Daikin FHQ-CB Instruction manual

Air Conditioning

Technical Data

FHQ-CB

> FHQ35CBVEB

> FHQ50CBVEB

> FHQ60CBVEB

> FHQ71CBVEB

> FHQ100CBVEB

> FHQ125CBVEB

> FHQ140CBVEB

• Split - Sky Air • FHQ-CB 1

• Indoor Unit • FHQ-CB

TABLE OF CONTENTS

FHQ-CB

1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

6 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

7 External connection diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

8 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Sound Pressure Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

• Indoor Unit • FHQ-CB

• Split - Sky Air • FHQ-CB

1 Features

IndoorUnit Split-Sk FHQ-CBCeilingsus

For wide rooms with no false ceilings nor free floor space

• Ideal for comfortable air flow in wide rooms thanks to Coanda effect:

up to 100° discharge angle

• Even rooms with ceilings up to 3.8m can be heated up or cooled

down very easily without capacity loss

• Can easily be mounted in corners and narrow spaces, as it only

needs 30mm lateral service space

• Reduced energy consumption thanks to specially developed DC fan

motor and drain pump

• Stylish unit blends easily with any interior. The flaps close entirely

when the unit is not operating and there are no air intake grilles visible

• No optional adapter needed for DIII-connection, link your unit into the

wider building management system.

• Drain pump kit available as accessory

• Fresh air intake integrated in the same system thus reducing

installation cost as no additional ventilation device is required

Infrastructure

cooling

Inverter Home leave

operation

Fan only Radiant heat Vertical auto

swing

Fan speed

steps

Dry programme Air filter

Weekly timer Infrared remote

control

Wired remote

control

Centralised

control

Auto-restart Self diagnosis Drain pump kit Twin/triple/

double twin

application

Multi model

application

VRV for

residential

application

• Split - Sky Air • FHQ-CB 3

• Indoor Unit • FHQ-CB

2 Specifications

2-1 Technical Specifications FHQ35CB FHQ50CB FHQ60CB FHQ71CB FHQ100CB FHQ125CB FHQ140CB

Power input - 50Hz Cooling Nom. kW 0.090 0.091 0.110 0.172 0.217 0.251

Heating Nom. kW 0.072 0.090 0.172 0.217 0.251

Casing Colour White

Material Resin, sheet metal

Dimensions Unit Height/Width/

Depth

mm 235/960/690 235/1,270/690 235/1,590/690

Packed unit Height/Width/

Depth

mm 340/1,116/858 349/1,426/878 349/1,746/878

Weight Unit kg 24 25 31 32 38

Packed unit kg 38 39 52 54 61

Packing Material Carton / Plywood

Weight kg 8.5 13.9 15.0

Heat exchanger Fin Type ML fin (Multi louver)

Treatment Anti Corrosion Hydrophilic

Air filter Type Resin net with mold resistance

Quantity pc 2

Fan Type Sirocco fan

Quantity 2 4

Air flow rate Cooling High m³/min 14 15 19.5 20.5 28 31 34

cfm 494 530 689 724 989 1,095 1,201

Low m³/min 10 11.5 14 20 23 24

cfm 353 406 494 706 812 848

Nom. cfm 406 424 530 600 848 953 1,024

m³/min11.5121517242729

Heating High m³/min 14 15 19.5 20.5 28 31 34

cfm 494 530 689 724 989 1,095 1,201

Low m³/min 10 11.5 14 20 23 24

cfm 353 406 494 706 812 848

Nom. cfm 406 424 530 600 848 953 1,024

m³/min11.5121517242729

Fan motor Quantity 1

Model KFD-280-87-8A KFD-280-117-8A EQDW01EDK

Speed Steps 3

Output High W 60 91 150

Phase x Voltage V DC280V DC192V-380V

Full load amps

(FLA)

Cooling A 0.6 0.8 1.2 1.6 1.8

Heating A 0.6 0.8 1.2 1.6 1.8

Sound power level Cooling dBA 53 54 55 60 62 64

Heating dBA 53 54 55 60 62 64

Sound pressure level Cooling High/Low dBA 36/31 37/32 37/33 38/34 42/34 44/37 46/38

Heating High/Low dBA 36/31 37/32 37/33 38/34 42/34 44/37 46/38

Control systems Infrared remote control BRC7G53

Wired remote control BRC1D52 / BRC1E52A/B / BRC1E53A / BRC1E53B / BRC1E53C / BRC1E51A

