 pW), in decibels: 95
Measuring uncertainty K
wA
, in decibels: 3
A-weighted emission pressure power level measured at the workplace L
pA
(re 20 µPa),
in decibels: 84
Measuring uncertainty K
pA
, in decibels: 3
C-weighted peak sound pressure level measured at the workplace L
pCpeak
, in decibels: 99.5
Measuring uncertainty K
pCpeak
, in decibels: 3
Vibrations
Vibration emission value (triax vector sum) determined according to EN 60745 , in
m/s
2
: 0.5
ft/s
2
: 1.5
Measuring uncertainty K, in
m/s
2
: 1.5
ft/s
2
: 4.5
REMARK: The sum of the measured emission value and respective measuring inaccuracy
represents the upper limit of the values that can occur during measuring.
Wear ear protection!
Measured values determined in accordance with the corresponding product standard.
WARNING
Cord Size in A.W.G.
16 14 12
Cord Length in Feet
50 100 150
3 41 01 011 21 0.book Seite 6 Montag, 8. Februar 2010 11:51 11

7
en
Symbols.
Symbol Explanation
➤
Action to be taken by the user
This action is forbidden!
Do not touch the rotating grinding wheels.
Follow the instructions in the adjacent text or graphic!
Be absolutely sure to read the enclosed documentation such as the
Instruction Manual and the General Safety Instructions.
Follow the instructions in the adjacent text or graphic!
Before commencing this working step, pull the mains plug out of the
socket. Otherwise there will be danger of injury if the power tool should
start unintentionally.
Use eye-protection during operation.
Use ear protection during operation.
This symbol confirms the certification of this product for the USA and
Canada.
This sign warns of a directly imminent, dangerous situation. A false reac-
tion can cause a severe or fatal injury.
This sign indicates a possible dangerous situation that could cause severe
or fatal injury.
This sign warns of a possible dangerous situation that could cause injury.
Worn out power tools and other electrotechnical and electrical products
should be sorted separately for environment-friendly recycling.
Product with basic insulation and exposed (touchable), conductive parts
additionally connected to the protective earth conductor.
~ or a. c. Alternating current
1 ~ Alternating current single-phase
Ø
Diameter of a round part
!
DANGER
WARNING
CAUTION
3 41 01 011 21 0.book Seite 7 Montag, 8. Februar 2010 11:51 11

8
en
Character Unit of measure, national Explanation
n
0
rpm Revolution speed at no-load
P W Unit of measure for electrical power
V Unit of measure for the electric voltage
f Hz Unit of measure for the frequency
I A Unit of measure for the electric current intensity
° Unit of measure for the angle width
m lbs Unit of measure for the mass
l
ft, in Unit of measure for length, height, depth or diameter
m, s, kg, A, mm, V, W,
Hz, N, °C, dB, min, m/s
2
Basic and derived units of measure from the interna-
tional system of units
SI
.
3 41 01 011 21 0.book Seite 8 Montag, 8. Februar 2010 11:51 11

9
en
Technical description and specifications.
Before mounting or replacing application tools or accessories, pull the power
plug.
This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Only part of the accessories described or shown in this instruction manual will be included
with your power tool.
WARNING
Fig. 1
Motor switch
Magnetic foot
Guard protecting against chippings
QuickIN
Tool holder
Application tool
Depth scale
Capstan handle
3 41 01 011 21 0.book Seite 9 Montag, 8. Februar 2010 11:51 11

10
en
Type KBM32Q
Reference number 7 270 27
Power input 700 W
Output 450 W
Power supply type 1 ~
No-load speed 550 rpm
Speed, full load 440 rpm
Weight according to EPTA-Procedure 01/2003 10.5 kg
23.1 lbs
Class of protection I
Drilling capacity in steel (core drill bits) 32 mm
1
1
/
4
in
Drilling capacity in steel (twist drill bits) 13 mm
1
/
2
in
Max. twist drill diameter with the supplied chuck 13 mm
1
/
2
in
3 41 01 011 21 0.book Seite 10 Montag, 8. Februar 2010 11:51 11
Other manuals for KBM 32Q
3
Table of contents
Languages:
Other Fein Drill manuals

Fein
Fein ASCD18W2 User manual

Fein
Fein ABS18 Q User manual

Fein
Fein Slugger HoleMaker III User manual

Fein
Fein ASCM 12 C User manual

Fein
Fein ASq 658 User manual

Fein
Fein KBM 50 Q User manual

Fein
Fein Handy Master ABS14 User manual

Fein
Fein ABS 18 User manual

Fein
Fein BOP6 User manual

Fein
Fein Slugger JHM Magforce X User manual

Fein
Fein ASCM18QM Series User manual

Fein
Fein kbb38x Setup guide

Fein
Fein ABS18 Q User manual

Fein
Fein kbb38x User manual

Fein
Fein KBM 52 U User manual

Fein
Fein KBE 35 Series User manual

Fein
Fein ASCD12-100W4 Series User manual

Fein
Fein BOP 6 Setup guide

Fein
Fein AGWP10 User manual

Fein
Fein ASCT18 User manual
