Electrolux EWB 105405 W User manual

user manual

notice d'utilisation

Washing Machine

Lave-linge

EWB 105405 W

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

CONTENTS

Safety Information 2

Product description 3

Personalisation 4

How to run a wash cycle? 4

Daily use 5

Washing programmes 7

Care and cleaning 8

Operating Problems 8

Detergents and Additives 10

Technical Specifications 10

Installation 10

Environment concerns 12

Subject to change without notice

SAFETY INFORMATION

Please read these points carefully before in-

stalling and using your appliance. Keep this

user manual with your appliance.

General safety

• Do not modify or attempt to modify this

appliance. This would put yourself in dan-

ger.

• Ensure that all coins, safety pins, brooch-

es, screws etc have been removed be-

fore starting a washing programme. If left

in washing, they can seriously damage

the appliance.

• Use the recommended quantity of deter-

gent.

• Put small items together (socks, belts

etc.) in a small linen bag or pillow case.

• Unplug and close inlet hose tap after us-

ing appliance.

• Always disconnect the power supply

from the appliance before cleaning or

maintenance.

•Donotmachinewashclothes with rib-

bing, unfinished or torn material.

Installation

• Unpack or ask for the appliance to be

unpacked immediately upon delivery.

Check the outside of the appliance is not

damaged in any way. Report all transit

damage to your retailer.

• Remove all transit bolts and packaging

before installing the appliance.

• Connection to the water supply must be

carried out by a qualified plumber.

• If your domestic electrical circuit needs

adapting to allow the appliance to be

plugged in, use a qualified electrician.

• Ensure that, after installation, the power

cable is not trapped under the appliance.

• If the appliance is installed on carpeted

floor, ensure that the carpet does not ob-

struct any ventilation ducts located at the

base of the appliance.

• The appliance must be equipped with an

earthed power plug which conforms to

regulations.

• Before connecting your appliance to the

power supply, carefully read the instruc-

tions in the chapter entitled “Electrical

connection”.

• Replacing the power cable should only

be carried out by an authorised service

engineer.

• The manufacturer cannot be held re-

sponsible for any damage resulting from

incorrect installation.

Precautions to be taken against frost

If your appliance is exposed to tempera-

tures below 0°C, the following precautions

must be taken:

• Close the tap and disconnect the inlet

hose.

• Place the end of this hose and the drain

hose in a basin on the floor.

• Select the Drain programme let it run until

the end of the cycle.

• Disconnect the appliance from the power

supply by turning the programme selec-

tor to “Stop” .

• Unplug the appliance.

• Replace the inlet hose and drain hose.

This way, the water remaining in the hoses

will be drained away, avoiding any ice for-

mation which would damage your appli-

ance.

2 electrolux

Before turning your appliance on again, en-

sure that it is installed in an area where the

temperature will not fall below freezing.

Use

• Your appliance is intended for normal do-

mestic use. Do not use the appliance for

commercial or industrial purposes or for

any other purpose.

• Refer to the instructions on the label of

each item before washing.

• Do not put items into the washing ma-

chine which have had stains removed

with petrol, alcohol, trichlorethylen etc. If

such stain removers have been used,

wait until the product has evaporated be-

fore putting these items into the drum.

• Empty pockets and unfold items.

• This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge, un-

less they have been given supervision or

instruction concerning use of the appli-

ance by a person responsible for their

safety.

Children should be supervised to ensure

that they do not play with the appliance.

PRODUCT DESCRIPTION

1. The control panel

2. Lid handle

3. Adjustable levelling feet

Control panel

1 2 3 4 5 6

electrolux 3

1. Programme selector

2. Pushbuttons and their functions

3. Display

4. "Add washing" light

5. "Start/Pause" pushbutton

6. "Time manager" pushbuttons

The symbols

12 34 5

1. Time manager

2. Temperature

3. Child safety

4. Cycle running : Prewash/Wash,

Rinse, Drain, Spin

5. Length of cycle or Timer delay count-

down

Dispenser box

Prewash

Wash

Softener (do not fill above the MAX symbol

)

PERSONALISATION

Child safety

This option provides two types of locking :

• if the option is activated after the cycle

has started, no changes to the options or

programme is possible.

