Electrolux EOB 31010 Operation manual

Built-in oven

EOB 31010

user information

2electrolux

electrolux 3

Thank you for selecting our appliance

We wish you lots of enjoyment with your new appliance and we

hope that you will consider our brand again when purchasing

household appliances.

Please read this user manual carefully and keep it throughout the

product life cycle as a reference document. The user manual should

be passed on to any future owner of the appliance.

4electrolux

Important Safety Information .............................................................................. 5

Description of the Oven ...................................................................................... 7

Controls............................................................................................................. 8

Before the First Use ......................................................................................... 10

Using the Oven ............................................................................................... 11

Cooking Chart ................................................................................................. 16

Cleaning and Maintenance .............................................................................. 18

Care of Catalytic Liners.................................................................................... 19

Something not Working ................................................................................... 24

Technical Data ................................................................................................ 25

Electrical Connection ...................................................................................... 26

Instructions fo Building In ................................................................................. 27

Guarantee/Customer Service ........................................................................... 28

European Guarantee ....................................................................................... 30

Safety instructions

Step by step instructions

Hints and Tips

Guide to using the user instructions

)

Contents

This appliance conforms with the following ECC Directives:

- 2006/95 (Low Voltage Directive);

- 89/336 (EMC Directive);

- 93/68 (General Directive);

and subsequent modifications.

MANUFACTURER:

ELECTROLUX HOME PRODUCTS ITALY S.p.A.

Viale Bologna 298

47100 FORLI’ (Italy)

electrolux 5

Important Safety Information

These warnings are provided for the safety of the users and those living

with them. So read them carefully before installing and using the appliance.

This will allow you to obtain best performance, avoid improper actions,

use the appliance in complete safety and also respect the environment.

If you need assistance, contact our Customer Care Department on 08705

727 727

Installation

·This oven must be installed by

qualified personnel to the relevant

British Standards.

·This oven is heavy. Take care when

moving it.

·Remove all packaging, both inside

and outside the oven, before using

the oven.

·Do not attempt to modify the oven

in any way.

During use

·This oven is intended for domestic

cooking only. It is not designed for

commercial or industrial purposes.

·Always stand back from the oven when

opening the oven door during cooking

or at the end of it to allow any build up

of steam or heat to release.

·Appliances become very hot with

use, and retain their heat for long

periods after use. Care should be

taken to avoid touching heating el-

ements inside the oven.

·Never line any part of the oven with

aluminium foil.

·Do not allow heatproof cooking ma-

terial, e.g. roasting bags, to come

into contact with oven elements.

·Never place plastic or any other

material which may melt in or on

the oven.

·Do not place sealed cans or aero-

sols inside the oven. They may ex-

plode if they are heated.

·Do not hang towels, dishcloths or

clothes from the oven or its handle.

·Do not use this oven if it is in con-

tact with water and never operate

it with wet hands.

·Take great care when heating fats

and oils as they will ignite if they

become too hot.

·Always use oven gloves to remove

and replace food in the oven.

·Before cleaning the oven, either turn

the power off or pull the mains plug

out.

·Ensure that all controls are in the

OFF position when not in use.

·Do not leave cookware containing

foodstuffs, e.g. fat or oil in or on the

oven in case it is inadvertently

switched ON.

·When using other electrical appli-

ances, ensure the cable does not

come into contact with the hot sur-

faces of the oven.

6electrolux

People Safety

·This oven is designed to be operated

by adults. Do not allow children to

play near or with the oven.

·The oven gets hot when it is in use.

Children should be kept away until it

has cooled.

·This appliance is not intended for use

by children or other persons whose

physical, sensory or mental capabili-

ties or lack of experience and knowl-

edge prevents them from using the

appliance safely without supervision

or instruction by a responsible per-

son to ensure that they can use the

appliance safely.

Maintenance and Cleaning

·Only clean this oven in accordance

with the instructions.

·Always allow the oven to cool down

and switch off the electrical supply

before carrying out any cleaning or

maintenance work.

·The oven should be kept clean at all

times. A build-up of fats or other

foodstuffs could result in a fire,

especially in the grill pan.

·Never use steam or high pressure

steam cleaners to clean the

appliance.

· Do not use abrasive cleaners or sharp

metal scrapers. These can scratch

the glass in the oven door, which may

result in the shattering of the glass.

Service

·This oven should only be repaired or

serviced by an authorised Service

Engineer and only genuine approved

spare parts should be used.

Environmental Information

·After installation, please dispose of

the packaging with due regard to

safety and the environment.

·When disposing of an old appliance,

make it unusable, by cutting off the

cable. Remove any door catches, to

prevent small children being trapped

inside.

The symbol on the product or on its

packaging indicates that this product

may not be treated as household waste.

Instead it shall be handed over to the

applicable collection point for the

recycling of electrical and electronic

equipment. By ensuring this product is

disposed of correctly, you will help prevent

potential negative consequences for the

environment and human health, which

could otherwise be caused by

inappropriate waste handling of this

product.

For more detailed information about

recycling of this product, please contact

your local city office, your household

waste disposal service or the shop where

you purchased the product.

Always keep these user instructions

with the appliance. Should the

appliance be passed on to third

persons or sold, or if you leave this

appliance behind when you move

house, it is very important that the

new user has access to these user

instructions and the accompanying

information.

electrolux 7

Description of the Oven

1. Control Panel

2. Oven Function Control Knob

3. End of Cooking Programmer

4. Thermostat Control Knob

5. Thermostat Control Light

6. Mains On Light

7. Air Vents for Cooling Fan

8. Grill

9. Oven light

10.Shelf supports

11.Oven Fan

12.Rating plate

Oven accessories

Anti-tip shelf

8electrolux

Controls

Oven Function Control Knob

The oven is off.

