Инструкция для
Dynam P51D Mustang
Перейти в карточку товара
8 800 775 98 98
Instruction Manual
Wingspan:
Overall Length:
Flying weight:
Servo:
Battery:
Speed Control:
Motor Size:
Charger :
47 in (1200mm) 41 in (1045mm)
38.8oz (1100 g)
9g 4pcs include
3S 11.1V 2200mAh Li-Po ,20c
30A brushless
850Kv Brushless Outrunner
3-cell Li-Po balancing
1
2
RTF INCLUDING
3
RTF including:
fuselage
wing
elevator
landing gear
Vertical stabilizer
Push rod
Propeller
glue
decal
balance charger
LI-Po battery (11.1V 2200mAh 20C)
transmitter
Adaptor
Spinner
ESC
4
Apply the foam glue on the joiner of
the left and right landing gear, push
them in the position.
Fix the wing on fuselage with
PA2.3*20mm screw.
Insert the horizontal stabilizer and
vertical stabilizer in place.
Insert ¢8x406mm glass fiber tube into
left and right wing, and connect the
wings together.
Fix the rear landing gear on fuselage
with 1.5mm hexangular screwdriver.
Fix the stabilizers with PA 2.3*20mm
screw.
Install spinner with PA2.5*8mm screws.
Insert the pushrod into elevator
quick-controller and tighten the
screw(the servo should be in center
position).
Connect the aileron servos with Y wires.
Repeat the steps for the rudder.
Install the propeller.
Put the battery in position.
THROTTLE
RUDDER
ELEVATOR
AILERONS
airplane action
airplane action
airplane action
airplane action
control plane
movement
control plane
movement
Aileron
movement
6
STICK OPERATION
MODE 1 MODE 2 MOVEMENT
75
70
70 75 70 75
1107x3
7
