Dometic SC330 Owner's manual

POWER & CONTROL

CHARGER

SC330, SC480

EN Solar Charge Controller

Short Installation and Operating Manual............................... 3

DE Solarladeregler

Montage- und Bedienungskurzanleitung............................. 10

FR Contrôleur de charge solaire

Bref manuel d’installation et d’utilisation..............................17

ES Controlador de carga solar

Guía breve de instalación y funcionamiento.........................24

PT Controlador de carga solar

Breve Instalação e Manual de Operações............................ 31

IT Regolatore di carica solare

Guida rapida di installazione e d’uso.................................. 38

NL Laadregelaar voor zonne-energie

Beknopte montagehandleiding en gebruiksaanwijzing......... 45

DA Styreenhed til solcelleladning

Kort installations- og betjeningsvejledning...........................52

SV Solladdningsregulator

Snabbguide för installation och användning........................ 59

NO Solcelleregulator

Kort monterings- og brukerveiledning.................................66

FI Aurinkosähkölaturi

Pikaohje asennusta ja käyttöä varten................................... 73

PL Regulator ładowania dopaneli fotowoltaicznych

Krótka instrukcja montażu iobsługi.....................................80

SK Solárna nabíjačka

Krátky návod namontáž aobsluhu......................................87

CS Řídicí jednotka solárního nabíjení

Stručný návod kmontáži aobsluze.....................................94

HU Napelem töltő

Rövid telepítési és üzemeltetési kézikönyv.......................... 101

HR Upravljački sklop solarnog punjenja

Kratke upute za montažu i rukovanje................................. 108

TR Solar Şarj Cihazı

Kısa Kurulum ve Kullanım Kılavuzu......................................115

SL Solarni polnilnik

Kratka navodila zamontažo in uporabo..............................122

RO Controler de Încărcare Fotovoltaică

Manual scurt de instalare şi de utilizare.............................. 129

BG Слънчево зарядно устройство

Кратко ръководство за инсталация и работа..................... 136

ET Päikeseenergia laadija

Lühike paigaldus- ja kasutusjuhend....................................143

EL Ελεγκτής ηλιακής φόρτισης

Συνοπτικό εγχειρίδιο τοποθέτησης και χρήσης........... 150

LT Saulės įkrovos reguliatorius

Trumpas montavimo ir naudojimo vadovas.........................158

LV Saules enerģijas lādēšanas kontrolieris

Īsā uzstādīšanas un lietošanas rokasgrāmata....................... 165

design law. The underlying technical design and the products contained herein may be protected by design,

patent or pending patent. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights

are reserved.

English

1 Important notes

Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to

ensure that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.

By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and that you understand

and agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and ap-

plication and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance

with all applicable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury

to yourself and others, damage to your product or damage to other property in the vicinity. This product manual, including the instruc-

tions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date product informa-

tion, please visit documents.dometic.com.

2 Related documents

Find the full installation and operating manual online at:

http://qr.dometic.com/beEcxd.

3 General safety instructions

Also observe the safety instructions and stipulations issued by the vehicle manufacturer and autho-

rized workshops.

WARNING! Electrocution hazard

• Installation and removal of the device may only be carried out by qualified personnel.

• Do not operate the device if it is visibly damaged.

• If this device's power cable is damaged, the power cable must be replaced in order to pre-

vent safety hazards.

• This device may only be repaired by qualified personnel. Improper repairs can lead to con-

siderable hazards.

• If you disassemble the device: Detach all connections. Ensure that no voltage is present on

any of the inputs and outputs.

• Do not use the device in wet conditions or submerge in any liquid. Store in a dry place.

• Only use accessories that are recommended by the manufacturer.

• Do not modify or adapt any of the components in any way.

• Disconnect the device from the power supply:

Before each cleaning and maintenance

After use

Before changing a fuse

Before carrying out electrical welding work or work on the electrical system

WARNING! Health hazard

• This device can be used by children aged from 8 years and above and persons with re-

duced physical, sensory or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the device in a safe way and

understand the hazards involved.

•Electrical devices are not toys. Always keep and use the device out of the reach of very

young children.

• Children must be supervised to ensure that they do not play with the device.

