displayit E20J User manual
20’ Ensemble Tension Fabric Trade Show Display Kit E20J
Assembly Instructions
1. Straighten and assemble all
bungeed poles.
2. Assemble the frame by aligning
the stickers as seen in the frame
diagram above.
4. Attach the feet to the frame as
seen in the diagram above.
3. Pull pillowcase graphic over frame
and zip bottom closed.
79” x 91” Flat-Top 79” x 91” Flat-Top
79” x 101” Arch-Top
Foot push button holes
face forward
Foot push button holes
face backward
Foot push button holes
face backward
1
23
4
5
6
7
8
9101112
13
14
15
16
12
34
5
6
7
8
9101112
13
14
15
16
12
34
5
6
7
8
9101112
13
14
15
16
1. Matching the numbered stickers,
assemble the frame as seen in Diagram A.
2. Attach monitor bracket plate on the
horizontal support bars using four bolts,
spacers, and washers.
6. Hang the monitor in place via the
vertical bar hooks and tighten the safety
screws on the bottom.
Diagram A
Ensemble 40” Accessory Panel with Monitor Mount
Assembly Instructions
4. Attach arch frame to any 91” tall
at-top Ensemble frame using two clips.
3. Pull the fabric graphic over the frame
and zip up the bottom. Attach Feet to the
bottom of the frame.
5. Attach the monitor bracket vertical
bars to the back of the frame with the
correct screw size for your monitor.
Tilt
Knob
Hook
Top
Safety
Screw
Compatible with monitors
up to 43” and 25 lbs.
lbs
1. Matching the numbered stickers,
assemble the frame as seen in Diagram A.
2. Pull the fabric graphic over the frame
and zip up the bottom. Attach Feet to the
bottom of the frame.
3. Attach arch frame to any 91”tall
at-top Ensemble frame using two clips.
Diagram A
Ensemble 30” Accessory Panel with Shelves
Assembly Instructions
4 . Clip the shelf brackets to the left and
right sides of the frame.
5. Set the shelf onto the brackets and
make sure it’s level. Attach the shelf with
two knobs through the brackets.
Shelf
Bracket
Shelf
Knob
Weight on shelves must not
exceed 11 lbs per shelf.
lbs
