Directed Electronics Automate 640M User manual

Model SSKR

Automate®Vehicle Anti-Theft System

OOwwnneerr’’ssGGuuiiddee

limited lifetime consumer warranty

Directed Electronics, Inc. promises to the original purchaser to repair or replace with a

comparable reconditioned model any Directed Electronics, Inc. unit (hereafter the

"unit"), excluding without limitation the siren, the remote transmitters, the associated

sensors and accessories, which proves to be defective in workmanship or material under

reasonable use during the lifetime of the vehicle provided the following conditions are

met: the unit was professionally installed and serviced by an authorized Directed

Electronics dealer; the unit will be professionally reinstalled in the vehicle in which it was

originally installed by an authorized Directed Electronics dealer; and the unit is returned

to Directed Electronics, Inc., shipping prepaid with a legible copy of the bill of sale or

other dated proof of purchase bearing the following information: consumer's name, tele-

phone number and address; the authorized dealers name, telephone number and address;

complete product description, including accessories; the year, make and model of the

vehicle; vehicle license number and vehicle identification number. All components other

than the unit, including without limitation the siren, the remote transmitters and the

associated sensors and accessories, carry a one-year warranty from the date of purchase of

the same. This warranty is non-transferable and is automatically void if: the original pur-

chaser has not completed the warranty card and mailed it within ten (10) days of the date

of purchase to the address listed on the card; the unit's date code or serial number is

defaced, missing or altered; the unit has been modified or used in a manner contrary to

its intended purpose; the unit has been damaged by accident, unreasonable use, neglect,

improper service, installation or other causes not arising out of defects in materials or con-

struction. The warranty does not cover damage to the unit caused by installation or

removal of the unit. Directed Electronics, Inc., in its sole discretion, will determine what

constitutes excessive damage and may refuse the return of any unit with excessive damage.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES,

INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WAR-

RANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR

PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL

PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED ELECTRONICS,

INC. NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO

ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION

WITH ITS PRODUCTS. DIRECTED ELECTRONICS, INC. DISCLAIMS AND

HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PAR-

TIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED

ELECTRONICS, INC. SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE

DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED ELECTRONICS, INC.

IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM,

DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;

AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,

INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE

AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS

FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR

ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A

CLAIM OR A DISPUTE INVOLVING DIRECTED ELECTRONICS, INC. OR ITS

SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE

STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FED-

ERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM

RECOVERY UNDER ANY CLAIM AGAINST DIRECTED ELECTRONICS, INC.

SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED ELEC-

TRONICS DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED ELEC-

TRONICS, INC. SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHAT-

SOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL

DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME,

LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTU-

NITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFAC-

TURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE

CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations

on how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights and you may also have

other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your

authorized Directed Electronics dealer for details of the plan or call Directed

Electronics, Inc. Customer Service at 1-800-876-0800. Directed Electronics, Inc.

security systems, including this unit, are deterrents against possible theft. Directed

Electronics, Inc. is not offering a guarantee or insurance against vandalism, damage or

theft of the automobile, its parts or contents; and hereby expressly disclaims any

liability whatsoever, including without limitation, liability for theft, damage and/or

vandalism. Directed Electronics, Inc. does not and has not authorized any person or

entity to create for it any other obligation, promise, duty or obligation in connection

with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

limited lifetime consumer . . . . .

warranty . . . . . . . . . . . . . . . . . . . .i

trademarks and copyrights . . . . .1

important information . . . . . . . . .2

fcc/id notice . . . . . . . . . . . . . . . . . .2

automate® vehicle anti-theft . .

system . . . . . . . . . . . . . . . . . . . . . .3

Standard Transmitter . . . . . . . . . .

Configuration . . . . . . . . . . . . . . . .3

Using Your System . . . . . . . . . . . .4

Arming . . . . . . . . . . . . . . . . . .4

Disarming . . . . . . . . . . . . . . . .4

Valet® Mode . . . . . . . . . . . . . . . .4

To Enter Valet® Mode . . . . . . .5

To Exit Valet® Mode . . . . . . . .5

Customer Override Mode . . . . . .6

contents

trademarks and copyrights

Code-Hopping™, Directed®, Doubleguard®, FailSafe®, Nuisance Prevention Circuitry®, NPC®,

Silent Mode™, Soft Chirp®, Stealth Coding™, Stinger®, Valet®, and Warn Away®are all

Trademarks or Registered Trademarks of Directed Electronics, Inc.

important information

Congratulations on the purchase of your anti-theft system. Due to the

complexity of this system, it must be installed by an authorized dealer

only. Installation of this product by anyone other than an authorized

dealer voids the warranty. All dealers are provided with a preprinted

dealer certificate to verify that they are authorized.

By carefully reading this Owner's Guide prior to using your system, you

will maximize the use of this system and its features.

You can print additional or replacement copies of this manual by

accessing the Directed web site at www.directed.com.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is subject to

the following conditions: (1) This device may not cause harmful inter-

ference, and (2) This device must accept any interference received,

including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsi-

ble for compliance could void the user’s authority to operate this device.

Tested to Comply

with FCC Standards

Directed Electronics, Inc. SSKR Series

automate®vehicle anti-theft system

The Automate®Anti-Theft System is designed to protect your new vehi-

cle investment and keep your new vehicle where you parked it. A state-

of-the-art electronic system, it incorporates the latest in Radio

Frequency (RF) immobilizer technology, and seamlessly integrates with

the vehicle to protect it from car thieves. Convenient, hidden and easy

to use, the Automate®Vehicle Anti-Theft system operates with the push

of a button to provide remote control protection around the clock.

