Daikin FXHQ-MVJU Dimension Guide

Ceiling Suspended Type

FXHQ-MVJU

EDUS39-600A-F5

202103

Engineering Data

60 Hz

FXHQ-MVJU EDUS39-600A-F5

Table of Contents

1. FeaturesandBenets ................................................................................2

2. Specications .............................................................................................3

3. Dimensions.................................................................................................5

4. Piping Diagrams .........................................................................................8

5. Wiring Diagrams.........................................................................................9

6. Electric Characteristics.............................................................................11

7. Safety Device Setting ...............................................................................12

8. Capacity Tables........................................................................................13

8.1 CoolingCapacityatTe:43°F(6°C).................................................13

8.2 Heating Capacity.............................................................................13

8.3 CorrectionFactorforCoolingCapacityatTe:48°F(9°C)...............13

9. AirVelocityandTemperatureDistributions(ReferenceData) .................14

9.1 CoolingMode..................................................................................14

9.2 HeatingMode..................................................................................17

10.SoundLevels(ReferenceData) ...............................................................20

10.1 Overall.............................................................................................20

10.2 OctaveBandLevel..........................................................................21

11.Accessories ..............................................................................................22

11.1 OptionalAccessories(forUnit) .......................................................22

FXHQ-MVJU EDUS39-600A-F5

1. Features and Benets

Slim, E󰀩cient, Quiet, Easy to Maintain

Withitsslim,elegantdesign,theFXHQceiling-suspendedunitisagreattforanylight

commercialspace.Wideairopeningsprovideacomfortableairow,andaninnovativestreamfan

ensuresquietoperation,makingitidealforretailstores,restaurants,classroomsandconference

rooms.

Slimdesignoflessthan8”inheightmakesitanidealtswithinanyinteriordesign

Wideairdischargeoutletdistributesacomfortableairowthroughoutthespacewiththrowofup

to25ft.

Innovativestreamfantechnologyallowsforoperatingsoundlevelaslowas38dB(A)

Simplecleaningthankstotheunit’ssmoothatlouverdesignanditsbristle-freefrapthat

minimizescontamination

Long-lifelterincludedasstandard

Wideairdischargeof100°foroptimalairspread

Componentsareaccessiblefromundertheunitforeaseofmaintenanceandservice

Modelsrangefrom12MBHto36MBH

Backedby10yearpartslimitedwarranty

Non-dew Frap

Sound

absorption

member

Turbulent flow

is produced

Straightening vane

New quiet stream fan

FXHQ-MVJU EDUS39-600A-F5

2. Specications

Ceiling suspended type

Model FXHQ12MVJU FXHQ24MVJU

Powersupply 1 phase, 60 Hz, 208/230 V 1 phase, 60 Hz, 208/230 V

H1, H3Coolingcapacity Btu/h 12,000 24,000

H2, H3 Heating capacity Btu/h 13,500 27,000

Casing/Color White(10Y9/0.5) White(10Y9/0.5)

Dimensions:(H × W ×D) in. 7-11/16 × 37-13/16 × 26-3/4 7-11/16 × 55-1/8 × 26-3/4

Coil(crossn

coil)

Rows × Stages × FPI 2 × 12 × 15 3 × 12 × 15

Face area ft² 1.96 3.15

Fan

Model 3D12K1AA1 3D12K2AA1

Type Siroccofan Siroccofan

Motoroutput W 62 130

Airowrate(H/L) cfm 410/340 710/600

Drive Direct drive Direct drive

Temperaturecontrol Microprocessorthermostatforcoolingand

heating

Microprocessorthermostatforcoolingand

heating

Soundabsorbingthermalinsulationmaterial Glasswool Glasswool

Airlter Resinnet(withmoldresistant) Resinnet(withmoldresistant)

H4Soundpressurelevel(reference

data)(H/L) dBA 42/38 44/42

Weight lbs 55 80

Piping

connections

Liquidpipes in. f1/4(areconnection) f3/8(areconnection)

Gas pipes in. f1/2(areconnection) f5/8(areconnection)

Drain pipe in. VP20(externaldia.1,internaldia.3/4) VP20(externaldia.1,internaldia.3/4)

