Electrolux B3741-5 User manual

B3741-5

User manual Built-In Electric Oven

Contents2

Contents

Operating Instructions 3

Safety instructions 3

Description of the Appliance 4

General Overview 4

Control Panel 5

Oven Features 5

Oven accessories 6

Before Using for the first time 6

Setting and changing the time 6

Initial Cleaning 7

Using the Oven 8

Switching the Oven On and Off 8

Rapid heat up 10

Oven Functions 11

Inserting the Oven Shelf and the Baking Tray

Clock Functions 13

Other functions 17

Uses, Tables and Tips 18

Baking 18

Roasting 23

Grill sizes 25

Defrosting 26

Drying 27

Making preserves 27

Cleaning and Care 28

Outside of the appliance 28

Oven interior 29

Accessories 29

Pyrolytic cleaning 29

Shelf Support Rails 30

Oven lighting 31

Oven door 31

Oven door glass 33

What to do if … 37

Disposal 38

Installation Instructions 39

Safety information for the installer 39

Guarantee/Customer Service 43

Service 45

Thank you for choosing one of our high-quality products.

To ensure optimal and regular performance of your appliance please read this instruc-

tion manual carefully. It will enable you to navigate all processes perfectly and most ef-

ficiently.

To refer to this manual any time you need to, we recommend you to keep it in a safe

place. And please pass it to any future owner of the appliance.

We wish you much joy with your new appliance.

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how to

avoid damaging the appliance.

3General information and tips

2Environmental information

3Operating Instructions

Operating Instructions

1Safety instructions

Electrical safety

•This appliance must be only connected by a registered electrician.

•In the event of a fault or damage to the appliance: Take the fuses out or switch off.

•Repairs to the appliance must only be carried out by qualified service engineers.

Considerable danger may result from improper repairs. If repairs become necessary,

please contact our Customer Services or your dealer.

Child Safety

•Never leave children unsupervised when the appliance is in use.

Safety whilst using

•People (including children) who, because of their physical, sensory or mental capabili-

ties or their inexperience or ignorance are not able to use the device safely, should not

use this device without supervision or instruction by a responsible person.

•This appliance is intended to be used for cooking, roasting and baking food in the

home.

•Take care when connecting electric appliances to sockets nearby. Do not allow con-

necting leads to come into contact with or to catch beneath the hot oven door.

•Warning: Risk of burns! The interior of the oven becomes hot during use.

•Using ingredients containing alcohol in the oven may create an alcohol-air mixture

that is easily ignited. In this case, open the door carefully. Do not have embers, sparks

or naked flames in the vicinity when opening the door.

3Information on acrylamides

According to the latest scientific knowledge, intensive browning of food, especially in

products containing starch, can constitute a health risk due to acrylamides. Therefore we

recommend cooking at the lowest possible temperatures and not browning foods too

much.

How to avoid damage to the appliance

•Do not line the oven with aluminium foil and do not place baking trays, pots, etc. on

the oven floor, as the heat that builds up will damage the oven enamel.

•Fruit juices dripping from the baking tray will leave stains, which you will not be able

to remove. For very moist cakes, use a deep tray.

•Do not put any strain on the oven door when open.

•Never pour water directly into the oven when it is hot. This could cause damage to or

discolouration of the enamel.

•Rough handling, especially around the edges of the front panel, can cause the glass to

break.

•Do not store any flammable materials inside the oven. These could ignite when the

oven is switched on.

Description of the Appliance4

•Do not store any moist foods inside the oven. This could damage the oven enamel.

•After switching off the cooling fan, do not keep uncovered dishes in the oven. Mois-

ture may condense in the oven interior or on the glass doors and may get into the

units.

3Note on enamel coating

Changes in the colour of the oven’s enamel coating as a result of use do not affect the

appliance’s suitability for normal and correct use. They therefore do not constitute a de-

fect in the sense of the warranty law.

Description of the Appliance

General Overview

Full glass door

Control panel

Door

handle

5Description of the Appliance

Control Panel

Oven Features

Oven Functions Temperature / Time Selection

Function buttons

Oven Power Indicator

Temperature /

Time Display

Top heat and heating elements

Oven lighting

Fan

Bottom Heat

Shelf positions

Oven shelf runners,

removable

Before Using for the first time6

Inside of door

You will find the shelf position number on the

inside of the oven door.

Oven accessories

Oven shelf

For cookware, cake tins, roasts and grilled foods.

Baking tray

For cakes and biscuits.

Before Using for the first time

Setting and changing the time

3The oven only operates when the time has been set.

When the appliance has been connected to the

electrical supply or when there has been a pow-

er cut, the function indicator Time of

day flashes automatically.

1. To change a time that has already been set,

press the Selection button repeatedly until

the function indicator Time of day flashes.

7Before Using for the first time

2. Using the / control knob, set the current

time.

After approx. 5 seconds, the flashing stops and

the clock displays the time of day set.

The appliance is now ready to use.

3The time can only be modified, if the child safe-

ty device is deactivated, none of the Minute

Minder , Duration or End clock func-

tions and no oven function is set.

Initial Cleaning

Before using the oven for the first time you should clean it thoroughly.

1Caution: Do not use any caustic or abrasive cleaners. The surface could be damaged.

3To clean metal fronts use commercially available cleaning agents.

1. Set the oven functions dial to Light .

2. Remove all accessories and the shelf support rails and wash them with warm water and

washing up liquid.

3. Then wash out the oven with warm water and washing-up liquid, and dry.

4. Wipe the front of the appliance with a damp cloth.

Using the Oven8

Using the Oven

Switching the Oven On and Off

Switching the oven on

Turn the oven functions selector to the desired

function. The power indicator light lights up.

The temperature display shows the suggested

temperature for the oven function selected.

The oven starts to heat up.

When the temperature set is reached, an audi-

ble signal sounds.

Oven Functions Temperature / Time Selection

Temperature / Time Display

Change display

Heat indicatorSpeedcook

Oven Power Indicator

Clock FunctionsButton Speedcook

9Using the Oven

Changing the oven temperature

Turn the / knob to raise or lower the tem-

perature.

The setting changes in 5 °C steps.

Checking the temperature

Press Rapid heat up and Selection but-

tons at the same time.

The current oven temperature appears in the

temperature display.

Switching the oven off

To turn the oven off, turn the oven functions

selector to the OFF position.

3Cooling fan

The fan switches on automatically in order to keep the appliance’s surfaces cool. When

the oven is switched off, the fan continues to run to cool the appliance down, then

switches itself off automatically.

Using the Oven10

3Heat indicator

Indicates warming up

When the oven function has been switched on

the bars that slowly light up one after the other

indicate how far the oven has heated up.

Fast heat indicator

When the fast heat function has been

switched on the bars that flash one after

the other indicate that fast heat is operating. In

addition the bars next to the symbol light

up.

Residual heat indicator

When the oven has been switched off, the bars

that are still lit indicate the remaining residual

heat in the oven.

Rapid heat up

After an oven function is selected, using the additional function Rapid heat up the

empty oven can be pre-heated in a relatively short time.

1Important: Do not put the food to be cooked into the oven, until Rapid heat up is

completed and the oven is operating using the desired function.

1. Set the desired oven function (e. g., Conventional ). If necessary, change the suggested

temperature.

2. Press the Rapid heat up button. The bars next to the symbol light up.

When the bars flash one after another it shows that Rapid heat up is operating.