Standard Transmitter Configuration

controls manual arming of your anti-theft system.

controls disarming of your anti-theft system.

and pressed simultaneously controls Valet®mode.

Using Your System

Arming

Your anti-theft system is programmed to arm itself automatically (called

passive arming). Your anti-theft system will automatically arm 30-sec-

onds after the ignition is turned off.

If you prefer to arm your system with the transmitter, you may press the

button on your transmitter after the IGNITION is turned OFF.

Your system will arm and prevent your vehicle from starting.

Disarming

To disarm your anti-theft system, press the button on your trans-

mitter. Your vehicle should now start.

Note: If more than 30-seconds elapses after pressing the button

on your transmitter, your system will automatically arm again. You will

have to disarm your system again to start your vehicle.

Valet®Mode

You can prevent the system from automatically arming by using Valet®

mode. This mode is useful when having the vehicle washed or serviced.

In Valet®mode, the system will not passively arm allowing the vehicle

to start.

To Enter Valet®Mode

1. Your vehicle should be able to start and the ignition must be

ON.

2. Turn the IGNITION key to the OFF position and then to the

START position and HOLD.

3. While holding the IGNITION key, within 2-seconds, simulta-

neously press buttons and on your transmitter.

4. Wait 30-seconds and start the vehicle a few times to ensure

the system is in Valet®mode.

Your vehicle is now in Valet®mode, allowing the vehicle to start until

Valet®mode is exited.

To Exit Valet®Mode

1. Turn the IGNITION key to the START position and HOLD.

2. Simultaneously press buttons and once on your

transmitter. This will exit Valet®mode.

3. Turn the IGNITION key to the OFF position and wait for at

least 30-seconds.

4. Attempt to start the vehicle. The vehicle should NOT start

indicating your system has entered the armed state and is

active.

Customer Override Mode

If your transmitter is lost or does not operate your system, you can

override the system to allow you to start the vehicle. This feature will

only work for ONE start (cycle). Bring your vehicle to the dealer for ser-

vicing of the anti-theft system.

Cycle the IGNITION key from the OFF position to the START position 7-

times and then HOLD on the 8th turn. After 2-seconds the system should

disarm allowing you to drive the vehicle.

The company behind this system is Directed Electronics, Inc.

Since its inception, Directed Electronics has had one purpose, to provide consumers with

the finest vehicle security and car stereo products and accessories available. The recipient of

nearly 100 patents and Innovations Awards in the field of advanced electronic

technology, DIRECTED is ISO 9001 registered.

Quality Directed Electronics products are sold and serviced throughout North America

and around the world.

Call ((880000))227744--00220000for more information about our products and services.

Directed Electronics, Inc.

Vista, CA 92081

www.directed.com

G640M 06-04

Directed Electronics is committed to delivering world class quality products

and services that excite and delight our customers.

This manual suits for next models

Table of contents

Other Directed Electronics Car Alarm manuals

Directed Electronics

Directed Electronics 4100 User manual

Directed Electronics

Directed Electronics Python 533 User manual

Directed Electronics

Directed Electronics Hornet 719T User manual

Directed Electronics

Directed Electronics Viper 4704 User manual

Directed Electronics

Directed Electronics Python 571XP User manual

Directed Electronics

Directed Electronics Cyber 130XV User manual

Directed Electronics

Directed Electronics Clifford 12.2X User manual

Directed Electronics

Directed Electronics Security System and Convenience 125xv User manual

Directed Electronics

Directed Electronics 200 User manual

Directed Electronics

Directed Electronics Hornet 740T User manual

Directed Electronics

Directed Electronics 4400 User manual

Directed Electronics

Directed Electronics 446 Series User manual

Directed Electronics

Directed Electronics 592 User manual

Directed Electronics

Directed Electronics 625 User manual

Directed Electronics

Directed Electronics 2100 User manual

Directed Electronics

Directed Electronics Viper 140 HF User manual

Directed Electronics

Directed Electronics G322R Quick start guide

Directed Electronics

Directed Electronics AVITAL 3001L User manual

Directed Electronics

Directed Electronics Python 990 User manual

Directed Electronics

Directed Electronics 700 ESP User manual

Directed Electronics

Directed Electronics Python 460HP User manual

Directed Electronics

Directed Electronics PYTHON 333 User manual

Directed Electronics

Directed Electronics 300 ESP User manual

Directed Electronics

Directed Electronics Viper 5601 User manual

Popular Car Alarm manuals by other brands

Clifford

Clifford 3606X owner's guide

Ultra Start

Ultra Start 2500M SERIES install guide

Ultra Start

Ultra Start 650 Series owner's manual

Audiovox

Audiovox Prestige Platinum+ APS-511C owner's manual

Sparkrite

Sparkrite SRA8 Guide

Viper

Viper 4708V owner's manual

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Installation and maintenance manual

Falcon

Falcon Predator XL3 Installer manual

Audiovox

Audiovox Auto Security XR91 Programming guide

Clifford

Clifford Sabre II owner's manual

CrimeStopper

CrimeStopper CS-8717 Wiring diagram

Ultra Start

Ultra Start 450 SERIES install guide

Scytek electronic

Scytek electronic Vectra X3 product manual

Excalibur

Excalibur AL-1860-EDPB Operation guide

Clifford

Clifford CYBER 2 owner's manual

Gemini

Gemini 7057 user manual

FlashLogic

FlashLogic FLRSBA PRESTIGE Product guide

Magicar

Magicar FAI-440 manual