Safety devices Fuse,Thermalprotectorforfanmotor Fuse,Thermalprotectorforfanmotor

Refrigerantcontrol Electronicexpansionvalve Electronicexpansionvalve

Connectableoutdoorunit R410AVRV series R410AVRV series

Standardaccessories

Operationmanual,Installationmanual,Drain

hose,Paperpatternforinstallation,Clampmetal,

Insulationfortting,Clamps,Washers

Operationmanual,Installationmanual,Drain

hose,Paperpatternforinstallation,Clampmetal,

Insulationfortting,Clamps,Washers

Note:

H1. Nominalcoolingcapacitiesarebasedonthefollowingconditions:

Returnairtemperature:80°FDB,67°FWB

Outdoortemperature:95°FDB

Equivalentrefrigerantpipinglength:25ft(horizontal)

H2. Nominalheatingcapacitiesarebasedonthefollowingconditions:

Returnairtemperature:70°FDB.

Outdoortemperature:47°FDB,43°FWB

Equivalentrefrigerantpipinglength:25ft(horizontal)

H3. Capacitiesarenet,includingadeductionforcooling(anadditionforheating)forindoorfanmotorheat.

H4. Anechoicchamberconversionvalue,measuredunderJISconditions.Duringactualoperation,

thesevaluesmaybehigherasaresultofambientconditions.

C:4D049326

FXHQ-MVJU EDUS39-600A-F5

Ceiling suspended type

Model FXHQ36MVJU

Powersupply 1 phase, 60 Hz, 208/230 V

H1, H3Coolingcapacity Btu/h 36,000

H2, H3 Heating capacity Btu/h 40,000

Casing/Color White(10Y9/0.5)

Dimensions:(H × W ×D) in. 7-11/16 × 62-5/8 × 26-3/4

Coil(crossn

coil)

Rows × Stages × FPI 2 × 12 × 15 + 2 × 10 × 15

Face area ft² 3.66 + 2.95

Fan

Model —

Type Siroccofan

Motoroutput W 130

Airowrate(H/L) cfm 830/670

Drive Direct drive

Temperaturecontrol Microprocessorthermostatforcoolingandheating

Soundabsorbingthermalinsulationmaterial Glasswool

Airlter Resinnet(withmoldresistant)

H4Soundpressurelevel(reference

data)(H/L) dBA 46/42

Weight lbs 90

Piping

connections

Liquidpipes in. f3/8(areconnection)

Gas pipes in. f5/8(areconnection)

Drain pipe in. VP20(externaldia.1,internaldia.3/4)

Safety devices Fuse,Thermalprotectorforfanmotor

Refrigerantcontrol Electronicexpansionvalve

Connectableoutdoorunit R410AVRV series

Standardaccessories Operationmanual,Installationmanual,Drainhose,Paperpatternforinstallation,Clampmetal,

Insulationfortting,Clamps,Washers

Note:

H1. Nominalcoolingcapacitiesarebasedonthefollowingconditions:

Returnairtemperature:80°FDB,67°FWB

Outdoortemperature:95°FDB

Equivalentrefrigerantpipinglength:25ft(horizontal)

H2. Nominalheatingcapacitiesarebasedonthefollowingconditions:

Returnairtemperature:70°FDB.

Outdoortemperature:47°FDB,43°FWB

Equivalentrefrigerantpipinglength:25ft(horizontal)

H3. Capacitiesarenet,includingadeductionforcooling(anadditionforheating)forindoorfanmotorheat.

H4. Anechoicchamberconversionvalue,measuredunderJISconditions.Duringactualoperation,

thesevaluesmaybehigherasaresultofambientconditions.

C:4D049326

FXHQ-MVJU EDUS39-600A-F5

3. Dimensions

FXHQ12MVJU

3D049330A

Unit: in.

FXHQ-MVJU EDUS39-600A-F5

FXHQ24MVJU

3D049331A

Unit: in.

FXHQ-MVJU EDUS39-600A-F5

FXHQ36MVJU

3D049332B

Unit: in.

FXHQ-MVJU EDUS39-600A-F5

4. Piping Diagrams

FXHQ12-36MVJU

Unit:in.

Model Gas Liquid

FXHQ12MVJU f1/2 f1/4

FXHQ24-36MVJU f5/8 f3/8

4D024460P
