Dimplex BLF74 User manual

10309-1

Cat. No.

Notes

Section 10309 –Manufactured Electric Fireplaces

PART 1 GENERAL

1.1 SECTION INCLUDES

A. Manufactured electric fireplaces.

B. Accessories.

1.2 RELATED SECTIONS

A. Section 06100 - Rough Carpentry: Wood framed rough opening and enclosure.

1.3 REFERENCES

A. UL - 2021

B. CSA - C22.2 No. 46

1.4 SUBMITTALS

A. Submit under provisions of Section 01300.

B. Product Data: Manufacturer's data sheets on each product to be used, including:

1. Preparation instructions and recommendations.

2. Storage and handling requirements and recommendations.

3. Installation methods.

C. Manufacturer's Certificates: Certify products meet or exceed specified requirements.

D. Manufacturer’s warranty.

1.5 DELIVERY, STORAGE, AND HANDLING

A. Store products in manufacturer's unopened packaging until ready for installation.

B. Protect materials from exposure to moisture. Do not deliver until after wet work is

complete and dry.

1.6 WARRANTY

A. Provide the manufacturers 2 year limited warranty on electrical components.

PART 2 PRODUCTS

2.1 ACCEPTABLE MANUFACTURERS

A. Pre-fabricated Electric Fireplace:

1. Base: Dimplex Electric Fireplace

Dimplex North America

1367 Industrial Road

Cambridge ON N1R 7G8

1-888-DIMPLEX

www.dimplex.com

[email protected]

10309-2

Cat. No.

Notes

Section 10309 –Manufactured Electric Fireplaces

2. Substitutions not permitted

3. Requests for substitutions will be considered in accordance with provisions of

Section 01600.

2.2 ELECTRIC FIREPLACES

A. General:

1. Provide all components and accessories required for a complete, functional unit.

2. UL or CSA listed.

B. Pre-fabricated Electric Fireplace:

1. Base Product:

a) Dimplex Electric Fireplace

b) Model Number: BLF74

2. Description: Realistic 74” wall-mounted electric fireplace

3. Dimensions:

a) Width: 74-1/4”

b) Height: 19-1/2”

c) Depth: 7-1/2”

4. Framing Dimensions:

Fully Recessed:

a) Width: 73”

b) Height: 18-1/2”

c) Depth: 7-1/4”(2 x 8 framing)

5. Electrical:

a) Volts: 120 / 240

b) Watts: 1,230 / 2,430

c) BTUs: 4,197 / 8,290

d) Amps: 10.3 / 10.1

6. Venting: Non-venting

7. Operation: Flame only, flame and heat

8. Heating: Louver-less, fan-forced circulation

9. Liner: Steel

10. Standard features:

a) Flame/ember bed on/off

b) Tumbled glass media ember bed

c) LED flame technology

d) On-demand fan-forced heater

e) Direct wire capabilities - 120V & 240V

11. Control options:

a) On/off remote control

b) Wall switch remote control kit

c) On-board manual on/off switch

10309-3

Cat. No.

Notes

Section 10309 –Manufactured Electric Fireplaces

PART 2 EXECUTION

1. INSPECTION

A. Do not begin installation until substrates have been properly prepared.

B. If substrate preparation is the responsibility of another installer, notify Architect of

unsatisfactory preparation before proceeding.

C. Verify proper power supply and fuel source are available.

2. PREPARATION

A. Clean surfaces thoroughly prior to installation.

B. Prepare surfaces using the methods recommended by the manufacturer for achieving

the best result for the substrate under the project conditions.

3. INSTALLATION

A. Install in accordance with manufacturer's instructions and requirements of authorities

having jurisdiction.

B. Use manufacturer's guidelines for minimum clearances to combustibles, walls, and

finishes.

C. Anchor all components firmly in position for long life under hard use.

D. Upon completion of installation, visually inspect all exposed surfaces. Touch up

scratches and abrasions with touch up paint recommended by the manufacturer;

make imperfections invisible to the unaided eye from a distance of 5 feet (1.5 m).

4. PROTECTION

A. Protect installed products until completion of project.

B. Touch-up, repair or replace damaged products before Substantial Completion.

END OF SECTION
