Denver BTL-63 User manual

BTL-63

Denver.eu

10/2023

Safety information

Please read the safety instructions carefully before

using the product for the first time and keep the

instructions for future reference.

1.This product is not a toy. Keep it out of reach of

children.

2.Warning: This product includes lithium polymer

batteries.

3.Keep product out of the reach of children and pets

to avoid chewing and swallowing.

4.Product operating and storage temperature is from

0 degree Celsius to 40 degree Celsius. Under and over

this temperature might affect the function.

5.Never open the product. Touching the inside

electrics can cause electric shock. Repairs or service

should only be performed by qualified personnel.

6.Do not expose to heat, water, moisture, direct

sunlight!

7.Please protect your ears against loud volume. Loud

volume can damage your ears and risk in hearing

loss.

8.Bluetooth wireless technology operates within a

range of about 10 m (30 feet). The maximum

communication distance may vary depending on the

presence of obstacles (people, metal objects, walls,

etc.) or the electromagnetic environment.

9.Microwaves emitting from a Bluetooth device may

affect the operation of electronic medical devices.

10.The unit is not waterproof. If water or foreign

objects enter the unit, it may result in fire or electric

shock. If water or a foreign object enters the unit,

stop use immediately.

11.Only charge with supplied USB cable.

12.Do not use non original accessories together with

the product as this can make the product

functionality abnormal.

Scope of Supply

Speaker x 1

Type-C charging cable x 1

Aux-in cable x 1

User manual x 1

Technical Data

Bluetooth version: V5.3

Rated input: 5V-500mA

Speaker: 2 x 3W

Battery: 1200mAh

Frequency range: 100 Hz – 18 KHz

Bluetooth working distance: up to 10 meters

Product Overview

1.Mode for Bluetooth,Aux-in,TF/Handsfree

2.VOL- button/Previous track

3.VOL+ button/Next track

4.Power ON&OFF/Play&Pause

(Double press for TWS connection)

5.Lighting Mode

6.AUX in port

7.Micro SD/TF card slot

8.USB-C charging port

Powering On/Off

To turn the unit on and off, long press the ON/OFF

button.

Charging the Battery

Please use the provided Type-C cable for charging.

Plug the Type-C end into the Type-C port of the unit

and the other end into the USB port of a PC, wall

charger, or other 5 V chargers.

Playing mp3 files from microSD devices

1.Insert the Micro SD card into the TF slot.

2.Play, pause or skip a selected track using the

controls on the speaker.

Bluetooth Operation

If you have used Bluetooth connection before, the

system will search for the device last connected.

When the device is found, the system will reconnect

automatically.

Pairing a Bluetooth Device for the First Time

1.Turn the unit on. You’ll hear an alert tone.

2.Turn on your external device. Refer to its user

manual for instructions on pairing and connecting

Bluetooth devices.

3.Using the controls on your Bluetooth device, select

“Denver BTL-63” in your Bluetooth settings to pair.

4.When successfully paired and connected, the unit

will emit an alert tone. After the initial pairing, the

unit will stay paired unless unpaired manually by the

user.

Cautions

1.Do not use abrasive cleaners to clean this product.

2.Keep this product away from fire or heat sources,

such as cooking stoves.

3.Do not expose this product to direct sunlight for a

long time.

4.Do not throw this product into the fire to avoid an

explosion.

5.Never attempt to disassemble or modify this

product, as it contains no after-service components.

6.Do not use this product in the rain.

7.If you do not plan to use this product for a long

time, please store it in a dry environment and charge

the speaker at least once a month to extend its life

and avoid extreme temperatures and dust.

Please notice - All products are subject to change

without any notice. We take reservations for errors

and omissions in the manual.

Electric and electronic equipment and included

batteries contains materials, components and

substances that can be hazardous to your health and

the environment, if the waste material (discarded

electric and electronic equipment and batteries) is

not handled correctly.

Electric and electronic equipment and batteries is

marked with the crossed out trash can symbol, seen

above. This symbol signifies that electric and

electronic equipment and batteries should not be

disposed of with other household waste, but should

be disposed of separately.

As the end user it is important that you submit your

used batteries to the appropriate and designated

facility. In this manner you make sure that the

batteries are recycled in accordance with legislature

and will not harm the environment.

All cities have established collection points, where

electric and electronic equipment and batteries can

either be submitted free of charge at recycling

stations and other collection sites, or be collected

from the households. Additional information is

available at the technical department of your city.

Hereby, Denver A/S declares that the radio

equipment type Denver BTL-63 is in compliance with

Directive 2014/53/EU. The full text of the EU

declaration of conformity is available at the following

internet address: denver.eu and then click the search

ICON on topline of website. Write model number:

Denver BTL-63 Now enter product page, and RED

directive is found under downloads/other

downloads.

Operating Frequency Range: 2.402-2.480 GHz

Max Output Power: 2x30W/2x3W RMS

DENVER A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

www.facebook.com/denver.eu

Version 1.1

Contact

Nordics

Headquarter

Denver A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

Phone: +45 86 22 61 00

(Push “1” for support)

E-Mail

For technical questions, please write to:

support.hq@denver.eu

For all other questions please write to:

contact.hq@denver.eu

Benelux

DENVER BENELUX B.V.

Barwoutswaarder 13C+D

3449 HE Woerden

The Netherlands

Phone: 0900-3437623

E-Mail: support.nl@denver.eu

Spain/Portugal

DENVER SPAIN S.A

Ronda Augustes y Louis Lumiere, nº 23 – nave 16

Parque Tecnológico

46980 PATERNA

Valencia (Spain)

Spain

Phone: +34 960 046 883

Mail: support.es@denver.eu

Portugal:

Phone: +35 1255 240 294

E-Mail: denver.service@satﬁel.com

Germany

Denver Germany GmbH Service

Max-Emanuel-Str. 4

94036 Passau

Phone: +49 851 379 369 40

E-Mail

support.de@denver.eu

Fairﬁxx GmbH

Repair and service

Rudolf-Diesel-Str. 3 TOR 2

53859 Niederkassel

(for TV, E-Mobility/Hoverboards/Balanceboards,

Smartphones & Tablets)

Tel.: +49 851 379 369 69

E-Mail: denver@fairﬁxx.de

Austria

Lurf Premium Service GmbH

Deutschstrasse 1

1230 Wien

Phone: +43 1 904 3085

E-Mail: denver@lurfservice.at

If your country is not listed above,

please write an email to

support@denver.eu

DENVER A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

denver.eu

facebook.com/denver.eu