The cycle runs and you must deactivate

the option to run a new cycle.

• if the option is activated before the cycle

has started, the appliance cannot be

started.

To activate child safety, turn appliance on

and press “Extra rinse” and “Delay start”

simultaneously until the confirmation

symbol shows on in the display. The ap-

pliance memorises the selection of this op-

tion. To deactivate child safety, repeat the

process.

Audible signal

When the audible signal is activated, it

sounds when a button is pressed, at the

end of the programme, to indicate a fault.

To deactivate, turn appliance on and press

“Prewash” and “Extra rinse” simulta-

neously until the beep sounds. The signal is

only active if alarm sounds. To reactivate it,

repeat the same process.

HOW TO RUN A WASH CYCLE?

Using for the first time

• Ensure the electrical and water con-

nections comply with the installation

instructions.

• Remove the polystyrene insert and

all other items inside the drum.

• Run an initial wash cycle at 90°C,

without any washing but with deter-

gent to clean the water tank.

4 electrolux

DAILY USE

Loading washing

• Open the lid of

the appliance.

• Open the drum

by depressing

the locking but-

ton A: The two

shutters unlock

automatically.

•Loadthewash-

ing, close the

drum and the lid of your washing ma-

chine.

Warning! Before closing the lid of your

appliance, ensure that the drum is

properly closed :

• When the two shutters are closed,

• locking button A released.

Proportioning of detergents

Pour the amount of washing powder into

the washing and prewash compart-

ments if you have selected the “prewash”

option. Pour fabric softener into the com-

partment if necessary.

Selection of desired programme

Turn the programme selector to the re-

quired programme. The “Start/Pause”

pushbutton flashes green.

If you turn the programme selector to an-

other programme while a cycle is in pro-

gress, the appliance will ignore the new se-

lected programme. “Err” flashes and the

“Start/Pause” pushbutton flashes red for

a few seconds.

Selecting the temperature

Press the “Temperature” pushbutton re-

peatedly to increase or decrease the tem-

perature (see “Programmes table”). The

symbol means a cold wash.

Selecting the spin speed

Press the spin button to change the spin

speed. You can also select “Rinse hold”

or “Night cycle” .

For the maximum spin speeds see "Wash-

ing programmes".

At the end of the programme, if you have

selected “Rinse hold” or “Night cycle”

, you then need to select a “Spin” or

“Drain” programme to finish the cycle

and empty the water.

Night cycle : the cycle contains no spin

and ends with a rinse hold.

Selecting options

You must select the different options after

selecting the programme and before press-

ing the “Start/Pause” pushbutton (see

“Programme table”). Press the desired but-

ton(s) ; the corresponding lights come on. If

pressed again, the lights go out. If one of

the options is not compatible with the se-

lected programme, “Err” flashes on the dis-

play and the “Start/Pause” pushbutton

flashes red.

“Prewash” option

The appliance runs a prewash at 30°C

max.

“Extra rinse” option

The washing machine will add one or more

rinses during the cycle. This option is rec-

ommended for people with sensitive skin

and in soft water areas.

Temporary : Press the “Extra rinse”

pushbutton. The option is only active for the

selected programme.

Permanent : Hold down the “Prewash”

and “Delay Start” pushbuttons for a few

seconds. The option is permanently activa-

ted, even if the appliance is switched off. To

deactivate it, repeat the process.

“Delay start”

This option allows you to delay the start of a

wash programme by 30, 60, 90, 2 hours to

20 hours. The selected time appears on the

display for a few seconds.

You can change or cancel the delayed start

time at any time before you press the

“Start/Pause” pushbutton, by pressing

the “Delay start” pushbutton again (0’

indicates immediate start).

If you have already pressed the “Start/

Pause” pushbutton and you want to

change or cancel the delayed start, pro-

ceed as follows :

electrolux 5

• To cancel the delayed start and start the

cycle immediately, press “Start/Pause”

and then “Delay start” . Press

“Start/Pause” to start the cycle.

• To change the timer delay period, you

must go through the “Stop” position

and reprogramme your cycle.

