EPSON PRODUCT SUPPORT BULLETIN

Date: 04/07/2003 Originator: TC

PSB #: PSB.2003.04.004 Authorization:

Reference: N/A Total Pages: 1

Product(s): EPSON Scanner Options

Subject: Part numbers for transparency adapter mounting screws (thumbscrews)

This bulletin was created to inform you of the part numbers used for the thumbscrews (mounting

screws) that secure the transparency units to the scanner.

Reason:

Epson Customers may need to replace these thumbscrews because they are missing or

misplaced. Epson Dealers and Customer Care Centers may call Technical Support for assistance

in locating the reference or part number for the thumbscrews. The location of the thumbscrews on

the Product diagram is on the right hand side, and is often overlooked (See red box below)

The correct part and reference numbers for the Expression 1600/1680 Transparency Unit

(B813182) lock-down thumbscrews are respectively: 1012588 and 815. The Parts Price List (PPL)

description is S. THUMB SCREW M4X10 F/NI, Quantity = 2.

Note: The part number is subject to change but the reference number will remain the same.

These screws are used on the following scanners and options: ES-600C/800C/1000C/1200C

options (ADF & TPU), and the Expression 636/800/1600/1680 options (ADF & TPU). The part and

reference number for Expression 1600/1680 Transparency Unit (B813182) can be used to order

replacement thumbscrews for all models and options listed above.

EPSON AMERICA, INC.

Product Support Bulletin

Subject: OS/2 Warp 3.0 and Epson TWAIN

Date: 1/26/95 PSB No: P-0103A

Page(s): 1 of 4 Originator: CEB

This bulletin describes the necessary steps to implement the Epson TWAIN driver

in a Windows 3.1 session under OS/2 Warp 3.0. This procedure will cover both

current versions of Epson TWAIN (1.03 and lower as well as 2.02 and higher) using

bidirectional parallel and SCSI interfaces.

NOTE:

TWAIN v1.03 and lower will not work with the Epson ES-1200C scanner. You must

use TWAIN 2.02 or higher. If you are using the ES-1200C with a program that has

Epson scanner support, you may need install the EPSN.SYS device driver for that

Windows session. To do this, follow steps 6 through 16 below. You will need to

obtain EPSNSY.EXE from the Epson BBS. This file has the EPSN.SYS driver

included in it. Simply copy the driver to the root directory of your boot drive.

Bidirectional Parallel Interface

Epson TWAIN v2.xx

There is no special procedure required to setup this version of the driver to run in a

Windows session under OS/2 Warp 3.0. Simply launch Windows and install the

driver.

Epson TWAIN

~1.0~

Follow the steps below to enable Epson TWAIN

~1.0~:

From the OS/2 desktop, double click on the OS/2 SYSTEM folder

Double click on the COMMAND PROMPTS folder

Double click on the Win-OS/2 icon.

Once Windows is loaded, follow the TWAIN installation procedure. When the

installation program asks if you wish to make changes to the CONFIG.SYS or

the CONFIG.ADD, select CONFIG.ADD.

Once the installation has completed, exit Windows.

If the COMMAND PROMPTS folder is not open, follow steps 1 and 2.

Move the mouse to the WIN-OS/2 FULL SCREEN icon. Click on the right

mouse button.

PSB No: P-0103A

Page: 2 of 4

10.

11.

12.

13.

14.

Select SETTINGS from the pop-up menu.

Once the SETTINGS notebook has opened, click on SESSION.

Click on the WIN-OS2 SETTINGS.

Click on OTHER DOS SETTINGS.

Click on OK.

Highlight DOS-DEVICE.

In the window to the right, add the EPSN.SYS driver. X represents the

appropriate parallel port.

X = 0 (Parallel port address 3BCh)

X = 1 (Parallel port address 378h)

X = 2 (Parallel port address 278h); This is the default setting Epson TWAIN

uses.

The device line would be entered in the following manner. Substitute 0, 1 or 2

based on your configuration.

C:\EPSN.SYS x /i79

15.

Click on SAVE.

16.

Close the SETTINGS notebook.

The next time a Win-OS/:! session is started, you will see the EPSON device driver

load. If you do not, repeat the above steps. If you have migrated a Windows

application to the OS/2 desktop, apply the above steps to that icon instead of the

Win-OS/2 icon. To verify that the configuration is correct, configure the DOS FULL

SCREEN icon using the same methods outlined in steps 6 through 16. Once you

have completed those steps, start a DOS FULL SCREEN session and run the

SCANTEST utility from the \WlNDOWS\TWAIN directory. If SCANTEST runs

successfully, chances are that the Windows session will run properly.

SCSI Interface

In order for either of the Epson TWAIN drivers to function in a Windows session

under OS/2, you must install support for your ASPI compliant SCSI card under

OS/2 first. For installation instructions, refer to your OS/2 manual.

