Daikin RX-JV Instruction manual

RX-JV/GV

Wall Mounted Unit

Air Conditioners

Technical Data

www.daikin.eu

RX-JV-GV_EN.pdf 1 12/05/2010 8:21:31

RX-JV/GV

Wall Mounted Unit

Air Conditioners

Technical Data

www.daikin.eu

RX-JV-GV_EN.pdf 2 12/05/2010 8:21:48

• Split Sky Air • Outdoor Units 1

• Outdoor Units • R-410A • RX-JV/GV

TABLE OF CONTENTS

RX-JV/GV

1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Nominal Capacity and Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cooling/Heating capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5 Dimensional drawing & centre of gravity . . . . . . . . . . . . . . . . . . . . . . . 14

Dimensional drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6 Piping diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7 Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

8 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Sound pressure spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

9 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

RX-JV-GV_EN.pdf 3 12/05/2010 8:21:49

• Outdoor Units • R-410A • RX-JV/GV

• Split Sky Air • Outdoor Units

1 Features

OutdoorUni SplitSky RX-JV/GVR-410A

• Outdoor units for pair application

• Daikin outdoor units are neat and sturdy and can be mounted easily

on a roof or terrace or simply placed against an outside wall.

• Outdoor units are fitted with a swing compressor, renowned for its low

noise and high energy efficiency

• “Silent” buttons on the remote control lower the operation sound of

the outdoor unit by 3dBA.

• Inverter compressors continuously adjust compressor speed to

actual demand, fewer power - consuming starts and stops result in

decreased energy consumption (up tot 30%) and more stable

temperatures.

