EDIMAX Technology co., Ltd.

The IP Security Solutions

Total Network Surveillance Solution

Product Overview

▪ IP-66 weather- resistant housing for outdoor

▪ Sony ExView CCD; 560-line High resolution

▪ 37x Optical zoom + 12x Digital zoom

▪ Pan 360°(continuous); Tilt 180° ; Speed up to 240°

▪ WDR (wide-dynamic-range) for environment

adoption

▪ Mask x 8 for privacy protection

▪ DSS and SNR – super for low-light surveillance

▪ ICR (IR-cut Removal) for day-n-night

▪ PelcoTM D/P compatible, work with most DVR

▪ 128 presets + 255 camera ID

▪ 6 modes of Auto-run; 1 alarm-in + 1 alarm-out

37x Optical zoom + 12x Digital zoom

Pan 360°/ Tilt 180°/ Speed up to 240°

IP-66 Weather-resistant

WDR improves contrast of picture that has target exposed under overwhelming light source which may drive the

target become too dark due to the over-do of auto gain control.

WDR

QMD-3437W has 37 times optical zoom and 12 times digital zoom. The 3.5 – 129mm focal range allows user to

see enough wide or target at distance effectively.

37x Optical Zoom

Mechanical IR-Cut lter makes the images clearly and steady during the day, and produce high quality video in

low light condition as well.

MIR

Specications

Dimension

Description Full D1 37X IP Outdoor Speed Dome Camera

IR-LED NA

sensor 1/4 Sony Ex-View CCD

Processor DSP Base (DaVinci TM320DM365)

Lens (optical / digital) 37x/12x ( f3.5-129.5mm) / F1.6-3.9

Min. Illumination (Color/BW/

Slow Shutter mode) 0.7lux/0.06lux /0.002 lux

Video Compression H.264 HP/MP/BP, MPEG-4 SP, M-JPEG

Resoultion (Color/BW) 520TVL / 570TVL

Multiple Streaming Yes

ICR Yes

SD/SDHC interface Yes

Power-over-Ethernet(IEEE 802.3af) NA

Audio Support Two-way

Alarm Input/output 1x D/I, 1x D/O

IP Digital zoom 10x

ONVIF Yes

Protocol TCP/IP,IPV6,UDP,ICMP ,DHCP ,NTP ,DNS ,DDNS ,SMTP ,FTP ,HTTP ,HTTPs

,Samba,PPPoE ,UPnP, Bonjour, RTP, RTSP, RTCP, IPV4

QoS Yes

Multi-level user access Yes

IP ltering Yes

3GPP support Yes

Time Management

Manual Time Setting

Time Server and NTP support

Real Time Clock

Event Management

Events Triggered by Motion detection or GPIO

Image or Video Upload/Send over email ,FTP, samba

Recording Video le to SD Card by schedule

System Management 64-ch Management Software(EdiView RS-64)

Operation Temperature -35oC~55oC

Approvals CE, FCC

Package

Accessories:

Power Supply (AC 24V)

Packaging(Brown Box)

CD, QIG

©2010 Edimax. All other company names and products are trademarks or registered trademarks of their respective companies.

We reserve the right to introduce modications without notice.