Once you have installed support for your ASPI compliant card under OS/2, you

need to manually check the CONFIG.SYS file for four key files. You should have

the following lines in the OS/2 CONFIG.SYS. If these lines do not exist, add them.

The AHAxxxx.ADD should have been inserted when you installed the SCSI support

for OS/2.

PSB No: P-0103A

Page: 3 of 4

BASEDEV=OS2ASPI.DMD

BASEDEV=OS2SCSLDMD

BASEDEV=AHAxxxx.ADD /V

DEVlCE=C:\OS2\MDOS\SPlSYS

NOTE:

This document assumes that you are using an Adaptec card. The AHA1510 and

AHA1540C were tested when creating this document.

Once you have verified that the above lines are in the CONFIG.SYS, shut down

OS/2 and reboot.

NOTE:

If the SCSI card does not find any devices on the SCSI chain, the AHAxxxx.ADD

driver will not load thus causing VASPI.SYS not to load. If this occurs, double

check your card’s configuration and the SCSI cabling.

Epson TWAIN

~1.0~

Follow the steps below to enable Epson TWAIN

~1.0~:

10.

11.

12.

13.

14.

From the OS/2 desktop, double click on the OS/2 SYSTEM folder

Double click on the COMMAND PROMPTS folder

Double click on the Win-OS/2 icon.

Once Windows is loaded, follow the TWAIN installation procedure. When the

installation program asks if you wish to make changes to the CONFIG.SYS or

the CONFlG.ADD, select CONFIG.ADD.

Once the installation has completed, exit Windows.

If the COMMAND PROMPTS folder is not open, follow steps 1 and 2.

Move the mouse to the WIN-OS/:! FULL SCREEN icon. Click on the right

mouse button.

Select SETTINGS from the pop-up menu.

Once the SETTINGS notebook has opened, click on SESSION.

Click on the WIN-OS2 SETTINGS.

Click on OTHER DOS SETTINGS.

Click on OK.

Highlight DOS-DEVICE.

In the window to the right, add the EPSN.SYS driver. X represents the

appropriate SCSI ID of the scanner.

The device line would be entered in the following manner.

C:\EPSN.SYS 3 /Sx /i79

PSB No: P-0103A

Page: 4 of 4

15. Click on SAVE.

16. Close the SETTINGS notebook.

The next time a Win-OS/2 session is started, you will see the EPSON device driver

load. If you do not, repeat the above steps. If you have migrated a Windows

application to the OS/2 desktop, apply the above steps to that icon instead of the

Win-OS/2 icon. To verify that the configuration is correct, configure the DOS FULL

SCREEN icon using the same methods outlined in steps 6 through 16. Once you

have completed those steps, start a DOS FULL SCREEN session and run the

SCANTEST utility from the \WlNDOWS\TWAIN directory. If SCANTEST runs

successfully, chances are that the Windows session will run properly.

Epson TWAIN v2.xx

There is no special procedure required to setup this version of the driver to run in a

Windows session under OS/2 Warp. Simply launch Windows and install the driver.

Follow the procedures outlined in the user’s manual. If the driver does not install

properly, verify that the device drivers mentioned earlier in this section are being

executed.

EPSON AMERICA, INC.

EPSON

Product Support Bulletin

Subject: Image Editing Terms

Date: 6/5/91

Page(s): 1 of 3

PSB No: P-0078

Originator: RS

The following terms’ are used to describe image editing and grayscale in

connection with scanners, monitors and printers.

Additive

Primary Colors:

Aliasing:

Antialiasing :

Brightness:

Continuous

Tone:

Contrast:

Cropping:

Dithering:

DPI:

The colors produced by mixing colored light. The primary

additive colors are red, green and blue. The absence of color

produces black (0%); maximum intensity produces white (100%).

This principle is used in color monitors (RGB). By using 24 bits

per pixel it is possible to represent more than 16 million colors.

The jagged diagonal lines that appear in low resolution mode.

Usually noticeable on characters like

‘A”

and

VV’!

The removal of the aliasing or step-like diagonal lines.

The balance of light and dark shades.

The transition from light to dark or dark to light in a smooth

uninterrupted progression. Laser and dot matrix printers do not

support continuous tones.

The range between the darkest and lightest shades of an image.

As contrast increases, the number of gray shades between black

and white decreases.

An operation that allows portions of an image to be selected.

Usually pertains to scanning technology.

A method of shading that uses black dots of varying density to

represent darker areas. This technology is used in devices that

only support black and white outputs.

Abbreviation for dot per inch. The standard measurement of

resolution for all output devices. DPI describes the number of

pixels in an image.

‘Some terms taken from PC Publishing, Jan. 1990.