• Cleaning and user maintenance shall not be made by children without supervision.

NOTICE! Damage hazard

• Before start-up, check that the voltage specification on the data plate is the same as that of

the power supply.

• Ensure that other objects cannot cause a short circuit at the contacts of the device.

• Ensure that the negative and positive poles never come into contact.

3.1 Installing the device safely

DANGER! Explosion hazard

Never mount the device in areas where there is a risk of gas or dust explosion.

WARNING! Risk of injury

• The device must be mounted and fastened in such a way that it cannot fall down.

• When positioning the device, ensure that all cables are suitably secured to avoid any form

of trip hazard.

NOTICE! Damage hazard

• Do not place the device near heat sources (heaters, direct sunlight, gas ovens, etc.).

• Mount the device in a dry location where it is protected against splashing water.

3.2 Safety when connecting the device electrically

DANGER! Electrocution hazard

If you are working on electrical systems, ensure that there is somebody close at hand who can help

you in emergencies.

WARNING! Electrocution hazard

• Observe the recommended cable cross-sections.

• Lay the cables so that they cannot be damaged by the doors or the hood. Crushed cables

can lead to serious injury.

NOTICE! Damage hazard

• Use ductwork or cable ducts if it is necessary to lay cables through metal panels or other

panels with sharp edges.

• Do not lay the cable so that it is loose or heavily kinked.

• Fasten the cables securely.

• Do not pull on the cables.

3.3 Operating the device safely

WARNING! Explosion hazard

• Only use the device in closed, well-ventilated rooms.

• Do not operate the device under the following conditions:

In salty, wet or damp environments

In the vicinity of corrosive fumes

In the vicinity of combustible materials

In areas where there is a danger of explosions

WARNING! Electrocution hazard

• Observe that parts of the device may still conduct voltage even if the fuse has blown.

• Do not disconnect any cables when the device is still in use.

NOTICE! Damage hazard

• Ensure that the air inlets and outlets of the device are not covered.

• Ensure a good ventilation.

• The device shall not be exposed to rain.

3.4 Safety precautions when handling batteries

WARNING! Risk of injury

• Batteries contain aggressive and caustic acids. Avoid battery fluid coming into contact with

your body. If your skin does come into contact with battery fluid, wash that part of your

body thoroughly with water. If you sustain any injuries from acids, contact a doctor immedi-

ately.

• When working on batteries, do not wear any metal objects such as watches or rings. Lead

acid batteries can cause short circuits that can cause serious injuries.

• Only use insulated tools.

• Wear goggles and protective clothing when working on batteries. Do not touch your eyes

when working on batteries.

CAUTION! Explosion hazard

• Never attempt to charge a frozen or defective battery. Place the battery in a frost-free area

and wait until the battery has acclimatized to the ambient temperature. Then start the charg-

ing process.

• Do not smoke, use an open ﬂame, or cause sparking near the engine or a battery.

NOTICE! Damage hazard

• Only use rechargeable batteries.

• Prevent any metal parts from falling on the battery. This can cause sparks or short-circuit the

battery and other electrical parts.

• Ensure that the polarity is correct when connecting the battery.

• Follow the instructions of the battery manufacturer and those of the manufacturer of the sys-

tem or vehicle in which the battery is used.

• If the battery has to be removed, ﬁrst disconnect the ground connection. Disconnect all

connections and all consumers from the battery before removing it.

• Only store fully charged batteries. Recharge stored batteries regularly.

• Do not carry the battery by its terminals.

Safety precautions when handling lithium batteries

CAUTION! Risk of injury

Only use batteries with integrated battery management system and cell balancing.

NOTICE! Damage hazard

• Only install the battery in environments with an ambient temperature of at least 0 °C.

• Avoid deep discharge of the batteries.

Safety precautions when handling lead acid batteries

CAUTION! Health hazard

The water-acid liquid inside the battery can evaporate and cause an acidic odor. Use the battery

only in a well-ventilated area.

NOTICE! Damage hazard

• The battery is not sealed. Do not turn the battery on its side or upside down. Place the bat-

tery on a horizontal surface.

• Check the acid level for open lead acid batteries regularly.

• Immediately recharge deeply discharged lead acid batteries to avoid sulfation.