RX-JV-GV_EN.pdf 4 12/05/2010 8:21:49

• Split Sky Air • Outdoor Units 3

• Outdoor Units • R-410A • RX-JV/GV

2 Specifications

2-1 Nominal Capacity and Nominal Input RX20JV1B RX25JV1B RX35JV1B

For combination

indoor units +

outdoor units

Indoor Units FTX20JV1B FTX25JV1B FTX35JV1B

Cooling capacity Minimum kW 1.3

Btu/h 4,400

Kcal/h 1,120

Standard kW 2.0 2.5 3.3

Btu/h 6,800 8,500 11,300

Kcal/h 1,720 2,150 2,840

Maximum kW 2.6 3.0 3.8

Btu/h 8,900 10,200 13,000

Kcal/h 2,240 2,580 3,270

Heating capacity Minimum kW 1.3

Btu/h 4,400

Kcal/h 1,120

Standard kW 2.5 2.8 3.5

Btu/h 8,500 9,600 11,900

Kcal/h 2,150 2,410 3,010

Maximum kW 3.5 4.0 4.8

Btu/h 11,600 13,600 16,400

Kcal/h 3,010 3,440 4,130

Piping connections Drain OD mm 18.0

Gas OD mm 9.52

Heat insulation Both liquid and gas pipes

Liquid OD mm 6.35

Power Input Cooling Nominal kW 0.550 0.730 0.980

Heating Nominal kW 0.950 0.690 0.930

For combination

indoor units +

outdoor units

EER Nominal 3.64 3.42 3.37

COP Nominal 4.24 4.06 3.76

Energy Label Cooling A

Heating A

Annual energy consumption kWh 275 365 490

2-1 Nominal Capacity and Nominal Input RX50G2V1B RX60G2V1B RX71GV1B

For combination indoor

units + outdoor units

Indoor Units FTX50GV1B FTX60GV1B FTX71GV1B

Cooling capacity Max. Btu/h 20,500 22,900 29,000

kcal/h 5,160 5,760 7,310

kW 6.0 6.7 8.5

Min. Btu/h 5,800 7,800

kcal/h 1,460 1,980

kW 1.7 2.3

Nom. Btu/h 17,100 20,500 24,200

kcal/h 4,300 5,160 6,110

kW 5.0 6.0 7.1

Heating capacity Max. Btu/h 26,300 27,300 34,800

kcal/h 6,620 6,880 8,770

kW 7.7 8.0 10.2

Min. Btu/h 5,800 7,800

kcal/h 1,460 1,980

kW 1.7 2.3

Nom. Btu/h 19,800 23,900 28,000

kcal/h 4,990 6,020 7,050

kW 5.8 7.0 8.2

RX-JV-GV_EN.pdf 5 12/05/2010 8:21:49

• Outdoor Units • R-410A • RX-JV/GV

• Split Sky Air • Outdoor Units

2 Specifications

Power Input Cooling Max. kW 2.08 2.40 3.20

Min. kW 0.44 0.57

Nom. kW 1.55 1.99 2.35

Heating Max. kW 2.53 2.81 3.82

Min. kW 0.40 0.52

Nom. kW 1.60 2.04 2.55

For combination indoor

units + outdoor units

EER Nominal 3.23 3.02

COP Nominal 3.63 3.43 3.22

Energy Label Cooling A B B

Heating A B C

Annual energy consumption kWh 3000 3350 4250

2-2 Technical Specifications RX20JV1B RX25JV1B RX35JV1B

Casing Colour Ivory White

Dimensions Unit Height mm 550

Width mm 658

Depth mm 275

Packing Height mm 616

Width mm 788

Depth mm 359

Weight Unit kg 28 28 30

Packed Unit kg 31 31 34

Heat Exchanger Dimensions Length mm 670 670 647

Nr of Rows 1 1 2

Fin Pitch mm 1.4 1.4 1.4

Nr of Stages 24 24 24

Tube type Hi-Xa(7)

Fin Type Waffle fin

Fan Type Propeller

Quantity 1 1 1

Air Flow Rate Cooling (High) m³/min 29.2 29.2 27.6

Heating (High) m³/min 26.2 26.2 24.5

Cooling (High) cfm 1,030 1,030 975

Heating (High) cfm 927 927 865

Motor Quantity 1 1 1

Model KFD-280-33-8A

Motor Speed (nominal) Cooling (Low) rpm 720 720 720

Cooling (High) rpm 860 860 860

Heating (Low) rpm 350 350 350

Heating (High) rpm 860 860 860

Fan Motor Output W 33 33 33

Motor Model KFD-280-33-8A

Type Propeller

Compressor Quantity 1 1 1

Motor Model 1YC23AEXDA

Type Hermetically sealed swing compressor

Motor Output W 750 750 750

Operation Range Cooling Min °CDB 10 10 10

Max °CDB 46 46 46

Heating Min °CWB -15 -15 -15

Max °CWB 20 20 20

Sound Level

(nominal)

Cooling Sound Power dBA 60 60 62

Sound Pressure

(High)

dBA 46 46 48

Heating Sound Pressure

(High)

dBA 47 47 48

Refrigerant Type R-410A

Charge kg 0.74 0.74 1.0

2-1 Nominal Capacity and Nominal Input RX50G2V1B RX60G2V1B RX71GV1B

RX-JV-GV_EN.pdf 6 12/05/2010 8:21:49

• Split Sky Air • Outdoor Units 5

• Outdoor Units • R-410A • RX-JV/GV

2 Specifications

Refrigerant Oil Type FVC50K

Charged Volume l 0.375 0.375 0.375

Piping connections Liquid (OD) Quantity 1 1 1

Diameter (OD) mm 6.35 6.35 6.35

Gas Quantity 1 1 1

Diameter (OD) mm 9.52 9.52 9.52

Drain Quantity 1 1 1

Diameter (OD) mm 18 18 18

Piping Length Maximum m 15 15 15

Additional Refrigerant Charge kg/m 0.02(>10m)

Installation height

difference

Maximum m 12 12 12

Heat Insulation Both liquid and gas pipes

Standard

Accessories

Item Installation manual

Quantity 1 1 1

Item Drain plug

Quantity 1 1 1

Notes Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19.0°CWB; outdoor

temperature: 35°CDB, 24°CWB, refr.pip.length: 5m

Nominal heating capacities are

based on: indoor temperature:

20°CDB; outdoor temperature:

7°CDB, 6°CWB,

refr.pip.length: 5m

Nominal heating capacities are

based on: indoor

temperature:20°CDB, outdoor

temperature:7°CDB, 6°CWB,

refr.pip. length 5m

Nominal heating capacities are

based on: indoor temperature:

20°CDB; outdoor temperature:

7°CDB, 6°CWB,

refr.pip.length: 5m

2-2 Technical Specifications RX50G2V1B RX60G2V1B RX71GV1B

Casing Colour Ivory white

Dimensions Unit Height mm 792 900

Width mm 960 925

Depth mm 390

Packing Height mm 735 770

Width mm 825 900

Depth mm 300 320

Weight Unit kg 48 71

Packed Unit kg 53 79

Heat Exchanger Dimensions Length mm 845 857

Nr of Rows 2

Fin Pitch mm 1.8 1.4

Nr of Stages 32 34

Tube type ø8 Hi-XA

Fin Type Waffle fin

Treatment Anti-corrosion treatment (PE)

