Epomaker TH21 User manual

QUICK S T A R T GUIDEEN

This Quick Guide is an introduction to the use and functionality of the EPOMAKER TH21.

For in-depth guide of functionality of the customization software please refer to the manual that you can

Fnd in the ofﬁcial epomaker website at https://epomaker.com/pages/software-downloads

Should you require more assistance please email us at [email protected]

20% Hot Swappable RGB 2.4Ghz/Bluetooth 5.0/

Wired Numpad

RoHS

COMPLIANT

CreatedbyHeipi

fromtheNoun Project

Created by Loren Klein

from the Noun Project

Manufacturer: Shenzhen Changyun Technology Co., Ltd.

Address: Seventh Floor, Kai Daer Building, No.168 Tongsha Road,

Xili Street, Nanshan Disctrict, Shenzhen,Guangdong, CN

Email: support@epomaker.com

Web: www.epomaker.com

Made in China

EC REP

APEX CE SPECIALISTS LIMITED

Address: UNIT 3D NORTH POINT HOUSE, NORTH POINT

BUSINESS PARK, NEW MALLOW ROAD CORK, T23 AT2P,

IRELAND

Contact: Wells Tel: +353212066339

Email: info@apex-ce.com

TH21

E P O M A K E R

TRIPLE-MODE

Please be gentle. Be sure the pins are

aligned with the slots.

Before installing switches, be sure the pins are clean and

straight, you may damage the switch otherwise.

Push Straight Down

R E P L A CING KEY C A P S A N D S W I T C HES

For a full guide on how to remove keycaps and switches scan the QR Code or type in

your browser: https://epomaker.com/blogs/guides/diy-guide-how-to-remove-and-

replace-your-mechanical-keyboard-switches

Installing Switches

QUICK S T A R T GUIDEEN

Logo

Switch Shaft

The Switch Puller tool aligns Vertically to the

mechanical switch to unclip the plastic securing

the switch to the plate.

Example of a switch

as seen from top

after you remove the

keycap to prepare for

switch removal.

Mechanical

Switch

Switch Puller

Keycap Puller

Included

Tools

Using the Switch Puller

QUICK S T A R T GUIDEEN

FN + 1

FN + 2

PAIRING BLUETOOTH

PAIRING WIRELESS 2.4GHz

BASIC FUNCTION

1. Hold Fn+1/2/3 for 3-5 seconds till the indicators flashes fast, the numpad is ready to pair.

1. Hold Fn+4 for for 3-5 seconds till the light flashes fast, the keyboard is ready to pair.

Toggle the switch to the wired mode, press Fn+5 till the T key lights up, and the keyboard enters

to the wired mode successfully.

The Tab light is the battery indicator. When the numpad is at low battery, it flashes red; when the

numpad is charging, the Tab key remains red light; when the numpad is fully charged, the indicator

light is off.

2. Insert the 2.4G dongle to your device, the 4 key stops flashing green and the connection is done.

2. Turn on your Bluetooth device and find“TH21 BT5.0” or “TH21 BT3.0”, then connect. When the

keyboard is connected to the Bluetooth device, the light on the 1/2/3 key stops flashing and the

connection is done.

3. Press Fn+1/2/3 to toggle between the Bluetooth devices 1/2/3.

Short Press to Switch to BT1;

Long Press to Pair Devices

Short Press to Switch to BT2;

Long Press to Pair Devices

FN + 3

Short Press to Switch to BT3

Long Press to Pair Devices

FN + 4

Short Press to Switch to 2.4G Mode;

Long Press to Pair Devices

FN + 5

Wired Mode

FN + 6

Toggle RGB Effects

FN + 7

Toggle RGB Colors

FN + 8

Calculator

FN + -

FN + +

Backlights Brightness

Backlights Brightness +

FN + .

Battery Check

FN + ÷

Backlights Speed-

FN + ×

Backlights Speed+

FN + Back

Battery Saving Mode

Fn+ Enter

(Long press 3s in

wireless mode)

Turn on/off Numpad

Fn+ Esc

(Long press 3s)

Reset the numpad

TECHNICAL ASSISTANCE

TIPS ON CHARGING

WIRED MODE

For technical assistance, please email to support@epomaker.com with your purchase order number

and a detailed description of your issue.

We normally respond to enquiries within 24 hours. If you purchased your keyboard from a distributor or

not from any ofﬁcial store of Epomaker, please contact them directly for any additional help.

tiktok.com/@epomakerkeyboard

WARRANTY

EPOMAKER’s Warranty covers any factory defects that might affect the proper functionality of your

purchase. It doesn’t cover any damage that may occur from normal wear and tear. If your product is

defective we will send you a replacement unit. Replacement units might require you to send the defective

unit back to Epomaker.

We provide a 1 year warranty for our products when bought from our website (EPOMAKER.com). Your

item will not be covered by your 1 year warranty if the inspection shows any sign of modiﬁcation or

changes unsupported by the original product, these include: Changing internal components, Assembling

and reassembling the product, Replacing Batteries, etc.

We will ONLY cover the item if it is bought from our ofﬁcial stores. You do not have awarranty with us

if you bought the item from another reseller or likewise. Please contact the store that you bought your

product from to resolve issues.

EPOMAKER COMMUNITY

discord.gg/2q3Z7C2

Join our community and learn together with other keyboard enthusiasts.

reddit.com/r/epomaker

P R ODUCTSPECIFIC A TION S EN

KEYS AMOUNT 21 Keys

STABILIZER TYPE Plate-mounted

PCB TYPE 3/5-pin Hotswap PCB

MODEL EPOMAKER TH21

CONNECTIVITY Type-C Wired, 2.4 & Bluetooth Wireless

DIMENSION 88 x 133.5 x 51 mm

BATTERY CAPACITY 1500mAh

WEIGHT Around 0.3kg

Windows/Mac/Linux/Android/iOSCOMPATIBILITY