Refrigerant Type R-410A

Piping connections Sound absorbing insulation Not needed

Liquid Type/OD mm C1220T (Flare connection)/6.35 C1220T (Flare connection)/9.52

Gas Type/OD mm C1220T

(Flare

connection)/

9.5

C1220T (Flare connection)/

12.7

C1220T (Flare connection)/15.9

Drain VP20

Heat insulation Needed

Air direction control Up and downwards

Safety devices Item 01 Fuse (F, 5A, 250V) -

2-2 Electrical Specifications FHQ35CB FHQ50CB FHQ60CB FHQ71CB FHQ100CB FHQ125CB FHQ140CB

Power supply Phase 1~

Frequency Hz 50

Voltage V 220-240

Current - 50Hz Maximum running current A 0.6 0.8 1.3 1.5 1.8

• Indoor Unit • FHQ-CB

• Split - Sky Air • FHQ-CB

3 Options

3 - 1 Options

FHQ-CB

ϯϱ ϱϬ ϲϬ ϳϭ ϭϬϬ ϭϮϱ ϭϰϬ

<,&WϱDϯϱ

,ĞĂƚƉƵŵƉ

ŽŽůŝŶŐŽŶůǇ

;ϭͿ ŶĐůƵĚĞĚůĂŶŐƵĂŐĞƐĂƌĞŶŐůŝƐŚ'ĞƌŵĂŶ&ƌĞŶĐŚ ƚĂůŝĂŶ^ƉĂŶŝƐŚWŽƌƚƵŐƵĞƐĞĂŶĚƵƚĐŚ

;ϮͿ ŶĐůƵĚĞĚůĂŶŐƵĂŐĞƐĂƌĞŶŐůŝƐŚǌĞĐŚƌŽĂƚŝĂŶ,ƵŶŐĂƌŝĂŶ^ůŽǀĞŶŝĂŶZŽŵĂŶŝĂŶĂŶĚƵůŐĂƌŝĂŶ

;ϯͿ ŶĐůƵĚĞĚůĂŶŐƵĂŐĞƐĂƌĞŶŐůŝƐŚZƵƐƐŝĂŶ'ƌĞĞŬdƵƌŬŝƐŚWŽůŝƐŚůďĂŶŝĂŶĂŶĚ^ůŽǀĂŬ

;ϰͿ ŶĐůƵĚĞƐĚƵƚǇƌŽƚĂƚŝŽŶĨƵŶĐƚŝŽŶĂůŝƚǇ

;ϱͿ ŶĐůƵĚĞĚůĂŶŐƵĂŐĞƐĂƌĞ

>ĂŶŐƵĂŐĞƉĂĐŬϭŶŐůŝƐŚ'ĞƌŵĂŶ&ƌĞŶĐŚƵƚĐŚ^ƉĂŶŝƐŚ ƚĂůŝĂŶĂŶĚWŽƌƚƵŐƵĞƐĞ

tŝƚŚWĐĂďůĞ<WϯŝŶĐŽŵďŝŶĂƚŝŽŶǁŝƚŚƚŚĞhƉĚĂƚĞƌWƐŽĨƚǁĂƌĞǇŽƵĐĂŶĂĚĚŝƚŝŽŶĂůůǇĐŚĂŶŐĞƚŚĞůĂŶŐƵĂŐĞƚŽ