The lid will be locked during the delayed

start time. If you need to open it, you must

first pause the appliance by pressing the

“Start/Pause” pushbutton. After closing

the lid again, press the “Start/Pause”

pushbutton.

Time Manager

The cycle can be made longer or shorter by

using the “Time Manager” pushbuttons.

The level of soiling of the laundry is also in-

dicated.

Soil level Icon Type of fabric

Intensive For heavy soiled

items

Normal For normal soiled

items

Daily For daily soiled items

Light For slightly soiled

items

Quick

For very slightly

soiled items

Super quick

For items used or

worn for a short time

Refresh

For refreshing items

only

Super re-

fresh

For refreshing a very

few items only

1) To use on a half load.

2) The symbol flashes and disappears : this wash cycle

is a refresh cycle only.

The availability of these different levels var-

ies depending on the selected programme

type.

Start of the programme

Press the “Start/Pause” pushbutton to

start the cycle ; the corresponding light will

come on green. It is normal for the pro-

gramme selector to remain stationary dur-

ing the cycle. The symbol for the current

cycle and the remaining time appear on the

display. If a delayed start has been selec-

ted, the countdown appears on the display.

Warming up

During the cycle, the symbol comes on

when the appliance is reaching the right

temperature.

Interrupting a programme

Adding washing

When the “Add washing” light is on, you

can add washing by proceeding as follows.

Press the “Start/Pause” pushbutton :

the corresponding light will flash green while

the appliance is paused. The lid can only be

opened around 2 minutes after the washing

machine has come to a stop. Press the

“Start/Pause” pushbutton again to con-

tinue the programme.

Modifying the programme in progress

Before making any changes to the current

programme, you need to pause the wash-

ing machine by pressing the “Start/Pause”

pushbutton. If the modification is not

possible, “Err” flashes in the display and the

“Start/Pause” pushbutton flashes red for

a few seconds. If you still decide to change

the programme, you must cancel the cur-

rent programme (see below).

Cancelling the programme

If you want to cancel the programme, turn

the programme selector to the “Stop” posi-

tion .

End of the programme

The washing machine stops automatically ;

the “Start/Pause” pushbutton goes out

and “0” flashes on the display. The lid can

only be opened around 2 minutes after the

washing machine has come to a stop. Turn

the programme selector to the “Stop”

position. Remove washing. Unplug and

close water inlet tap.

Stand by : once the programme has finish-

ed after a few minutes the energy saving

system will be enabled. The brightness of

the display is reduced. By pressing any but-

ton the appliance will come out of the ener-

gy saving status.

6 electrolux

WASHING PROGRAMMES

Programme / Type of washing Load Available options

Cottons (cold - 90°) : White or colour,

e.g. normally soiled work clothes, bed linen,

table linen, body linen, towels.

Max. spin speed: 1000 rpm

5,5 kg Night cycle, Rinse hold, Prewash, Ex-

tra rinse, Delay start, Time manager

Synthetics (cold - 60°) : Synthetic fab-

rics, body linen, fab, coloured farics, non-iron

shirts, blouses.

Max. spin speed: 900 rpm

2,5 kg Night cycle, Rinse hold, Prewash, Ex-

tra rinse, Delay start, Time manager

Delicates (cold - 40°) : For all delicate

materials, for example curtains.

Max. spin speed: 700 rpm

2,5 kg Night cycle , Rinse hold, Prewash,

Extra rinse, Delay start, Time manager

Wool (cold - 40°) : Machine washable

wool carrying the labels “pure new wool, ma-

chine washable, does not shrink”.

Max. spin speed: 1000

1,0 kg Night cycle, Rinse hold, Delay start

Silk (cold - 30°) : Fabric machine wash-

able at 30°C.

Max. spin speed: 700 rpm

1,0 kg Night cycle, Rinse hold, Delay start

Lingerie (cold - 40°) : For very delicate

items, like lingerie.

Max. spin speed: 900 rpm

1,0 kg Night cycle, Rinse hold, Delay start

Rinse : Hand washed items can be

rinsed in this programme.

Max. spin speed: 1000 rpm

5,5 kg Night cycle, Rinse hold, Extra rinse,

Delay start

Drain : Runs an empty cycle after a Rinse

hold (or Night cycle ).

