Dell EMC 40U-P User manual

Regulatory Model: 300-000-239

40U-P Cabinet

Unpacking and Setup Guide

Rev. Rev 02

July 2020

This Unpacking and Setup Guide contains information about the 40U-P cabinet. Topics include:

•Before you start .........................................................................................................................................................................................................2

•Tools required..............................................................................................................................................................................................................2

•Hardware acclimation.................................................................................................................................................................................................2

•Steps to unpack and setup cabinet..........................................................................................................................................................................3

•Remove the ramp and shipping material from the cabinet................................................................................................................................... 3

•Remove the cabinet shipping brackets....................................................................................................................................................................5

•Attach the unloading ramp........................................................................................................................................................................................ 6

•Roll the cabinet down the ramp................................................................................................................................................................................7

•Position and level the cabinet................................................................................................................................................................................... 8

•Power requirements...................................................................................................................................................................................................8

•Attach (optional) brackets........................................................................................................................................................................................11

•Install the lower trim strip.........................................................................................................................................................................................12

•Ground the cabinet................................................................................................................................................................................................... 13

•Repackaging shipping material (2-piece ramp kits only)......................................................................................................................................14

•If you need help......................................................................................................................................................................................................... 15

Before you start

This section contains important information you should read prior to unpacking and setting up the 40U-P cabinet.

CAUTION: Some products are designed for installation by trained service personnel only. Attempts by unqualified personnel to

set up and start certain products may result in system damage and may void product warranties. Contact your representative

for detailed warranty, installation, and initialization policies.

Please dispose of shipping material responsibly, and recycle wherever and whenever possible. Cabinet packaging that includes a collapsible

downloading ramp can be re-packaged and returned, as described in Repackaging shipping material (2-piece ramp kits only).

CL5427

NOTE: The illustrations in this guide are examples only. Depending on what you ordered, your configuration may look somewhat

different from what is shown here.

Tools required

• 9/16-in. (14-mm) socket wrench

• Adjustable wrench

• Flat screwdriver

• Phillips screwdriver

Hardware acclimation

Systems and components must acclimate to the operating environment before power is applied to them. Once unpackaged, the system

must reside in the operating environment for up to 16 hours to thermally stabilize and prevent condensation.

If the last 24 hours of the TRANSIT/STORAGE environment

was:

…and the OPERATING

environment is:

…then let the system or

component acclimate in the

new environment this many

hours:

Temperature Relative Humidity Temperature Acclimation Time

Nominal

68–72°F (20–22°C)

Nominal 40–55% RH Nominal

68–72°F (20–22°C) 40–55%

1 hour or less

Cold <68°F (20°C) Dry <30% RH <86°F (30°C) 4 hours

If the last 24 hours of the TRANSIT/STORAGE environment

was:

…and the OPERATING

environment is:

…then let the system or

component acclimate in the

new environment this many

hours:

Damp >30% RH

Hot >72°F (22°C) Dry <30% RH

Humid 30–45% RH

Hot >72°F (22°C) Humid 45–60% RH <86°F (30°C) 8 hours

Hot >72°F (22°C) Humid >60% RH <86°F (30°C) 16 hours

Unknown

IMPORTANT:

• If there are signs of condensation after the recommended acclimation time has passed, allow an additional eight (8) hours to stabilize.

• System components must not experience changes in temperature and humidity that are likely to cause condensation to form on or in

that system or component. Do not exceed the shipping and storage temperature gradient of 45°F/hr (25°C/hr).

• To facilitate environmental stabilization, open both front and rear cabinet doors.

Steps to unpack and setup cabinet

The steps to unpack, setup and repackage the shipping material are listed in the following table:

Step Task

1Remove the ramp and shipping material from the cabinet on page 3

2Remove the cabinet shipping brackets on page 5

3#unique_10

4Roll the cabinet down the ramp on page 7

5Position and level the cabinet on page 8

6Attach AC power input cords

7Attach (optional) brackets on page 11

8Install the lower trim strip on page 12

9Ground the cabinet on page 13

10 Repackaging shipping material (2-piece ramp kits only) on page 14

Remove the ramp and shipping material from the

cabinet

Steps

1. Remove any boxes and other material from the cabinet sides.

CL4691

2. Do not pull a ramp down from the top. To release the ramp from the pallet, grasp the ramp, pull it straight back toward you, then pull it

straight up to free it from the screws.

Accessory Kit

EMC3552

Rotated 90

Bracket

Screws

Rear

3. Remove the plastic covering from the cabinet.

Remove the cabinet shipping brackets

Steps

1. At the rear of the cabinet, remove the rear shipping bracket, by removing the bolts that go through the bracket to the cabinet and into

the pallet.

2. At the front of the cabinet, remove the bottom cabinet bezel, if necessary. Pull the bezel straight out to remove it.

3. Remove the bolts that attach the cabinet to the front shipping bracket. Your can leave the front bracket attached to the shipping

pallet.

NOTE:

Save the bolts. You may need them later to install optional stabilizer brackets.