4 Target Group

The electrical power supply must be connected by a qualified electrician who has demonstrated

skill and knowledge related to the construction and operation of electrical equipment and instal-

lations, and who is familiar with the applicable regulations of the country in which the equipment

is to be installed and/or used, and has received safety training to identify and avoid the hazards in-

volved.

5 Intended use

The solar charge controller is intended to ensure the correct charging voltage of the house battery when being

charged by solar panels using microprocessor controlled IU0U charging programs and to protect the battery

against over voltage and deep discharge.

Additionally the solar charge controller secures a sufficient state of charge of the starting battery to ensure the

starting of the engine.

The solar charge controller is only suitable for controlling solar modules.

The solar charge controller is not suitable for controlling other charging sources.

The solar charge controller is intended for charging the following battery types:

• Lead acid batteries

• Lead gel batteries

• Absorbed glass mat (AGM) batteries

• LiFePO4 batteries

The solar charge controller is not intended for charging other types of batteries (e.g., NiCd, NiMH, etc.).

The solar charge controller is suitable for:

• Installation in recreational vehicles

• Stationary or mobile use

• Indoor use

The solar charge controller is not suitable for:

• Mains operation

• Outdoor use

The energy output of connected solar panels must not exceed the maximum output stated in the technical data.

This product is only suitable for the intended purpose and application in accordance with these instructions.

This manual provides information that is necessary for proper installation and/or operation of the product. Poor

installation and/or improper operating or maintenance will result in unsatisfactory performance and a possible

failure.

The manufacturer accepts no liability for any injury or damage to the product resulting from:

• Incorrect assembly or connection, including excess voltage

• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer

• Alterations to the product without express permission from the manufacturer

• Use for purposes other than those described in this manual

Dometic reserves the right to change product appearance and product specifications.

6 Installation

Observe the following instructions:

• Install the device close to the batteries to keep the battery connection cable as short as possible.

• Ensure that the mounting surface is solid and level.

• Choose an location that is well ventilated and protected from moisture and dust.

• Keep a distance of 10 cm to all sides around the device.

• Before drilling any holes, ensure that no electrical cables or other parts of the vehicle can be damaged by

drilling, sawing, or filing.

• Completely cover all solar panels with an opaque material during installation to prevent electricity from

being generated.

• Observe the recommended cable cross sections, cable lengths and fuse.

• Place the fuses near the batteries to protect the cables from short circuits and possible burning.

• To ensure measuring the internal temperature of the battery connect the temperature sensor provided to

the negative terminal of the house battery.

Proceed as shown:

To mount the solar charge controller: See leaﬂet Fig. on page1

To connect the solar charge controller: See leaﬂet Fig. on page1 to Fig. on page1

To replace the fuse: See leaﬂet Fig. on page2

7 Operation

Proceed as shown:

To set the charging program: See leaﬂet Fig. on page2

To perform the system operation check: See leaﬂet Fig. on page2 to Fig. on page2

To download the SunControl app: See leaﬂet Fig. on page2

8 Disposal

Recycling packaging material: Place the packaging material in the appropriate recycling waste bins

wherever possible.

Recycling products with non-replaceable batteries, rechargeable batteries or light sources:

• If the product contains any non-replaceable batteries, rechargeable batteries or light

sources, you don't have to remove them before disposal.

• If you wish to finally dispose of the product, ask your local recycling center or specialist deal-

er for details about how to do this in accordance with the applicable disposal regulations.

• The product can be disposed free of charge.

9 Legal

Hereby, Dometic Mobile Power Italy S.r.l. declares that the radio equipment type SC330 and SC480 are in com-

pliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following

internet address: documents.dometic.com

Deutsch

1 Wichtige Hinweise

Lesen und befolgen Sie bitte alle Anweisungen, Richtlinien und Warnhinweise in diesem Produkthandbuch sorgfältig, um sicherzustel-

len, dass Sie das Produkt ordnungsgemäß installieren und stets ordnungsgemäß betreiben und warten. Diese Anleitung MUSS bei

dem Produkt verbleiben.

