Educational Insights Circuit Explorer Rover User manual

SIMPLE CIRCUITS BIG IMAGINATION

ROVER

MISSION GUIDE

EI-4201

You made it to Mars! You are stationed at The Last Outpost, which is equipped with supplies

to build the things you will need.

Your team will journey into the unknown regions to map the surface and collect samples —

be sure to radio the Base Station with your discoveries! Follow these instructions to construct

an Explorer Rover, a sample collector known as The Claw, a Charging Station, and a

Portable Communication Tower. We’re relying on your engineering skills to create closed

circuits and propel our mission forward!

Good Luck!

Parts Checklist

1x1x 2x

2x1x

N7P2 N8

A13

P4 1x

P4a

STICKERS

2x 2x

2x 2x 2x2x

8x1x

1x 1x

L3 W1

A2 A5 A6A4

T1A9

P1 V1

Conductive Parts

These parts are where

energy is stored.

Power Source EffectConductor

The various lights and motors in this

set are powered by the energy.

These parts extend your builds

and allow power to ow from

the battery to the effect.

CapacitorBattery

Read all instructions before using your Circuit Explorer™set and keep this guide for reference.

WARNING: SHOCK HAZARD – Never touch the circuit connectors to outlets or anything else electrical in your home. Circuit components are

only intended for use with other Circuit Explorer products, as described in this guide.

Attention Adults:

• Seek medical attention immediately if

batteries or parts are swallowed. Have

physician call the NATIONAL BATTERY

INGESTION HOTLINE for advice and

follow-up: (202) 625-3333 collect

day or night.

• Do not use components in or near water.

• Do not put any components in mouth,

eyes, or nose.

• Keep battery pack and other components

away from AC power plugs and outlets

• Remove worn, dead, or corroded batteries

immediately and discard properly.

• Please read all instructions and help your

child follow each mission’s steps and

safety procedures.

Building a Circuit

Line up the conductive symbols to make a complete loop.

Line up the power source with a conductor and the effect. When connected, these are ready to become a closed circuit.

After the parts are connected, press the power button.

The depressed button closes the loop, allowing the energy to ow. This is a closed circuit!

2 X

3X AAA3X AAA

3X AAA

P2P1

DOES

NOT

OPEN!

Battery Installation

and Instructions

1. Use a Phillips-head screwdriver to remove the

battery door screws.

2. Battery packs require three AAA batteries

each, not included.

3. Batteries must be inserted with the

correct polarity.

4. Do not mix old and new batteries.

5. Do not recharge non-rechargeable batteries.

6. Do not mix different types of batteries:

alkaline, standard (carbon zinc), or

rechargeable batteries.

7. Only use batteries of the same or

equivalent type.

8. Remove exhausted batteries from the units.

9. Do not short-circuit the supply terminals.

10. Only charge rechargeable batteries under

adult supervision.

11. Remove rechargeable batteries from the toy

before charging.

12. This toy is not to be connected to more than

the recommended number of power supplies.

To prevent corrosion and possible damage to the

product, it is recommended to remove the batteries

from the units if they will not be used for more than

two weeks.

1 2 1 2

Astronaut Robot

Explorer Rover

This manual suits for next models