Fan Type Propeller

Air Flow Rate Cooling (High) m³/min 48.9 50.9 54.5

Cooling (Low) m³/min 41.7 42.4 46

Cooling (High) cfm 1,727 1,797 1,924

Cooling (Low) cfm 1,472 1,497 1,624

Heating (High) m³/min 45 46.3 46

Heating (Low) m³/min 41.7 42.4 46

Heating (High) cfm 1,589 1,635 1,624

Heating (Low) cfm 1,472 1,497 1,624

Motor Model KFD-380-50-8C

Motor Speed (nominal) Cooling (Low) rpm 670 680 730

Cooling (High) rpm 780 810 860

Heating (Low) rpm 670 680 730

Heating (High) rpm 720 740 730

Fan Motor Output W 53 66

2-2 Technical Specifications RX20JV1B RX25JV1B RX35JV1B

RX-JV-GV_EN.pdf 7 12/05/2010 8:21:50

• Outdoor Units • R-410A • RX-JV/GV

• Split Sky Air • Outdoor Units

2 Specifications

Compressor Motor Model 2YC36BXD#C 2YC63BXD#A

Type Hermetically sealed swing compressor

Motor Output W 1,20 1,10 1,92

Operation Range Cooling Min °CDB -10

Max °CDB 46

Heating Min °CWB -15

Max °CWB 18

Sound Level

(nominal)

Cooling Sound Power dBA 61 63 66

Sound Pressure (High)

dBA 47 49 52

Sound Pressure (Low)

dBA 44 46 49

Heating

Sound Pressure (High)

dBA 48 49 52

Sound Pressure (Low)

dBA 45 46 49

Refrigerant Type R-410A

Charge kg 1.5

Refrigerant Oil Type FVC50K

Charged Volume l 0.650 0.750

Piping connections Drain OD mm 18

Gas OD mm 12.7 15.9

Liquid OD mm 6.35

Piping Length Maximum m 30

Chargeless m 10

Additional Refrigerant Charge kg/m 0.020 (for piping length exceeding 10m)

Heat Insulation Both liquid and gas pipes

Standard Accessories Drain socket

Installation manual

Notes

Cooling: indoor temp. 27°CDB, 19.0°CWB; outdoor temp. 35°CDB, 24°CWB; equivalent piping length:

Heating: indoor temp. 20°CDB; outdoor temp. 7°CDB, 6°CWB; equivalent refrigerant piping: 5m

SL: The silent fan level of the air flow rate setting

220V;3;230V;4;240V

2-3 Electrical Specifications RX20JV1B RX25JV1B RX35JV1B

Power Supply Name V1

Phase 1~

Frequency Hz 50 50 50

Voltage V 220-230-240

Current Nominal running

current (RLA)

Cooling (A) A 2.52 3.52 5.02

Heating (A) A 2.62 3.02 4.52

Starting current (cooling/heating) A 2.7 3.7 5.0

Wiring connections For Power Supply Quantity 3 3 3

For connection with

indoor

Quantity 4 4 4

Remark Earth wire included

2-3 Electrical Specifications RX50G2V1B RX60G2V1B RX71GV1B

Power Supply Name V1

Phase 1~

Frequency Hz 50

Voltage V 220-230-240

Current Nominal running

current (RLA)

Cooling A 7.040 - 6.750 - 6.450 9.010 - 8.920 - 8.230 10.590 - 10.200 - 9.710

Heating A 7.230 - 6.940 - 6.640 9.190 - 8.800 - 8.410 11.420 - 10.930 - 10.440

Wiring connections For Power Supply Quantity 3

For connection with

indoor

Remark Earth wire included

2-2 Technical Specifications RX50G2V1B RX60G2V1B RX71GV1B

RX-JV-GV_EN.pdf 8 12/05/2010 8:21:50

• Split Sky Air • Outdoor Units 7

• Outdoor Units • R-410A • RX-JV/GV

3 Electrical data

3D065911

NOTES

1. RLA is based on the following conditions.

 Indoor temp. 27°CDB/19°CWB.

 Outdoor temp. 35°CDB.

2. Maximum allowable voltage variation between phases is 2%.

3. Select wire size based on the larger value of MCA.

4. Instead of fuse, use circuit breaker.

RX20-35JV

Representative unit combination Power supply CompOFM IFM

Indoor unit Outdoor unit Hz-Volts Voltage range MCA MFA RHz RLA WFLA WFLA

FTX20JV1B RX20JV1B

50 - 220Max. 50Hz 264V

Min. 50Hz 198V14.5 16 36 2.233 0.17 16 0.1250 - 230

50 - 240

FTX25JV1B RX25JV1B

50 - 220Max. 50Hz 264V

Min. 50Hz 198V14.5 16 48 3.233 0.17 16 0.1250 - 230

50 - 240

FTX35JV1B RX35JV1B

50 - 220Max. 50Hz 264V

Min. 50Hz 198V14.5 16 70 4.7 33 0.17 16 0.1250 - 230

50 - 240

SYMBOLS

MCA : Min. Circuit Amps (A)

MFA : Max. Fuse Amps (A)

RLA : Rated Load Amps (A)

OFM : Outdoor Fan Motor

IFM : Indoor Fan Motor

FLA : Full Load Amps (A)

W: Fan Motor Rated Output (W)

