AboutYourProjector:Dell™3300MPProjector

Features

Equipment

Main Unit

Control Panel

Connection Ports

Remote Control



Features



Singlechip0.7"TexasInstrumentsDLP™technology

High contrast, double data rate (DDR) digital micro mirror device

True XGA (1024 x 768) native resolution

3.99 lbs (1.81 kg) lightweight compact design

1600 ANSI lumens brightness (Max)

1700:1 full on / full off contrast ratio

1.2x manual zoom lens

Built in 2W speaker

Auto image re-sizing (Auto-Sync) to 1024x 768 full screen with scaling compression compatibility for SXGA+, SXGA, XGA, SVGA,

VGA, MAC

Great connectivity -- Multiple PC and High Definition inputs (via M1-DA and RGB), S-Video, Composite Video (RCA), Component Video

Preset and user defined video modes for optimum video and graphic settings

LCD display for real time projector status

Self-diagnostic for video troubleshooting

State-of-the-art motion adaptive hardware de-interlacing with 3:2 and 2:2 pull down

180-watt user-replaceable P-VIP 3000-hour lamp

Eco Mode allows end user to extend lamp life to 5000 hours by reducing the lamp wattage and brightness.

Compatibility with Macintosh®computers

Compatibility with NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, and HDTV (1080i, 720p, 576i/p, 480i/p)

High-definition TV compatibility

User-friendly, multi-language on-screen display (OSD)

Advanced auto vertical electronic keystone correction

Remote projector control from PC via RS232 port

User-friendly control panel with backlight buttons

Drop tested carrying case included

Plug and play for photo image display from the option for memory card reader (Memory card module sold separately)

Equipment

Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell if anything is missing.



Main unit

3.0m Power cord

1.8m M1-A to D-sub/USB cable

2.0m S-video cable

1.8m M1-A to HDTV cable

1.8m Composite Video cable

http://www.pureglare.com.au

Batteries (2)

1.8m RCA to Audio cable

1.8m 1/8" Mini Phone Jack cable

Remote control



Dell 3300MP Projector

User's Guide

Dell 3300MP Projector Quick Start

Card

Warranty Guide

Owner's Manual

Carrying case

Main Unit



Control panel

LCD status display

Zoom tab

Focus ring

Lens

IR Remote control receiver

Elevator button

Control Panel

http://www.pureglare.com.au



Power button

Source

Keystone adjustment

Re-sync

Four directional keys

Keystone adjustment

Lamp warning light

Temperature warning light

Connection Ports



Kensington lock hole

RS232 connector

Audio input connector

Composite video connector

S-video connector

M1-DA connector

VGA Out (monitor loop-through)

IR Receiver

Remote Control

http://www.pureglare.com.au



Light

Directional Pad

Power button

R-sync button

PU button (page up)

Source button

Laser pointer

PD button (page down)

Hide button

Keystone correction

Mute button

Color Mode button

Volume+-button

Menu button

Freeze button

4:3/16:9 (aspect ratio) button

Normal button

Slide Show button

Preview button

Rotate button

CAUTION: The remote control has a Class II laser that emits radiation. To reduce the risk of injury to the eyes, do

not look directly into the laser light on the remote control and do not point the laser light into anyone's eyes.

Battery Disposal: Your projector remote control uses zinc-manganese batteries. If you need to replace the batteries, see your Dell 3300MP

Projector Quick Start Card.

Do not dispose of used batteries along with household waste. Contact your local waste disposal agency for the address of the nearest battery

deposit site.