>ĂŶŐƵĂŐĞƉĂĐŬϮŶŐůŝƐŚƵůŐĂƌŝĂŶƌŽĂƚŝĂŶǌĞĐŚ,ƵŶŐĂƌŝĂŶZŽŵĂŶŝĂŶĂŶĚ^ůŽǀĞŶŝĂŶ

>ĂŶŐƵĂŐĞƉĂĐŬϯŶŐůŝƐŚ'ƌĞĞŬWŽůŝƐŚZƵƐƐŝĂŶ^ĞƌďŝĂŶ^ůŽǀĂŬĂŶĚdƵƌŬŝƐŚ

;ϲͿ

ZĞƋƵŝƌĞƐŝŶƐƚĂůůĂƚŝŽŶďŽǆĨŽƌĂĚĂƉƚŽƌW;<ZWϭϵϯͿ

;ϳͿ

KŶůǇƉŽƐƐŝďůĞŝŶĐŽŵďŝŶĂƚŝŽŶǁŝƚŚƐŝŵƉůŝĨŝĞĚƌĞŵŽƚĞĐŽŶƚƌŽůZϮϯϱϮϳ

ůĞĐƚƌŝĐĂůďŽǆǁŝƚŚĞĂƌƚŚƚĞƌŵŝŶĂů;ϮďůŽĐŬƐͿ <:ϮϭϮ

ŝŐŝƚĂůŝŶƉƵƚĂĚĂƉƚŽƌ ZWϳϱϮ

;ϲͿ;ϳͿ

ZĞŵŽƚĞƐĞŶƐŽƌ <Z^ϬϭͲϰ

ZĞŵŽƚĞΗKEK&&ΗĂŶĚΗĨŽƌĐĞĚK&&ΗŬŝƚ <ZKZϬϰ

ůĞĐƚƌŝĐĂůďŽǆǁŝƚŚĞĂƌƚŚƚĞƌŵŝŶĂů;ϯďůŽĐŬƐͿ <:ϯϭϭ

tŝƌŝŶŐĂĚĂƉƚŽƌĨŽƌĞůĞĐƚƌŝĐĂůĂƉƉĞŶĚŝĐĞƐ <ZWϰϱϮ

;ϲͿ

ŶƐƚĂůůĂƚŝŽŶďŽǆĨŽƌĂĚĂƉƚŽƌW <ZWϭϵϯ

DŽƵŶƚŝŶŐƉůĂƚĞĨŽƌĂĚĂƉƚŽƌWŝŶƐƚĂůůĂƚŝŽŶďŽǆ <<^WϱϬϱϲ Ͳ

hŶŝĨŝĞĚKEK&&ĐŽŶƚƌŽůůĞƌ ^ϯϬϭϱϭ

^ĐŚĞĚƵůĞƚŝŵĞƌ ^dϯϬϭϱϭ

tŝƌŝŶŐĂĚĂƉƚŽƌĨŽƌĞůĞĐƚƌŝĐĂůĂƉƉĞŶĚŝĐĞƐ <ZWϭϱϰ

^ŝŵƉůŝĨŝĞĚƌĞŵŽƚĞĐŽŶƚƌŽů;ǁŝƚŚŽƉĞƌĂƚŝŽŶŵŽĚĞƐĞůĞĐƚŽƌďƵƚƚŽŶͿ ZϮϱϮϳ

;ϱͿ

^ŝŵƉůŝĨŝĞĚƌĞŵŽƚĞĐŽŶƚƌŽů;ǁŝƚŚŽƵƚŽƉĞƌĂƚŝŽŶŵŽĚĞƐĞůĞĐƚŽƌďƵƚƚŽŶͿ ZϯϱϮϳ

;ϱͿ

ĞŶƚƌĂůƌĞŵŽƚĞĐŽŶƚƌŽů ^ϯϬϮϱϭ

ZĞŵŽƚĞĐŽŶƚƌŽů

tŝƌĞĚƌĞŵŽƚĞĐŽŶƚƌŽů Zϭϱϯϳ

;ϭͿ;ϮͿ

Zϭϱϯϳ

;ϭͿ;ϯͿ

Zϭϱϯϳ

;ϭͿ;ϰͿ

ZϭϱϮϳZϭϱϮϳZϭϱϭϳZϭϱϮϴ

tŝƌĞůĞƐƐƌĞŵŽƚĞĐŽŶƚƌŽů Zϳ'ϱϯ

Zϳ'ϱϲ

ƌĂŝŶƉƵŵƉŬŝƚ <hϱϬWϲϬs <hϱϬWϭϰϬs

>ͲƚǇƉĞƉŝƉŝŶŐŬŝƚ;ƵƉǁĂƌĚĚŝƌĞĐƚŝŽŶͿ <,&WϱEϲϯ <,&WϱEϭϲϬ

&,YΎs

>ŽŶŐͲůŝĨĞƌĞƉůĂĐĞŵĞŶƚĨŝůƚĞƌ <&WϱϬϭϱϲ <&WϱϬϭϴϬ <&WϱϬϭϭϲϬ

&ƌĞƐŚĂŝƌŝŶƚĂŬĞŬŝƚ <YϱϬϭϰϬ

ϯϭϬϭϰϴϰ

• Split - Sky Air • FHQ-CB 5

• Indoor Unit • FHQ-CB

4 Dimensional drawings

4 - 1 Dimensional Drawings

• Indoor Unit • FHQ-CB

• Split - Sky Air • FHQ-CB

4 Dimensional drawings

4 - 1 Dimensional Drawings

• Split - Sky Air • FHQ-CB 7

• Indoor Unit • FHQ-CB

4 Dimensional drawings

4 - 1 Dimensional Drawings

3D069633D

• Indoor Unit • FHQ-CB

• Split - Sky Air • FHQ-CB

5 Piping diagrams

5 - 1 Piping Diagrams

,QGRRUXQLW

)LHOGSLSLQJ



㻌㻭㻌㻌㻌㻌㻯㻝㻞㻞㻜㼀㻙㻜



㻌㻮㻌㻌㻌㻌㻯㻝㻞㻞㻜㼀㻙㻜

7RRXWGRRUXQLW

FHQ-CB

3D101475
