Dimplex DFB6016 Quick start guide

PARTS & SERVICE MANUAL

FOR THE 30”

ELECTRIC FIREPLACE

MODEL NUMBER

DFB6016

TABLE OF CONTENTS

OPERATION PAGE2

PARTS DRAWING PAGE 4

PARTSLIST PAGE5

WIRING DIAGRAM PAGE 6

LIGHT BULB REPLACEMENT PAGE 7

LED/SWITCH HARNESS REPLACEMENT PAGE 9

LIGHT DIMMER SWITCH REPLACEMENT PAGE 10

FLAME SPEED CONTROL REPLACEMENT PAGE 11

FLAME MOTOR/FLAME ROD REPLACEMENT PAGE 12

HEATER ON/OFF SWITCH REPLACEMENT PAGE 14

HEATER ASSEMBLY REPLACEMENT PAGE 15

CIRCUIT BOARD REPLACEMENT PAGE 17

POWER CORD REPLACEMENT PAGE 18

OPEN

EF3003, SF3003, DF3003

OPERATION

Initializing The Remote Control

1. Turn on the electrical power at the circuit breaker.

2. Slide open the battery cover on the back of the remote transmitter.

3. Install one 9 volt battery into the remote control. Replace the battery cover.

Remote Control Operation

The fireplace is supplied with a radio frequency remote control. This remote control has

a range of approximately 50 feet. (15.25 m), it does not have to be pointed at the

fireplace and can pass through most obstacles (including walls). It is supplied withone

of 243 independent frequencies to prevent interference with other units. The frequency

designation is indicated on the back of the transmitter.

Remote Control Initialization

This procedure is required every time there is a loss of power to the remote control in

the fireplace. (ie. Power failure, breaker tripped, main power switch is turned off)

1. Ensure that the power is supplied through the main service panel.

2. Locate manual controls (refer to fig. 1)

3. Activate main power switch (“_” position) red indicator light 1will flash.

4. Press and hold manual selection switch for five seconds (“_” position) UNTIL the

second red indicator light flashes.

5. Press ON button located on the remote control transmitter (fig. 2). This will

synchronize the remote control transmitter and receiver.

The remote control operates the fireplace levels sequentially. The level is increased

every time the ON button on the transmitter is pressed. The fireplace can be turned off

at any point by pressing the OFF button on the remote control transmitter.

Electric Fireplace Manual Controls

A. Manual on/off switch

1. The fireplace has a manual power ON/OFF switch located on the control panel of

the fireplace.

2. To operate press the switch once, to turn the unit on. Press the switch again to turn

the unit off.

B. Flame brightness control

Turn the flame brightness control knob to increase or decrease the brightness of the

flame and embers.

C. Flame action control

Turn the flame action control knob to adjust the flame speed control to the desired level.

D. Manual Selection Switch

To choose between the flame effect setting, flame effect with low heat setting, and

flame effect with high heat setting.

RESETTING THE TEMPERATURE CUTOFF SWITCH

Should the heater overheat, an automatic cut out will turn the heater off and it will not

come back on without being reset. It can be reset by switching the MAIN ON/OFF

SWITCH to OFF and waiting 5 minutes before switching the unit back on.

CAUTION

If you need to continuously reset the heater, unplug the unit and call Dimplex North

America Limited at 1-800-668-6663.

DFB6016

REPLACEMENT PARTS

FIREBOX, 30” – Dimplex

CATALOGUE NO. DFB6016

PART NO. 6901110559

REPLACEMENT PART

1. 30” LOG SET ASSEMBLY 0438550100RP

2. MOTOR, ASSEMBLY 1200W,980RPM 2200490200RP

3. WIRE ASSY LAMPHOLDER 4 SOCKET 2500190500RP

4. UPPER WIRE ASSY LAMPHOLDER 2 SOCKETS 4200090100RP

5. ON/OFF SWITCH 2800070200RP

6. REMOTE CONTROL RECEIVER 3 STAGE 3000430800RP

7. REMOTE CONTROL SENDER 3 STAGE (Not Shown) 3000370300RP

8. FLAME SPEED 3000240100RP

9. FLAME MOTOR 3000240200KIT

10. CONTROL, DIMMER 3000250100RP

11. CORD SET 4100040500RP

12. REFLECTOR ASSY 5900080700RP

13. MIRROR 5900300400RP

14. FRONT GLASS 5900310300RP

15. FLAT BLACK KNOB 8800000200RP

16. HEAT SWITCH 2800070500RP

WIRING DIAGRAM

DFB6016

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Light bulbs need to be replaced when you notice a dark section of the flame. There are

four bulbs under the log set which generate the flames and embers.

It is a good idea to replace all of the light bulbs at one time if they are close to the end of

their rated life. Group replacement will reduce the number of times you need to open

the unit to replace the light bulbs.

LOWER BULB REPLACEMENT

1. Remove the trim by turning the retaining fasteners counter clockwise ¼ turn until the

trim releases from the firebox using a slotted screwdriver. (FIGURE 1)

2. Hold the glass in place while removing the retaining clip from the upper center of the

firebox.

3. Lift glass out and store in a safe place.

4. Lift up the front edge of the log until it clears the front tabs. Pull out until the rear tab

clears the back ledge, then lift out.

5. Examine the bulbs to determine which bulbs require replacement.

6. Hold the socket while unscrewing the bulb.

7. Hold the socket while screwing in the new bulb.

8. Replace the log emberbed by placing the back lip of the log emberbed under the

mirror then push the front of the log emberbed down into the recess.

LOWER LIGHT BULB REQUIREMENTS

Quantity of 4 clear chandelier or candelabra bulbs with an E-12 (small) socket base,

60 watt rating.

FIGURE 1

DFB6016

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Light bulbs need to be replaced when you notice a dark section of the flame. There are

four bulbs under the log set which generate the flames and embers.

It is a good idea to replace all of the light bulbs at one time if they are close to the end of

their rated life. Group replacement will reduce the number of times you need to open

the unit to replace the light bulbs.

UPPER BULB REPLACEMENT

1. Remove the trim by turning the retaining fasteners counter clockwise ¼ turn until the

trim releases from the firebox using a slotted screwdriver. (FIGURE 1)

2. Hold the glass in place while removing the retaining clip from the upper center of the

firebox.

3. Lift glass out and store in a safe place.

4. Locate the two upper bulbs inside the firebox at the top.

5. Examine the bulbs to determine which bulbs require replacement.

6. Hold the socket while unscrewing the bulb.

7. Hold the socket while screwing in the new bulb.

UPPER LIGHT BULB REQUIREMENTS

Quantity of 2 clear chandelier or candelabra bulbs with an E-12 (small) socket base,

15 watt rating.

DFB6016

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE LED/SWITCH HARNESS

1. Remove the trim by turning the retaining fasteners counter clockwise ¼ turn until the

trim releases from the firebox using a slotted screwdriver.

2. Remove the firebox from mantel.

3. Lower the grill covering the controls.

4. Remove the (10) retaining screws on the top cover and remove the top being careful

not to damage any of the wiring.

5. Locate the main on/off switch mounted on the top panel and disconnect the wiring

clips and connections noting their original locations.

6. Depress the retainer clips on the rear of the switch and push the switch out of the

rear of the cover.