5,5 kg

Spin : A spin cycle from 700 to 1000 rpm

after a Rinse hold (or Night cycle).

5,5 kg Delay start

Eco

(40° - 90°) : White or colour, e.g.

normally soiled work clothes, bed linen, table

linen, body linen, towels.

Max. spin speed: 1000 rpm

5,5 kg Night cycle, Rinse hold, Prewash, Ex-

tra rinse, Delay start

Easy iron (cold - 60°) : For cottons and

synthetics. Reduces creasing and makes

ironing easier.

Max. spin speed: 900 rpm

1,0 kg Rinse hold, Prewash, Extra rinse, De-

lay start

Jeans (cold - 60°) : For washing denim

clothes. The Extra rinse option is activated.

Max. spin speed: 1000 rpm

3,0 kg Night cycle, Rinse hold, Prewash, De-

lay start

Anti allergy (60°) : For eliminating the

bacteria and allergens present in cottons fab-

rics. The Extra rinse option is activated.

Max. spin speed: 1000 rpm

5,5 kg Rinse hold, Prewash, Delay start

electrolux 7

Programme / Type of washing Load Available options

Hygiene (90°) : Cycle encouraging the

elimination of micro-organisms.

Max. spin speed: 1000 rpm

5,5 kg Night cycle, Rinse hold, Prewash, Ex-

tra Rinse, Delay start

1) Reference programme for test confirming to CEI 456 standard (Eco 60° programme) : 49 L / 0,94 kWh / 210 min

CARE AND CLEANING

Unplug the appliance before cleaning.

Descaling the appliance

To descale the appliance, use an appropri-

ate non-corrosive product designed for

washing machines. Read product label for

recommended amounts and how often

descaling should be carried out.

The exterior

Use warm soapy water to clean the exterior

of the appliance. Never use alcohol, sol-

vents or similar products.

Dispenser box

To clean, proceed as follows :

Object trap

Regularly clean out the object trap which is

located at the bottom of the drum :

Check if the filter being coupled

well before closing the trap to

pull up and down the central

wall.

Water inlet filters

To clean, proceed as follows :

OPERATING PROBLEMS

Numerous checks were carried out on your

appliance before it left the factory. Howev-

er, should you notice a malfunction, please

refer to the sections below before contact-

ing the after-sales service.

8 electrolux

Problems Causes

The washing machine

doesn’t start or doesn’t

fill :

• the appliance isn’t plugged in correctly, the electrical installation isn’t

working, there is a power failure,

• the lid of your appliance and the drum shutters aren’t closed firmly,

• the programme start command hasn’t been properly selected,

• the water supply has been cut off, the water inlet tap is closed,

• the water inlet filters are dirty,

• a red tab appears on the water inlet hose.

The appliance fills but

empties straight away : • the drainage U-piece is fixed too low (see installation section).

The washing machine

doesn’t rinse or doesn’t

empty :

• the drain hose is blocked or bent,

• the object trap is obstructed,

• the out of balance detector has been activated : washing is unevenly

distributed in the drum,

• the “Drain” programme or “Night Cycle” or “Rinse hold” option have

been selected,

• the height of the drainage U-piece is unsuitable.

You have found water

around the washing ma-

chine :

• too much detergent has caused foam to overflow,

• the detergent is unsuitable for machine washing,

• the drainage U-piece isn’t attached correctly,

• the water inlet hose is leaking.

Wash is unsatisfactory : • the detergent is unsuitable for machine washing,

• there is too much washing in the drum,

• the wash cycle is unsuitable,

• there isn’t enough detergent.

The appliance vibrates,

is noisy : • all packaging have not been removed from the appliance (see installa-

tion section),

• the appliance isn’t level and is unbalanced,

• the appliance is too close to the wall or furniture,

• washing is unevenly distributed in the drum, the load is too small.

• the appliance is in running in period, noise will disappear with time.

The wash cycle is much

too long : • the water inlet filters are dirty,

• the power or water supply has been cut off,

• the motor overheating detector has been activated,

• the water inlet temperature is lower than usual,

• the foam detection security system has been activated (too much de-

tergent) and the washing machine has begun draining the foam,

• the out of balance detector has been activated: an extra phase has

been added to distribute washing more evenly in the drum.

