Electrolux W565H User manual

PROFESSIONAL LAUNDRY

W565H

7/15

520

1245

450

5.4 / 7.5

2.0 / 3.0

46 43 46 43

43+11 20+6 54+0 26+0

0.15/0.3/0.7 0.15/0.15/0.3 0.15/- 0.15/-

- - 1.5 0.75

48 49 48 49

Washer extractor

W565H

Main speciﬁcations

Max. capacity ﬁlling factor 1:9 kg/lb

Drum, volume litre

diameter ø mm

Extraction rpm

G-factor

Standard heating alternatives electricity kW

Low energy heating alternatives electricity kW

steam

non-heated

Consumption data ”Normal 60°C”

Economy*

Total time min

Water consumption (cold+hot) litre

Energy consumption (motor/heating/hot water) kWh

Steam consumption kg

Residual moisture %

* Water temperature 15°C cold water and 65°C hot water.

** Programs with AS.

*** Depending on steam pressure.

Images shown are a representation of the product only

and variations may occur.

Main options

• Automatic liquid detergent supply (optional I/O board)

• Stainless steel front panel

• Connection to booking- /payment- system or coin meter

• Drain pump

Full load, 7 kg Half load**, 3.5 kg Full load, 7 kg Half load**, 3.5 kg

Features and beneﬁts

• Compass Pro® microprocessor offers:

– Large display and one control knob for easy program selection

– Language selection

– Quick selection and option buttons for the most frequently used wash

programs and options

– Wash program packages optimized on Economy, Perfomance and Time.

(Available on general programs)

• AS – Automatic Savings:

– The machine weighs the linen and adjusts the amount of water and energy

according to the load. This leads to considerable savings in case the machine

is not fully loaded. (Available on general programs)

• Extremely low water and energy consumption – see table below

• Four compartment detergent box for manual dosing of powder or liquid

detergent

• High extraction force for efﬁcient dewatering

• Door with gasket and strong hinges built for heavy duty operation

• Stainless and galvanized steel in all vital parts for high degree of rust protection

• Power Balance:

– Maximises the extraction force, leading to highest dewatering and savings in

drying

– Minimizes the stress on the machine, leading to trouble-free operation and

increased machine lifetime

– Reduces vibrations, making it possible to install the machine in all locations

El Steam***

Certiﬁed in accordance with ISO 9001 and ISO 14001 and approved IP 24D.

W565H

200-600

50/75

170

300-600

20.8

1.8 ± 0.5

145

0.82

720

1130

1132

408

721

831

1030

224

124

1010

910

278

239

Share more of our thinking at www.electrolux.com

220-240V 1 ~ 50/60 5.4/7.5 5.5/7.6 25/35

220-240V 1 ~ 50/60 2.0/3.0 2.1/3.1 10/16

220-240V 3 ~ 50/60 5.4/7.5 5.5/7.6 16/20

220-240V 3 ~ 50/60 3.0/4.3 3.1/4.5 10/16

380-415V 3N ~ 50/60 5.4/7.5 5.5/7.6 10/16

380-415V 3N ~ 50/60 3.0/4.3 3.1/4.5 10

440V 3 ~ 60 7.5 7.6 16

480V 3 ~ 60 7.5 7.6 10

220-480V 1/3 ~ 50/60 - 1.0 10

Water and steam connection

Water valves DN

Water pressure kPa

Capacity at 300 kPa l/min

Drain valve ø mm

Draining capacity l/min

Steam valve DN

Steam pressure kPa

Liquid detergent supplies

Floor requirements

Frequency of the dynamic force Hz

Floor load at max extraction kN

Sound levels

Sound power level (IEC 60704-2-4)

wash dB(A)

extraction dB(A)

Heat emission

% of installed power, max

Shipping data**

Weight net, kg

Shipping volume m3

Accessories

Steel base

Hose kits for water or steam

Fluff collector

Dimensions in mm

A Width

B Depth

C Height

1 Operating panel

2 Door opening ø 310 mm

3 Detergent box

4 Cold water

5 Hot water

6 Re-used water

7 Drain

8 Liquid detergent supply

9 Electrical connection

10 Steam connection

11 Third water valve

Front and side panels in light grey and blue (RAL 260 70 05, 250 60 30)

* Other voltages available, see installation manual.

** Average data. Crated weight/shipping volume depends on conﬁguration.

Please contact logistics for exact measures.

Side view

Rear

Front

Art. No. 438919494EN/2013.09.03

We reserve the right to alter speciﬁcations without notice.

www.electrolux.com/laundrysystems

Electrical connections*

Heating Main voltage Heating Total Recommended

alternative power power fuse

Hz kW kW A

Electric heated

Steam or

Non heated