Attach the unloading ramp

Steps

1. Insert the ramp brackets into the pallet notches in the rear of the pallet.

2. If your shipment includes a two-piece ramp, attach part A to the pallet and part B to part A.

CL4692

Roll the cabinet down the ramp

About this task

NOTE: Make certain the leveling feet are secured in the UP position before moving the cabinet. Secured feet allow the cabinet

to roll off the ramp and into position. If you need to adjust the leveling feet, use the 6mm hex key (top access) or an adjustable

wrench (bottom access) to turn the feet counter-clockwise. This raises them to the UP position.

EMC2845

Leveling

Feet

Rear

Rails

WARNING:

The cabinet is heavy. Make certain you have sufficient help and secure footing before rolling the cabinet onto the ramp.

ATTENTION! L'armoire est lourde. Assurez-vous d'obtenir l'aide d'une personne et d'avoir un point d'appui sûr avant d'installer

l'armoire sur la rampe.

ACHTUNG! Das Gestell ist schwer. Versichern Sie sich, dass Sie genügend Hilfe haben und dass das Fundament gesichert ist,

bevor Sie das Gestell auf die Rampe rollen.

ATTENZIONE! Poiché il cabinet è molto pesante assicurarsi di essere in un numero sufficiente di persone e di avere un appoggio

sicuro prima di spingerlo sullo scivolo.

ADVERTENCIA! El bastidor es pesado. Asegúrese de contar con ayuda suficiente y de tener un apoyo seguro antes de colocar

el bastidor en la rampa.

WARNING: Balance the cabinet from the sides; do not grasp the plastic bezels or other components on the front of the cabinet.

DO NOT STAND IN FRONT OF THE CABINET

EMC2846

Position and level the cabinet

About this task

EMC2847

1 3/8-in.

Power requirements

Depending on the cabinet configuration and input ac power source, single or three-phase, the cabinet requires two to 12 independent

power sources. To determine your site requirements, use the published technical specifications and device rating labels. This will help

provide the current draw of the devices in each rack. The total current draw for each rack can then be calculated. For Dell EMC products,

visit the "Dell EMC Power Calculator" on the web at http://powercalculator.dell.com.

Table 1. Single-phase power connection requirements

Specification North American

3 wire connection (2 L and 1 G)a

International and Australian

3 wire connection (1 L, 1 N, and 1 G)

Input nominal voltage 200 - 240 V ac +/- 10% L - L nom 220 - 240 V ac +/- 10% L - L nom

Table 1. Single-phase power connection requirements (continued)

Specification North American

3 wire connection (2 L and 1 G)a

International and Australian

3 wire connection (1 L, 1 N, and 1 G)

Frequency 50 - 60 Hz 50 - 60 Hz

Circuit breakers 30 A 32 A

Power zones Two Two

Power requirements at site (minimum to

maximum)

• One to six 30 A, single-phase drops per zone

• Each rack requires a minimum of two drops to a maximum of 12 drops. This will be

determined by the system configuration and the power needs for that configuration.

a. L = line phase, N = neutral, G = ground

Table 2. Single-phase AC power input connector options

Single-phase rack connector options Customer AC source interface receptacle Site

NEMA L6-30P NEMA L6-30R

North America and Japan

Russellstoll 3750DP

Russellstoll 9C33U0

North America and Japan

IEC-309 332P6

IEC-309 332C6

International

CLIPSAL 56PA332

CLIPSAL 56CSC332

Australia

Table 3. Three-phase AC power connection requirements

Specification North American (Delta)

4 wire connection (3 L and 1 G)a

International and Australian (Wye)

5 wire connection (3 L, 1 N, and 1 G)

Input nominal voltage 200 - 240 V ac +/- 10% L - L nom 220 - 240 V ac +/- 10% L - N nom

Frequency 50 - 60 Hz 50 - 60 Hz

Circuit breakers 50 A 32 A

Power zones Two Two

Power requirements at site (minimum to

maximum)

North America (Delta):

• One to two 50 A, three-phase drops per zone

• Each rack requires a minimum of two drops to a maximum of four drops. This will be

determined by the system configuration and the power needs for that configuration.

International (Wye):

Table 3. Three-phase AC power connection requirements (continued)

Specification North American (Delta)

4 wire connection (3 L and 1 G)a

International and Australian (Wye)

5 wire connection (3 L, 1 N, and 1 G)

• One 32 A, three-phase drop per zone

• Each rack requires a minimum of two drops to a maximum of four drops. This will be

determined by the system configuration and the power needs for that configuration.

NOTE: The interface connector options for the Delta and Wye three-phase PDUs

are listed in and

a. L = line phase, N = neutral, G = ground

Table 4. Three-phase Delta-type AC power input connector options

Three-phase Delta rack connector options Customer AC source interface receptacle Site

Russellstoll 9P54U2

Russellstoll 9C54U2

North America and International

Hubbell CS-8365C

Hubbell CS-8364C

North America

Table 5. Three-phase Wye-type AC power input connector options

Three-phase Wye rack connector options Customer AC source interface receptacle Site

GARO P432-6

GARO S432-6

International

Hubbell L22-30P Hubbell L22-30R North America

Fly Lead Customer Receptacle International