Durch die Verwendung des Produktes bestätigen Sie hiermit, dass Sie alle Anweisungen, Richtlinien und Warnhinweise sorgfältig ge-

lesen haben und dass Sie die hierin dargelegten Bestimmungen verstanden haben und ihnen zustimmen. Sie erklären sich damit ein-

verstanden, dieses Produkt nur für den angegebenen Verwendungszweck und gemäß den Anweisungen, Richtlinien und Warnhin-

weisen dieses Produkthandbuchs sowie gemäß allen geltenden Gesetzen und Vorschriften zu verwenden. Eine Nichtbeachtung der

hierin enthaltenen Anweisungen und Warnhinweise kann zu einer Verletzung Ihrer selbst und anderer Personen, zu Schäden an Ihrem

Produkt oder zu Schäden an anderem Eigentum in der Umgebung führen. Dieses Produkthandbuch, einschließlich der Anweisungen,

Richtlinien und Warnhinweise, sowie die zugehörige Dokumentation können Änderungen und Aktualisierungen unterliegen. Aktuelle

Produktinformationen finden Sie unter documents.dometic.com.

2 Zugehörige Dokumente

Die vollständige Montage- und Bedienungsanleitung finden Sie online unter:

http://qr.dometic.com/beEcxd.

3 Grundlegende Sicherheitshinweise

Beachten Sie die vom Fahrzeughersteller und vom Kfz-Handwerk herausgegebenen Sicherheits-

hinweise und Auflagen.

WARNUNG! Gefahr durch Stromschlag

• Montage und Demontage des Geräts dürfen nur durch qualifiziertes Fachpersonal erfolgen.

• Wenn das Gerät sichtbare Beschädigungen aufweist, dürfen Sie es nicht in Betrieb nehmen.

• Wenn das Stromversorgungskabel dieses Geräts beschädigt ist, muss es ausgetauscht wer-

den, um Sicherheitsrisiken zu vermeiden.

• Reparaturen an diesem Gerät dürfen nur von Fachkräften durchgeführt werden. Durch un-

sachgemäße Reparaturen können erhebliche Gefahren entstehen.

• Falls Sie das Gerät demontieren: Lösen Sie alle Verbindungen. Stellen Sie sicher, dass alle

Ein- und Ausgänge spannungsfrei sind.

• Verwenden Sie das Gerät nicht bei Nässe und tauchen Sie es nicht in Flüssigkeiten ein. La-

gern Sie das Gerät an einem trockenen Ort.

• Verwenden Sie nur vom Hersteller empfohlenes Zubehör.

• Führen Sie keine Änderungen bzw. Anpassungen an Komponenten durch.

Other manuals for SC330

This manual suits for next models

Table of contents

Languages:

Other Dometic Controllers manuals

Dometic

Dometic Go Power! GP-SB-PWM-10 User manual

Dometic

Dometic FT7000SEP User manual

Dometic

Dometic GP-MPPT-60/10 User manual

Dometic

Dometic Go Power! GP-SB-PWM-30BT User manual

Dometic

Dometic GP-PC-10-IP68 User manual

Dometic

Dometic Go Power! 30 AMP RVC MPPT User manual

Dometic

Dometic PCWM-VAR User manual

Dometic

Dometic RTX1000 User manual

Dometic

Dometic GP-MPPT-100/30 User manual

Dometic

Dometic 30AMP PWM User manual

Dometic

Dometic GP-MPPT-60/10 User manual

Dometic

Dometic PCD5501 User manual

Dometic

Dometic Go Power GP-PWM-10-SQ User manual

Dometic

Dometic Enerdrive EN43510 User manual

Dometic

Dometic EA1000 User manual

Dometic

Dometic SC330 User manual

Dometic

Dometic SmartStart III User manual

Dometic

Dometic Marine Air Systems Fx-Maxx SDL User manual

Dometic

Dometic MPC01 Plus User manual

Dometic

Dometic Go Power! GP-PWM-30-SB User manual

Dometic

Dometic Go Power! GP-SB-PWM-10 User manual

Dometic

Dometic SmartStart SMRTSTACRV User manual

Dometic

Dometic Optimus Adaptive Trim Tab System User manual

Dometic

Dometic Zamp Solar ZS-30A Deluxe User manual

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

ABB

ABB ACS580-01 drives Hardware manual

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual
