wireless sensors or wired ports trigger alarm(only the wireless detectors of HomeArm function effective,
Out Arm detectors are ineffective), then dial out phone or send message, the light STATUS becomes
red flashing.
When press Disarm, the light STATUS becomes green, wireless detectors or wired ports won’t
trigger alarm.
When press Alarm, regardless of the host in arming status (the light STATUS is green flashing),or
disarming status (the light STATUS is green ), will make the host trigger alarm immediately , dial out
phone and send message, the light STATUS becomes red flashing.
How to record 10 seconds voice message ?
Users can record geographical location, home address information as alarm voice, which will be
broadcast when alarming, convenient for the receiver to know the scene information.
Recording operation:
Press the record key for 2 seconds until the light Record is on, then speak by the microphone which
embedded in the left side of the host, then 10 seconds’ voice can be record. 10 seconds later the light
RECORD is off, then exits the recording status automatically. If you want to change the voice content,
repeat the operation.
How to test the alarm function ?
When the host is powered and disarmed, users can use remote controller(OutArm, Home Arm key )
or send message (123456#1#1#) to arm. Under arming status, the green light flash, If the wired input
trigger alarm (any port of I1, I2, I3, I4, I5 shorted or disconnected to GND) or wireless sensors trigger
alarm (wireless FIR detector, wireless door sensor, Out Arm, Home Arm key of remote controller ),or
calling in the system from other places trigger alarm (input password 123456 #, then 2 # 1 #), will make
the host send alarm information.
⒈If there are phone numbers stored to receive SMS, the host will send the corresponding SMS to the
SMS users based on the trigger port（wired I1,I2,I3,I4,I5,wireless sensors 1-16）.
⒉If there are phone numbers stored to receive alarm, the host can dial every number to alarm. When
replying, users can hear the alarm voice which recorded before. if the voice isn't clear, press “＊”
key to listen again.
⒊When alarming，users can open the listening-in function or control in long-distance, no need to input
the password，pressing 2#1# to make scene alarm immediately，pressing 2#0# to close on-site
alarm.
⒋When alarming，users can open listening-in function or control in long-distance, no need to input
password，pressing 3#1# to open listening-in，pressing 3#0# to close listening-in.
⒌When alarming，users can talk to people at the scene, after the phone getting through, there is no
need to input password，pressing 4#1# to make the host send out the voice of master immediately,
pressing 4#0# to close the voice at the scene.
⒍When alarming，after users get through the phone, if it is not the intrusion, users can dial 1#1# to
make the host arm again, and the host will not go on dialing other phones.
⒎When alarming，people at the scene can press the Disarm key to exit from alarm status.
⒏Normal use, if there is built-in battery, when external power supply is off / on, the host will send
messages to inform users.
The message content :power change off/on(year/month/day, hour/minute/second)
⒐Usually, users can remote control the host through phone, but input password first to continue other
operation.