RHz : Rated Operating Frequency (Hz)

'$

127(6

 5/$LVEDVHGRQWKHIROORZLQJFRQGLWLRQV

 ,QGRRUWHPS&'%&:%

 2XWGRRUWHPS&'%

 0D[LPXPDOORZDEOHYROWDJHYDULDWLRQEHWZHHQSKDVHVLV

 6HOHFWZLUHVL]HEDVHGRQWKHODUJHUYDOXHRI0&$

 ,QVWHDGRIIXVHXVHFLUFXLWEUHDNHU

5;*

5;*9

5HSUHVHQWDWLYHXQLWFRPELQDWLRQ 3RZHUVXSSO\ &RPS 2)0 ,)0

,QGRRUXQLW 2XWGRRUXQLW +]9ROWV 9ROWDJHUDQJH 0&$ 0)$ 5+] 5/$ : )/$ : )/$

)7;*9% 5;*9%

 0D[+]9

0LQ+]9   



    

 

)7;*9% 5;*9%

 0D[+]9

0LQ+]9   



    

 

)7;*9% 5;*9%

 0D[+]9

0LQ+]9   



    

 

6<0%2/6

0&$ 0LQ&LUFXLW$PSV$

0)$ 0D[)XVH$PSV$

5/$ 5DWHG/RDG$PSV$

2)0 2XWGRRU)DQ0RWRU

,)0 ,QGRRU)DQ0RWRU

)/$ )XOO/RDG$PSV$

: )DQ0RWRU5DWHG2XWSXW:

5+] 5DWHG2SHUDWLQJIUHTXHQF\+]

RX-JV-GV_EN.pdf 9 12/05/2010 8:21:50

• Outdoor Units • R-410A • RX-JV/GV

• Split Sky Air • Outdoor Units

4 Capacity tables

4 - 1 Cooling/Heating capacity tables

)7;-9%5;-9%

'

&RROLQJ

+]9

$)5 

%) 

,QGRRU 2XWGRRUWHPSHUDWXUH&'%

(:% ('%      

& & 7& 6+& 3, 7& 6+& 3, 7& 6+& 3, 7& 6+& 3, 7& 6+& 3, 7& 6+& 3,







































































































































































































+HDWLQJ +]9

$)5 

,QGRRU 2XWGRRUWHPSHUDWXUH&:%

('%     

& 7& 3, 7& 3, 7& 3, 7& 3, 7& 3,

















































































































127(6

 &DSDFLWLHVDUHEDVHGRQWKHIROORZLQJFRQGLWLRQV

 &RUUHVSRQGLQJUHIULJHUDQWSLSLQJOHQJWK P

 /HYHOGLIIHUHQFH  P

 VKRZVQRPLQDOUDWHGFDSDFLWLHVDQGSRZHULQSXW

6<0%2/6

$)5 $LUÀRZUDWH  P



PLQ

%) %\SDVVIDFWRU

(:% (QWHULQJZHWEXOEWHPS &

('% (QWHULQJGU\EXOEWHPS &

7& 7RWDOFDSDFLW\ N:

6+& 6HQVLEOHKHDWFDSDFLW\ N:

3, 3RZHULQSXW  N:

RX-JV-GV_EN.pdf 10 12/05/2010 8:21:50

This manual suits for next models

Table of contents

Other Daikin Air Conditioner manuals

Daikin

Daikin FUY71FJV1 User manual

Daikin

Daikin FTXG25CVMAW User manual

Daikin

Daikin VRV FXMQ50P7VEB9 User manual

Daikin

Daikin FXFQ20AVEB User manual

Daikin

Daikin FTXS50CVMA User manual

Daikin

Daikin RZQ18PVJU (9) User manual

Daikin

Daikin EF series Manual

Daikin

Daikin FXCQ20MVE User manual

Daikin

Daikin FTY50GV1A User manual

Daikin

Daikin SkyAir FAQ18PVJU User manual

Daikin

Daikin FXMA63A5VEB User manual

Daikin

Daikin FTXF20C5V1B User manual

Daikin

Daikin Perfera RXM R Series User manual

Daikin

Daikin RXF25D5V1B User manual

Daikin

Daikin FH(Y)35BJV1 User manual

Daikin

Daikin RZQG-L7V1 Instruction manual

Daikin

Daikin FAQ71BVV1B User manual

Daikin

Daikin RZQ71C7V1B Instruction manual

Daikin

Daikin RKM18PVMK User manual

Daikin

Daikin FTXM-K User manual

Daikin

Daikin RX18N5VL User manual

Daikin

Daikin INVERTER FTXM-V Series Dimension Guide

Daikin

Daikin RKS22MVLT User manual

Daikin

Daikin FVXS-F Instruction manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use

Frigidaire

Frigidaire FAZ12ES2A installation instructions