PSB No: P-0078

Page: 2 of 3

Gamma

Function:

The function that defines the light intensity ratio between the

original image and the output data. The ES-300C scanner allows

the function to be altered so that when the image is reproduced

on a different type of output device, the tones in the reproduced

images will be closer to the original image.

Grayscale:

A term used to describe the output of devices that support more

than just black and white. Grayscales support up to 258 shades

of gray. The table below details the number of data bits required

to show the number of possible gray levels.

Number of

Bits

Possible Gray Levels

(black and white)

grays

416

grays

128

grays

8 256 grays

Halftone:

The output in 1 or 2 bit data format that simulates grayscale by

creating a pattern of small dots that vary in size and density.

Halftones are used in newspapers to display photographs. The

Epson ES-300C supports 3 types of halftoning.

Highlight:

The brightest value in a continuous tone or halftone image.

Line Art:

Images consisting of only black and white pixels. Text is a good

example of line art.

tine Screen: Also known as screen ruling, it is the distance between the

centers of halftone dots. For example, a newspaper uses a

typical line screen - sixty five halftone dots per inch at a forty five

degree angle for photographs.

Matrix:

The square grid that forms the halftone dots. As the matrix size

increases, more possible variations on dot size and shape are

available.

PSB No: P-0078

Page: 3 of 3

Midtones:

Pixel:

The values in a continuous tone or halftone image correspond to

the medium values in the range. Generally the values is between

30% to 70%.

A relative unit of measuring resolution. Pixel size is relative, due

to the output device. For example, a monitor pixel may be

different in size compared to a scanner pixel. Pixels can be

measured absolutely when fixed to another standard, like pixels

per inch.

Posterize:

To limit the number of shades in an image to create a highly

contrasted effect.

Screen Angle:

The angle at which halftone dots are lined up. As mentioned

earlier, newspapers commonly use a screen angle of forty five

degrees.

Smoothing:

An operation that softens the edges between adjacent tones.

Spot Function:

A procedural body in the Postscript language that defines the

shape of the halftone spot.

Subtractive

Colors that are produced by mixing inks or paints. The three

Primary Colors:

subtractive colors are cyan, magenta, and yellow. This process

reduces the amount of light that the human eye receives. The

absence of color is white (0%), while full intensity is black (100%).

This model is used in printing.

Threshold:

The selected gray level above which gray shades are converted

to white and below which gray shades are converted to black.

This is used to produce higher contrast or posterize images.

Other manuals for ES-800C

Table of contents

Other Epson Scanner manuals

Epson

Epson 1250 - Perfection Photo Flatbed Scanner Reference guide

Epson

Epson DS-530 Instruction Manual

Epson

Epson DS-560 User manual

Epson

Epson Expression 12000XL User manual

Epson

Epson Perfection V37 Instruction Manual

Epson

Epson Perfection 1200s User manual

Epson

Epson SeriesPerfection 1240U Series User guide

Epson

Epson DS-1630 User manual

Epson

Epson Perfection 600 User manual

Epson

Epson ES-800C User manual

Epson

Epson DS-80W User manual

Epson

Epson Expression 11000XL - Graphic Arts User manual

Epson

Epson 3170 - Perfection Photo User manual

Epson

Epson Prefection 2450 User guide

Epson

Epson Perfection V550 Photo Operating instructions

Epson

Epson Perfection V350 Series User manual

Epson

Epson ES-1000C - Business Scanning System User manual

Epson

Epson Perfection V700 Series User manual

Epson

Epson Expression 636 User manual

Epson

Epson Expression 800 Dimensions

Epson

Epson Perfection V800 Photo User manual

Epson

Epson Perfection 2400 Photo User manual

Epson

Epson CaptureOne TM-S1000 Use and care manual

Epson

Epson SeriesPerfection 1240U Series Dimensions

Popular Scanner manuals by other brands

Plustek

Plustek Scanner user guide

Z/I Imaging

Z/I Imaging PhotoScan 2001 instructions

Renkforce

Renkforce DS100-5M operating instructions

Image Access

Image Access WideTEK A2 Operation manual

Canon

Canon imageFORMULA CR-120N user manual

Fujitsu

Fujitsu FI-4860C2 Specifications

GeoSlam

GeoSlam ZEB Horizon Hardware guide

Kodak

Kodak i5800 Scanner Brochure & specs

Kodak

Kodak i7300 user guide

Revopoint

Revopoint POP user manual

Fujitsu

Fujitsu fi-4860C installation guide

Eddyfi Technologies

Eddyfi Technologies Floormap X user manual

Faselase

Faselase F6 user manual

Fujitsu

Fujitsu CardMinder user guide

Uniden

Uniden BC340CRS owner's manual

Infinite Peripherals

Infinite Peripherals INFINEA TAB M user manual

Mustek

Mustek PageExpress 4800 Pro user guide

Optex

Optex 750830 owner's manual
