Eton P' 9120 User manual

porsche design

audio

ß9120

Instruction manual

Bedienungsanleitung

Mode d’emploi

Instrucciones de uso

Istruzioni per l’uso

P´9121 − North America XM I P´9122 − Europe DAB I P´9123 − United Kingdom DAB I

P´9124 − Germany DAB I P´9125 − Japan I P´9127 − Europe I P´9128 − Germany

Instruction manual

Bedienungsanleitung

Mode d’emploi

Instrucciones de uso

Istruzioni per l’uso

[ENG] Instruction manual −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− 03 − 36

[D] Bedienungsanleitung −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− 37 − 72

[F] Mode d’emploi −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− 73 − 110

[E] Instrucciones de uso −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− 111 − 150

[I] Istruzioni per l’uso −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− 151 − 190

Warning Environment

Disposal

According to the European Directive 2002/96/EC all electri-

cal and electronic products must be collected separately

by a local collection system.

Please act according to your local rules and do not dispose

of your old products with your normal household waste.

03 − 04

[ENG] Instruction manual

− Do not expose this appliance to rain or moisture.

− Do not submerge or expose for extended period to water.

− Protect from high humidity and rain.

− Only operate within speciﬁed temperature range

[0 °C to 40 °C].

− Unplug immediately if liquid has been spilled or objects have

fallen into the apparatus.

− Clean only with a dry cloth. Do not use detergents or chemi-

cal solvents as this might damage the ﬁnish.

− Unplug and disconnect external antennas during lightning

storms.

− Do not remove cover [or back].

− Refer servicing to qualiﬁed service personnel.

Need help? Contact us.

Etón Corporation

1015 Corporation Way

Palo Alto, CA 94303

USA

1−800−872−2228 [U.S.];

1−800−637−1648 [Canada];

1−650−903−3866 [Worldwide]

M−F, 8:30−4:00, Paciﬁc Time

www.etoncorp.com

Note: Not all sections in this manual may apply to your model.

The unit is powered by non grounded power adapter. When

connecting to sensitive external equipment eg. Pre-amp, users

should insure that the product is switched off before connecting.

Unit also should be installed away from any grounded equip-

ment to avoid electrical shock.

What Your Radio Includes?

− Owner’s manual

− Remote control

− iPod dock

− iPod dock inserts

− AM antenna (P´9121,

P´9125, P´9127, P´9128 only)

− Removable FM/SW/DAB

telescopic antenna

− FM/SW/DAB telescopic

antenna tool

− AC adapter

Preparing The Remote For Use

Grip the plastic piece on the bottom of the remote unit and pull

it out. If the battery drains replace it with a CR/DL2025.

[ENG] Instruction manual

05 − 06

Installing The Backup Batteries

[1.1]

Remove the rubber pad from the bottom of the radio and

install 4 AA alkaline batteries [not included] following the

installation diagram inside the battery compartment [1.1].

These batteries back up the time and alarm set in the

radio in case of a power failure. Replace the rubber pad

once they’re installed. In case of a power failure, if you

have backup batteries in the radio, the display will show

“CHECK POWER”. The batteries will keep the display and

clock running for about 8 hours if the power fails.

! Note regarding batteries ! Only use alkaline batteries. Do

not mix different brands or types of batteries. Change your

batteries once every six months. Check the batteries once

a month to make sure that they have not leaked. Damage

caused by leaked batteries is not covered by warranty.

Powering The Radio

Plug the Power Cord into a mains [AC] outlet, then into the

13.5 VDC, positive polarity socket on the back of the radio.

For best results on AM and SW reception, the power sup-

ply should be positioned away from the radio.

When the power cord is ﬁrst plugged in or the ON/OFF

button is given a quick press the display turns on into ON

mode [2.1]. Using a quick press of the ON/OFF button will

place it into STANDBY mode, with the time of day in the

display [2.2]. Using a longer press, about 4 seconds, of the

ON/OFF button will clear the display and turn everything OFF.

[2.1] [2.2]

Volume Control

The volume is controlled with the volume knob or the VOL +

− buttons on the remote. Turning the volume + increases the

volume; − decreases volume. While adjusting the volume, VOL-

UME SETTING appears in the display, with the volume number,

0−30 under it [3.1 & 3.2].

07 − 08

[ENG] Instruction manual

[3.1]

Muting The Radio

To mute the audio while it is playing, use a quick press of

the remote’s MUTE button [4.1] or the radio’s SNOOZE

button [4.2].

[3.2] [4.2][4.1]

Using Headphones/Earphones

Before placing Earphone/Headphone in/on your ears, turn

the volume all the way down. Use Headphone/Earphone

with a 3.5 mm [1/8th inch] stereo plug. Plug them into the

earphone socket on the back of the radio [5.1 & 5.2].

Selecting the Operating Mode (iPod, XM, FM, AM,

SW, DAB OR AUX)

[5.1] [6.2][6.1][5.2]

After turning on the radio, look at the display [6.1] and either

turn the MODE control on the radio [6.1], or use sequential

presses of the remote’s MODE buttons [6.2] to select the mode

and then press ENTER or wait 5 seconds.

09 − 10

[ENG] Instruction manual

Audio Setting

Listen to some music you like. Press SET [7.1], highlight AUDIO

SETTING with the UP/DOWN buttons [7.2 & 7.3] and press

ENTER. TREBLE is highlighted [7.4]. Press ENTER, select the

desired treble [+5 to −5] with the UP/DOWN buttons and press

ENTER. Select BASS with the UP/DOWN buttons and press

ENTER. Select the desired bass setting [+5 to –5] with the UP/

DOWN buttons and press ENTER. Press SET when ﬁnished.

While making these settings you’ll be able to hear the changes

you make.

[7.1] [7.2] [7.3] [7.4]
