Elo TouchSystems 1524L User manual

Touchmonitor User Guide

For 15" LCD Desktop Touchmonitors and Non-Touchmonitors

1524L Series

Revision B

Auto Enter - + Menu/Exit

2004 Printed in USA

P/N 008549

User Guide

15"LCD Desktop Touchmonitor

1524L Series

RevisionB

P/N 008549

iii

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means, including, but not

limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written

permission of Elo TouchSystems.

Disclaimer

The information in this document is subject to change without notice. Elo TouchSystems makes no

representations or warranties with respect to the contents hereof, and specifically disclaims any

implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves

the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Elo TouchSystems to notify any person of such revisions or changes.

Trademark Acknowledgments

IntelliTouch, SecureTouch, AccuTouch, Entuitive, and MonitorMouse are trademarks of Elo

TouchSystems, Inc.

Other product names mentioned herein may be trademarks or registered trademarks of their

respective companies. Elo TouchSystems claims no interest in trademarks other than its own.

Chapter 1

Introduction 7

ProductDescription.. . . .. . . .. . . . .. . 7

Precautions . . . . . . . . . . . . . . . . . . . . 7

About the Product . . . . . . . . . . . . . . . . . 8

Chapter 2

Installation and Setup 9

Unpacking Your Touchmonitor. . . . . . . . . . . 9

Product Overview . . . . . . . . . . . . . . . . 10

Main Unit . . . . . . . . . . . . . . . . . . . 10

RearView. . . .. . . .. . . .. . . . .. 10

Touch Interface Connection . . . . . . . . . . . 11

Installing the Driver Software . . . . . . . . . . 12

InstallingtheSerial TouchDriver. . ... . .13

Installing the Serial Touch Driver for Windows

XP,Windows 2000, Me,95/98 and NT 4.013

Installing the Serial TouchDriver forMS-DOS

and Windows 3.1 . . . . . . . . . . . . . 14

RegulatoryInformation33

Warranty37

Index 39

Table of Contents

Installing the USB Touch Driver for Windows

XP, Windows 2000, Me, 95/98 and NT 4.0 15

Chapter 3

Operation17

About Touchmonitor Adjustments . . .... . .17

Front Panel Controls.... . ... . . ... 18

Controlsand Adjustment ... . ... . . ... 19

OSDMenuFunctions. .. . . .. . . . .. 19

OSDControlOptions.. .. . . .. . . . .. 20

PresetModes ... . ... . ... . . ... 21

PowerManagementSystem .... . . ... 22

DisplayAngle.. . .. . . .. . . .. . . . .. 22

Chapter 4

Troubleshooting 23

Solutionsto CommonProblems.. .. . . . .. 23

Appendix A

Appendix B

Care and Handling of Your Touchmonitor .... 28

Appendix C

TouchmonitorSpecifications.. . . .. . . . .. 30

AccuTouch Touchscreen Specifications.. .31

15" LCD Touchmonitor (ET1524L-XXWC-1)

Dimensions. . . .. . . .. . . .. . . . .. 32

InstallingtheUSB TouchDriverr. . . . . . . 15

January 9, 2002 9:17 am (D:\Vera new\8549 15 in Econ AT User Guide\15 in Economy AT\15

in Econ ATTOC.fm)

1-7

CHAPTER

HAPTER

NTRODUCTION

Product Description

Your new touchmonitor combines the reliable performance of touch technology

with the latest advances in LCD display design. This combination of features

creates a natural flow of information between a user and your touchmonitor.

This LCD monitor incorporates 15” color active matrix thin-film-transistor

(TFT) liquid crystal display to provide superior display performance. A

maximum resolution of XGA 1024x768 is ideal for displaying graphics and

images. Other outstanding designs that enhance this LCD monitor’s

performance are Plug & Play compatibility, and OSD (On Screen Display)

controls.

OTE

Some monitors do not have the touchscreen capability.

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s manual to maximize the life of your unit. See Appendix B for more

information on touchmonitor safety.

1-8 User Guide

About the Product

Your LCD Desktop Touchmonitor is a 15” XGA TFT color display with the

following features:

• The internal microprocessor digitally controls auto-scanning. For horizontal

scan frequencies between 31.5 KHz and 60.2 KHz, and vertical scan

frequencies between 56.3 Hz and 75.0 Hz. In each frequency mode, the

microprocessor-based circuitry allows the monitor to function at the

precision-of a fixed frequency.

• High contrast color TFT LCD display support resolution up to XGA

1024x768. Compatible with VGA, SVGA, XGA (non-interlaced) and most

Macintosh compatible color video cards.

• Power management system conforms to VESA DPMS standard.

• Supports DDC1/2B for Plug & Play compatibility.

• Advanced OSD control for picture quality adjustment.

• Detachable stand for wall-mounting application.

• Optional touch screen function.

For full Product Specifications refer to Appendix C.

2-9

CHAPTER

HAPTER

NSTALLATION

AND

ETUP

This chapter discusses how to install your LCD touchmonitor and how to install

the driver software.

Unpacking Your Touchmonitor

Check that the following 7 items are present and in good condition:

Power cable US/Canada

VGA cable

European power cable

Serial cable

CD and Quick Install

Guide

LCD monitor

USB Cable

2-10 User Guide

Product Overview

Main Unit

Rear View
