Dimplex Lee LEE20 User guide

580

Rhone Model: RNE20

280

730

280 580

730

Lee Model: LEE20

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.

Dimensions

(millimetres)

InstallationandOperatingInstructions

Dimplex Lee & Rhone

Models : LEE20 and RNE20 08/18989/1 Issue 1

Important Safety Advice:

When using electrical appliances, Basic precautions

should always be followed to reduce the risk of fire,

electrical shock, and injury to persons, including the

following:

••

•If the appliance is damaged, check with the

supplier before installation and operation.

••

•Do not use outdoors.

••

•Do not use in the immediate surroundings of a

bath, shower or swimming pool.

••

•Do not locate the heater immediately below a

fixed socket outlet or connection box.

••

•Do not cover the heater. Do not place material or

garments on the heater, or obstruct the air

circulation around the heater, for instance by

curtains or furniture, as this could cause

overheating and a fire risk.

••

•The appliance is not intended for use by young

children or infirm persons without supervision.

•Young children or infirm persons should be

supervised to ensure that they do not play with

the appliance.

••

•Ensure that furniture, curtains or other

combustible material are positioned no closer

than 1 metre from the heater.

••

•In the event of a fault unplug the heater.

••

•Unplug the heater when not required for long

periods.

••

•Although this heater complies with safety

standards, we do not recommend its use on deep

pile carpets or on long hair type of rugs.

••

•The appliance must be positioned so that the

plug is accessible.

••

•If the power cord is damaged it must be replaced

by the manufacturer or service agent or a

similarly qualified person in order to avoid a

hazard.

General

Unpack the heater carefully and retain the packaging for possible

futureuse,intheeventofmovingorreturningthefiretoyoursupplier.

These models are fitted with castors and handles so they can moved

from room to room with ease, and are normally positioned against a

wall.

A choice of 1kW or 2kW heat output is provided by the fan heater,

which is located at the bottom of the unit.

Before connecting the heater check that the supply voltage is the

same as that stated on the heater.

Please note: Used in an environment where background

noise is very low, it may be possible to hear a sound which

is related to the operation of the flame effect. This is normal

and should not be a cause for concern.

Electrical

WARNING: THIS APPLIANCE MUST BE EARTHED.

This fire is suitable for operation on anAC~ electricity supply having

the same voltage as that shown on its rating label.

Before switching on, please read the safety warnings and

operating instructions.

Model Specification

Fig. 1

LEE20 2kW Portastove, Log,

Thermostat, & Dimmer -

Silver

RNE20 2kW Portastove, Log,

Thermostat, & Dimmer -

Black

(AUS/NZ)

After Sales Service

Please see the separate Warranty leaflet for details of your Warrantee

& after sales service including contact details.

Should you require after sales service, please get in touch with the

supplier through whom you purchased the appliance, or the contact

number on your Warranty leaflet.

Using the Thermostat

Plug in and set all switches to ON. Turn the thermostat knob to MAX

to warm the room rapidly. When the room temperature has reached

the desired level, turn the thermostat knob back slowly until the

thermostat just clicks off. The heater will then maintain the room

temperature at the chosen level - see Fig. 2.

NOTE – Should your heater fail to come on when the thermostat is at

a low setting, this may be due to the room temperature being higher

than the thermostat setting.

Using the Flame control

This unique effect may be enjoyed whether or not the heating elements

are in operation.

Brightness and flame effect control gives a choice of light and flame

setting. At minimum setting, the flame effect and the fuel brightness

will be lowest, indicated by a small bulb symbol on the control panel.

Clockwise rotation of knob will increase the intensity of the effect

(indicated by bulb symbols increasing in size) – see Fig 2.

The heater controls are located behind the flap on the front of the

heater. (see Fig 1)

Three switches provide a choice of heat settings. A switch is in the

ON position when the side with the markings on (i.e. I, I, or II ) is

pushed in - see Fig. 2.

Controls

Maintenance

WARNING – BEFORE UNDERTAKING ANY MAINTENANCE OR

CLEANING REMOVE PLUG OR DISCONNECT FROM THE

ELECTRICITY SUPPLY.

To gain access to the lamps,

the four screws which se-

cure the back panel, must

be removed. Remove and

slide out panel as indicated

on Fig. 4

Two lamps are located behind the back panel as indicated in Fig.3.

Fig. 3

Fig. 4

Remove the defective lamp by unscrewing it as shown - see Fig. 5.

Replace with a 60W E14 SES Clear Candle lamp.

Take care not to over-tighten the lamp. Refit the back panel and

secure with the four screws.

Fig.5

Safety cut-out

An automatic cut-out will switch off the heater if for any reason it

overheats. This could occur for instance, if the air inlet or outlet were

restricted in any way. If the cut-out operates, the heater will switch off.

The heater will switch on once the obstruction has been removed and

the heater has cooled. If the cut-out continues to operate intermittently,

the heater should be switched off and Customer Services contacted

Cleaning

For general cleaning use a soft clean duster – never use abrasive

cleaners. The viewing screen should be cleaned carefully with a soft

cloth. DO NOT use proprietary glass cleaners.

Lamp Replacement

II II

max

min

Flame control

knob Thermostat control

knob

Switches

321

Fig. 2

Switch 1 ( I )

Switch 2 ( I)

Switch 3 ( II )

Controls the electricity supply to the heater

and flame effect.

Note: This switch must be in the ON ( I )

position for heater to operate with or without

heat.

Provides 1kW heat output - thermostatically

controlled.

Provides 2kW output with switch 2 -

thermostatically controlled.

The product complies with theAustralian/New Zealand Safety StandardsAS/NZ S 335.2.30:1997 and 2002 Part 1 also the European Standard ElectromagneticCompatibility

(EMC) EN 55 014-1:1993, EN 61000-3-2:1995, EN 61000-3-3:1995, EN 55 014-2:1997 which cover the essential requirements of EEC Directive 89/336/EEC.

Specification subject to change without prior notice.