Oven light - The oven light

will be on without any cooking

function.

Defrost Setting - This setting

is intended to assist in thawing

of frozen food.

Fan cooking - This allows you

to roast or roast and bake

simoultaneously using any

shelf, without flavour

transference.

Inner grill element only - It

can be used for grilling small

quantities.

Mains on Light

The mains on light will come on when the

oven function control knob is set.

Thermostat Control Knob

Turn the thermostat control knob

clockwise to select temperatures

between 50°C and 250°C.

Thermostat Control Light

The thermostat control indicator will come

on when the thermostat control knob is

turned. The indicator will remain on until

the correct temperature is reached.

It will then cycle on and off to show the

temperature is being maintained.

electrolux 9

End of cooking programmer

This device allows you to make the oven

switch off automatically once the preset

time is over. An acousitic signal will be

heard when the cooking is

completed.The cooking duration can be

set up to 90 minutes maximum.

Place food in the oven and turn the oven

function control knob and the thermostat

control knob on the required settings.

Turn the timer knob to maximum time

position ("90"), then turn it back to set

the required cooking time. When the

cooking time is over, an acoustic alarm

will sound and the oven will switch off

automatically.

Turn the timer knob on to set the oven

on manual operation.

Safety Thermostat

To prevent dangerous overheating

(through incorrect use of the appliance or

defective components), the oven is fitted

with a safety thermostat, which interrupts

the power supply. The oven switches

back on again automatically, when the

temperature drops.

Should the safety thermostat trigger due

to incorrect use of the appliance, it is

enough to remedy the error after the oven

has cooled down; if on the other hand, the

thermostat triggers because of a defective

component, please contact Customer

Service.

The cooling fan

The oven is provided with a cooling fan,

meant to keep the front panel, the knobs

and the oven door handle cool.The fan

switches on automatically when the oven

is activated. Warm air is blown out

through the aperture near the oven door

handle.

When the oven is switched off,the fan may

run on after the oven isswitched off to

keep the controls cool.This is quite

normal.The action of the cooling fan will

de-pend on how long the oven has

beenused and at what temperature.

Itmay not switch in at all at

lowertemperature settings nor run

onwhere the oven has only been usedfor

a short time.

The fan switches off when, after cooking,

the oven function control knob is set to

OFF position .

10 electrolux

Before the First Use

To open the oven door,

always hold the handle in the

centre.

Remove all packaging, both

inside and outside the oven, be-

fore using the oven.

Before using for the first time, the oven

should be heated up without food.

During this time, an unpleasant odour

may be emitted. This is absolutely nor-

mal. It is caused by manufacturing resi-

dues.

Ensure the room is well ventilated.

1. Switch the oven function con-

trol knob to fan cooking .

2. Set the thermostat control

knob to 250°C.

3. Open a window for ventilation.

4. Allow the oven to run empty

for approximately 45 minutes.

This procedure should be repeated with

the inner grill function for approxi-

mately 5-10 minutes.

Then let the oven cool down. Then

dampen a soft cloth with warm

water and a little mild washing-

up liquid and use this to clean the

oven cavity.

Before using for the first time,

carefully wash the oven accesso-

ries as well.

)

Table of contents

Other Electrolux Oven manuals

Electrolux

Electrolux EOD43102 User manual

Electrolux

Electrolux EOK86030 User manual

Electrolux

Electrolux KDFEC40UX User manual

Electrolux

Electrolux EOB 2700 User manual

Electrolux

Electrolux B9978-5 User manual

Electrolux

Electrolux EOK76030 User manual

Electrolux

Electrolux EZB3411AOX User manual

Electrolux

Electrolux EH6K10SW User manual

Electrolux

Electrolux D57116 User manual

Electrolux

Electrolux Air-O-Steam 267551 User manual

Electrolux

Electrolux EOB63000X User manual

Electrolux

Electrolux EOK86030 User manual

Electrolux

Electrolux EOB 6640 User manual

Electrolux

Electrolux KOC6P40X User manual

Electrolux

Electrolux EW30EW65GS - 30" E Dbl Wall Oven WAVETCH... Installation instructions

Electrolux

Electrolux EOB974 Specification sheet

Electrolux

Electrolux EOB 966 User manual

Electrolux

Electrolux EOB54000 User manual

Electrolux

Electrolux EOB 966 User manual

Electrolux

Electrolux OPEA2350B User manual

Electrolux

Electrolux COP720X User manual

Electrolux

Electrolux EDB710 User manual

Electrolux

Electrolux EH L4-4 User manual

Electrolux

Electrolux EOB53020 User manual

Popular Oven manuals by other brands

Bosch

Bosch HVA531NS0 instruction manual

NEFF

NEFF B44S32 5GB Series instruction manual

Combi

Combi BLODGETT BC142GDS Specifications

AEG

AEG COMPETENCE 311704300 Installation and operating instructions

Falcon

Falcon DOMINATOR PLUS G3106 Series Servicing instructions

Rational

Rational SCC WE 61G installation manual

Smeg

Smeg DOSPA38X User manuals

Miele

Miele HR 1954-2 operating instructions

KHIND

KHIND OT50 instruction manual

Henny Penny

Henny Penny Smoker Box installation manual

Lang

Lang ECOD-AP Installation and operation instructions

AEG

AEG BEK455310M user manual

Frigidaire

Frigidaire FNGE90JGR user manual

Hotpoint

Hotpoint FE9 S831 JSH IX user manual

GE Advantium SCB2000 owner's manual

AEG

AEG DE401301DM user manual

DeLonghi

DeLonghi XA660 Directions for use

AEG

AEG BEB331010M user manual
