D-Link DIR-450 - 3G Mobile Router Wireless User manual
2D-Link DIR-450 Quick Install Guide
Package Contents
If any of the above items are missing, please contact your reseller.
• D-Link DIR-450 Mobile Router
• Power Adapter
• Ethernet Cable
• Manual and Warranty on CD
Note: Using a power supply with a different voltage rating than the one included with
the DIR-450 will cause damage and void the warranty for this product.
• A compatible 32-bit PCMCIA (EVDO) card with service*
• Computers with Windows®, Macintosh®, or Linux-based operating systems
with an installed Ethernet adapter
• Internet Explorer Version 6.0 or Netscape Navigator™Version 6.0 and above
(for configuration)
System Requirements
* Subject to services and service terms available from your carrier.
3 D-Link DIR-450 Quick Install Guide
Connect to your Network
Note: Ensure that power to your DIR-450 Mobile Router is not connected before
performing the installation steps below.
32-bit PCMCIA (EVDO) Card Connection
1. Attach the antenna.
a.Remove the antenna from its plastic wrapper.
b. Screw the antenna in a clockwise direction to the back panel of the
unit.
c. Once secured, position the antenna upward at its connecting joint. This
will ensure optimal reception.
2.Insert your wireless 32-bit PCMCIA (EVDO) card into the Internet Card
Slot on the back of the router.
3.Insert the Ethernet cable into LAN Port 1 on the back panel of the DIR-450
Mobile Router, and an available Ethernet port on the network adapter in
the computer you will use to configure the unit.
Note:The DIR-450 Mobile Router LAN Ports are “Auto-MDI/MDIX.”This provides
either patch or crossover Ethernet cable LAN Port access.
4.Connect the power adapter to the receptor on the back panel of your
DIR-450 Mobile Router. Then plug the other end of the power adapter into
a wall outlet or power strip.
a.The Power LED will turn ON to indicate power has been applied.
b. Other LEDs will flash ON and OFF as the DIR-450 Mobile Router
performs initialization and Internet connection processes. This will take
a few minutes.
c. When complete, the following LEDs will illuminate blue: Power,
Status, Internet, WLAN, and LAN Port 1 (or your specific LAN Port
connection).
4D-Link DIR-450 Quick Install Guide
Using the Setup Wizard
Open your web browser and
type http://192.168.0.1 into
the URL address box. Press
Enter.
Type admin for the
username and leave
the password blank.
The logon pop-up screen will appear:
Once you have logged in, the Setup screen will appear:
Click Setup Wizard
5 D-Link DIR-450 Quick Install Guide
Click Launch Internet Connection Setup Wizard to begin.
Click Launch Internet
Connection Setup
Wizard
Click Next to continue.
Create a new password and then click Next to continue.
Click Next
Select your time zone from the drop-down menu and then click Next to
continue.
Click Next
Click Next
6D-Link DIR-450 Quick Install Guide
Select the ISP Card from the drop-down list and then click Username /
Password Connection (WWAN). Click Next to continue.
Enter your WWAN user name, password, and server information. If you do
not have this information, please contact your ISP.
Click Connect to save your settings. Once the router is finished rebooting,
click Continue. Please allow 1-2 minutes to connect.
Click Next
Click Next
Click Connect
7 D-Link DIR-450 Quick Install Guide
Notes
8D-Link DIR-450 Quick Install Guide
Technical Support
D-Link’s website contains the latest user documentation and
software updates for D-Link products.
U.S. and Canadian customers can contact D-Link Technical
Support through our website or by phone.
United States
Telephone
(888) 843-6100
Monday through Friday 8:00am - 5:00pm (PST)
World Wide Web
http://support.dlink.com
Canada
Telephone
(800) 361-5265
Monday through Friday, 7:30am to 9:00pm (EST)
World Wide Web
http://support.dlink.ca
Version 1.0
August 18, 2006
Copyright ©2006 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered
trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property
of their respective owners. Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data
throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials
and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless
signal range. Product specifications, size and shape are subject to change without notice, and actual product appearance may
differ from that depicted on the packaging. Visit www.dlink.com for more details.
