Elo TouchSystems ET1509L User manual

Monitor Touch Screen

Elo Touch ET1509L

O ET1509L é o monitor touch screen de 15 polegadas da

Elo Touch Solutions com melhor custo benefício. A tela

widescreen de LCD é em vidro puro e transparente que

oferece uma qualidade de imagem superior.

www.bztech.com.br

User Manual

Elo TouchSystems 1509L Touchmonitor

User Manual – 1509L

SW601532 Rev A - Page 1 of 18

User Manual – 1509L

SW601532 Rev A - Page 2 of 18

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or

translated into any language or computer language, in any form or by any means, including, but not

limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission

of Tyco Electronics.

Disclaimer

The information in this document is subject to change without notice. Tyco Electronics Corporation and

its Afffiliates in the TE Touch Solutions business unit in the TE Connectivity Ltd. family of companies

(collectively "TE") makes no representations or warranties with respect to the contents herein, and

specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. TE

reserves the right to revise this publication and to make changes from time to time in the content

hereof without obligation of TE to notify any person of such revisions or changes.

Trademark Acknowledgments

Elo TouchSystems, IntelliTouch, TE Connectivity, TE connectivity (logo) and TE (logo) are trademarks

of the TE Connectivity Ltd. family of companies. Windows is a trademark of the Microsoft group of

companies. Other product names mentioned herein may be trademarks or registered trademarks of

their respective companies. Tyco Electronics claims no interest in trademarks other than its own.

User Manual – 1509L

SW601532 Rev A - Page 3 of 18

Table of Contents

Chapter 1 - Introduction ........................................................................... 4

Chapter 2 – Installation............................................................................. 5

Chapter 3 – Mounting................................................................................ 8

Chapter 4 – Operation............................................................................... 9

Chapter 5 – Technical Support............................................................... 13

Chapter 6 – Safety & Maintenance........................................................ 14

Chapter 7 – Regulatory Information..................................................... 15

Chapter 8 – Warranty Information......................................................... 18

User Manual – 1509L

SW601532 Rev A - Page 4 of 18

Chapter 1 - Introduction

Product Description

Your new touchmonitor combines the reliable performance of Elo TouchSystems touch products

with the latest developments in touch technology and display design. This combination of

features creates a natural flow of information between a user and the touchmonitor.

This widescreen touchmonitor incorporates a 24-bit color, active matrix thin-film-transistor LCD

panel to provide high quality display performance. Its LED backlight significantly reduces power

consumption and eliminates mercury (compared to CCFL-backlit panels). Other features that

enhance this LCD monitor’s performance are Plug & Play compatibility, on-screen display

(OSD) controls, and an optional magnetic strip reader (MSR).

Precautions

Follow all warnings, precautions and maintenance as recommended in this user manual to

maximize the life of your unit and prevent risks to user safety. See the Safety & Maintenance

chapter for more information.

This manual contains information that is important for the proper setup and maintenance of the

unit. Before setting up and powering on your new touchmonitor, read through this manual,

especially the Installation, Mounting, and Operation chapters.

Chapter 2 –Installation

Unpacking the Touchmonitor

Open the carton and verify that the following items are present:

Touchmonitor with protective sheet for its face

Elo TouchTools CD & User Manuals CD

Japanese language regulatory information pamphlet

Quick Install Guide

VGA cable

USB cable

AC-DC power adaptor

Connector Panel & Interfaces

Touchmonitor Connections

1. Connect the VGA video cables between the monitor’s VGAinput connectors and your VGA

video source, respectively. Tighten the video cable’s screws for best performance.

2. Connect the USB touch cable between the monitor’s USB connector and your PC’s USB

port.

3. Connect the power adaptor’s input connector to the AC power source. Connect the power

adaptor’s DC output connector to the monitor’s input power jack.

4. The touchmonitor ships in an OFF state. Press the power button to turn it on.

Installing the Touch Technology Software Drivers

Some software installation is required for your touchmonitor to work with your computer.

The drivers for the Windows 7, XP, Vista, WePOS, and 32-bit Server 2003 and 2008 operating

systems are provided with your touchmonitor on a CD.

User Manual – 1509L

SW601532 Rev A - Page 5 of 18

Visit www.elotouch.com for:

The most up-to-date touch driver versions

Additional touch driver information

Detailed touch driver installation guides

Touch drivers for other operating systems

Insert the Elo TouchTools CD into your computer’s CD-ROM drive. The CD should

automatically run the Elo TouchTools application. Select “Install Driver for This computer”:

User Manual – 1509L

SW601532 Rev A - Page 6 of 18

For Windows XP, Vista, Server 2003, Server 2008, and WEPOS installations, install the “USB

Touchscreen Drivers” when prompted:

For Windows 7 installations, check the “Install driver” box under “Elo USB Interfaces – Other

Touchscreens”

After accepting the end-user license agreement, the drivers will finish installing.

Reboot your computer after the install is complete.

User Manual – 1509L

SW601532 Rev A - Page 7 of 18

Chapter 3 – Mounting

General Mounting Information

The OSD text can be rotated through the OSD menu to better suit your mounting orientation.

The holes located on the sides and top of the touchmonitor case are for ventilation. Do not

block, cover, or insert anything inside the ventilation slots.

Rear VESA Mount

A four-hole 75x75mm mounting pattern for M4 screws is provided on the rear of the monitor.

Remove the stand using a Phillips screwdriver to access this mounting interface. The VESA

FDMI-compliant counting is coded: VESA MIS-B, 75, C

User Manual – 1509L

SW601532 Rev A - Page 8 of 18

User Manual – 1509L

SW601532 Rev A - Page 9 of 18

Chapter 4 – Operation

Power

To turn the touchmonitor on or off, press the touchmonitor power button once.

The Power Status LED on the bottom of the touchmonitor functions according to the following

table: TouchMonitor/Computer Module status LED status

OFF OFF

SLEEP PULSING

ON ON

The system consumes low power when in SLEEP and OFF modes. For detailed power

consumption specifications, refer to technical specifications on the Elo website

http://www.elotouch.com

Touching the screen will bring the attached host PC out of SLEEP mode (similar to moving the

mouse or pressing a keyboard key).

To improve reliability and reduce wasteful power consumption, disconnect the power adapter

when long periods of disuse are planned.

Touch

Your IntelliTouch touchmonitor is factory-calibrated and should not need manual calibration

(unless the input video is not fully scaled to the native resolution, or the touch experience needs

to be calibrated to a specific user).

Video

A display’s native resolution is its width and height measured in number of pixels. Generally, for

best performance, an image displayed on this monitor will look best when your computer’s

output resolution matches this monitor’s native resolution of 1366 x 768.

For computer output resolutions at non-native resolutions, the monitor will scale the video to its

panel’s native resolution. This involves stretching or compressing the input image as needed in

the X- and Y-dimensions to fit the display’s native resolution. An unavoidable byproduct of the

scaling algorithms is a loss of fidelity when the computer’s output video image is scaled by the

monitor to fit the display. This loss of fidelity is most apparent when viewing feature-rich images

at close distances (for example images containing small-font text).

Your touchmonitor will likely not require video adjustments. However, for analog VGA video,

variations in video graphic card outputs may require user adjustments through the OSD to

optimize the quality of the touchmonitor’s displayed image. These adjustments are

“remembered” by the touchmonitor. Also, to reduce the need for adjustments for different video

mode timings, the monitor correctly scales and displays some of the video industry’s most