The washing machine

stops during a wash cy-

cle :

• the water or electricity supply is defective,

• a Rinse hold has been selected,

• the drum shutters are open.

The lid doesn’t open at

the end of the cycle : • the temperature inside the drum is too high,

• the lid unlocks 1 - 2 minutes after the end of the cycle.

The error code

appears in the display

and the “Start/Pause”

button flashes red

• the lid is not closed properly.

electrolux 9

Problems Causes

The error code

appears in the dis-

play

and the “Start/

Pause” button flashes

red

• the object trap is obstructed,

• the drain hose is blocked or bent,

• the drain hose is fixed to high (see "Installation" section),

• the drainage pump is blocked,

• the standpipes blocked.

The error code ap-

pears in the display

and the “Start/Pause”

button flashes red

• the water tap is closed,

• the water supply has been cut off.

The error code

appears in the display

and the “Start/Pause”

button flashes red

• the drainage filter is obstructed,

• the anti-flooding security system has been activated, please proceed

as follows :

- close the water inlet tap,

- empty the appliance for 2 minutes before unplugging,

- call the after-sales service.

The drainage pump runs

constantly, even when

the appliance is inac-

tive :

• the anti-flooding security system has been activated, please proceed

as follows :

- close the water inlet tap,

- empty the appliance for 2 minutes before unplugging,

- call the after-sales service.

Softener runs directly in-

to the drum when filling

the dispenser box:

• you have gone past the MAX indicator.

1) On some models, the audible signals can sound

2) After solving any problems, press "Start/Pause" button to restart the interrupted programme.

DETERGENTS AND ADDITIVES

Only use detergents and additives designed

for use in a washing machine. We do not

recommend mixing different types of deter-

gents. This may spoil the washing. There

are no restrictions on the use of powder de-

tergents. Liquid detergents must not be

used when a prewash or the reference pro-

gramme (see Programmes table) has been

selected. For cycles without prewash, they

must be added via means of a dosing ball.

Detergent tablets or doses must be placed

in the detergent compartment of your appli-

ance's dispenser box.

TECHNICAL SPECIFICATIONS

DIMENSIONS Height

Width

Depth

850 mm

400 mm

600 mm

LINE VOLTAGE /FREQUENCY

POWER CONSUMPTION 230 V / 50 Hz

2300 W

WATER PRESSURE Minimum

Maximum 0,05 MPa (0,5 bar)

0,8 MPa (8 bar)

Connection to water supply Type 20/27

INSTALLATION

Remove all protective packaging for transit

before using for the first time. Keep in case

needed for future transit: Transporting a

non-secured appliance may damage inter-

nal components and cause leakages and

10 electrolux

Other manuals for EWB 105405 W

Table of contents

Languages:

Other Electrolux Washer manuals

Electrolux

Electrolux EW 1255 F User manual

Electrolux

Electrolux EWF 1408 WDL2 User manual

Electrolux

Electrolux 6000 User manual

Electrolux

Electrolux EW6T5227F5 User manual

Electrolux

Electrolux EIFLW55H MB User manual

Electrolux

Electrolux EWF1180 Operation manual

Electrolux

Electrolux EW7F3944LV User manual

Electrolux

Electrolux EFLS210TIW User manual

Electrolux

Electrolux EWT121 User manual

Electrolux

Electrolux EWT 1011 User manual

Electrolux

Electrolux W5105N User manual

Electrolux

Electrolux EW8F8669Q9 User manual

Electrolux

Electrolux EWF10841 User manual

Electrolux

Electrolux Inspiration EWX11831 TC4 User manual

Electrolux

Electrolux ELTW20XAKW0 User manual

Electrolux

Electrolux FO 950 User manual

Electrolux

Electrolux W365H User manual

Electrolux

Electrolux EWM2000 User manual

Electrolux

Electrolux EW7TN23372C User manual

Electrolux

Electrolux EW8F1168MS User manual

Electrolux

Electrolux EWF 771 User manual

Electrolux

Electrolux EWS1266EDW User manual

Electrolux

Electrolux EWL 105410 W User manual

Electrolux

Electrolux 970L4802 Series User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
