D-Link DIR-451 - 3G Mobile Router User manual

3.5G Mobile Router

Quick Installation Guide+

Руководство по быстрой установке+

Guía de Instalación Rápida+

Guia de Instalação Rápida+

快速安裝指南+

Petunjuk Pemasangan Cepat+

DIR-451

Quick Install Guide

DIR-451

3.5G Mobile Router

3 D-Link DIR-451 Quick Install Guide

System Requirements

Package Contents

* Subject to the services and terms available from your carrier.

• D-Link DIR-451 Mobile Router

• Power Adapter

• Ethernet Cable

• Manual and Warranty on CD

Note: Using a power supply with a different voltage rating than the one included with

the DIR-451 will cause damage and void the warranty for this product.

• A compatible 32-bit PCMCIA (HSUPA/HSDPA/UMTS) card or 3G USB

Modem*

• Computers with Windows®, Macintosh®, or Linux-based operating systems

and with an installed Ethernet adapter

• Internet Explorer Version 6.0 or Netscape Navigator™ Version 6.0 and

higher (for conguration)

If any of the above items are missing, please contact your reseller.

4D-Link DIR-451 Quick Install Guide

Connect to your network

Note: Ensure that your DIR-451 Mobile Router is not powered up before performing

the installation steps below.

1. Attaching the antenna.

a. Remove the antenna from its plastic wrapper.

b. Drive the antenna screws into the back panel of the

router in clockwise direction.

c. Once secured, position the antenna in an upward

direction at its connecting joint. This will ensure optimal

reception.

2. Insert your wireless 32-bit PCMCIA (HSUPA/HSDPA/UMTS) card into

the WWAN card slot or connect a 3G USB Modem to the USB port of

the DIR-451.

3. Insert the Ethernet cable into LAN Port 1 on the back panel of the

DIR-451, and the other end to an Ethernet port of the computer which

will be used for conguring this router.

Note: The LAN ports of the DIR-451 Mobile Router are Auto-MDI/MDIX, which provides

either patch or crossover Ethernet cable LAN Port access.

4. Connect the power adapter to the receptor on the back panel of your

DIR-451. Then plug the other end of the power adapter into a wall outlet

or power strip.

a. The Power LED will turn blue which indicates that

power has been supplied.

b. Other LEDs will also turn blue as the DIR-451 Mobile

Router performs initialization and Internet connection

processes. This will take a few minutes.

c. After you congure your Internet connection (using

the Setup Wizard), the following LEDs will turn blue:

Status, 3G Access, WLAN, and LAN Port 1 (or your

specic LAN Port connection).

5 D-Link DIR-451 Quick Install Guide

Using the Setup Wizard

The Login screen will appear.

Once you have logged in, the Setup screen will appear.

Open your web browser and

type http://192.168.0.1 into

the URL address box. Press

Enter.

Type admin fo r t he

username and leave the

password blank. Click Log

In to continue.

6D-Link DIR-451 Quick Install Guide

Click Launch Internet Connection Setup Wizard to begin.

Click Next to continue.

Create a new password and then

click Next to continue.

Click Prev to go back to the previous

page or click Cancel to close the

wizard.

Select your time zone from the drop-down box and then click Next to continue.

Click Internet Connection Setup

Wizard to begin.

Click Prev to go back to the

previous page or click Cancel to

close the wizard.

7 D-Link DIR-451 Quick Install Guide

Select from WWAN or WAN as the type of interface and then click Next to

continue.

Click Next

Note: DIR-451 supports two kinds of WAN

interfaces, allowing you to assign either

a WAN or a WWAN(3G) connection as

the Backup WAN. If the Primary WAN is

down or unavailable, congure the Backup

WAN to Enable, and all the trafc will be

routed through Backup WAN. This feature

is called WAN Failover.

Click Prev to go back to the previous page or click Cancel to close the wizard.

Select the Country, ISP and the 3G

Card you are using from the drop-down

boxes to set up a 3G connection. The

User Name, Password, Dial Number

and APN elds are optional. You can

get this information from your Internet

Service Provider (ISP).

Click Next to continue, Prev to go back

to the previous page or Cancel to close

the wizard.

Select Static IP if your ISP assigned you

the IP address, subnet mask, gateway, and

DNS server addresses. Each IP address

entered must be in the appropriate format,

which are four octets separated by a dot

(x.x.x.x). The router will not accept the IP

address if it is not in this format.

Click Next to continue, Prev to go back to

the previous page or Cancel to close the

wizard.

8D-Link DIR-451 Quick Install Guide

If you have selected Dynamic IP, enter

the MAC address of the computer that

was last connected to or if you are

currently using that computer, click

Clone Your PC’s MAC Address

to automatically update the MAC

address.

Click Next to continue, Prev to go back to the previous page or Cancel to close

the wizard.

If you have selected PPPoE,

enter your PPPoE Username and

password.

Click Next to continue, Prev to

go back to the previous page or

Cancel to close the wizard.

You have completed the

Setup Wizard.

Click Connect to save your settings.

Note: Please refer to the DIR-451 User Manual for more detailed

information.

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Australia:

Tel: 1300-766-868

24/7(24Hrs, 7days a week) technical support

http://www.dlink.com.au

e-mail: [email protected]

India:

Customer Support: - 1800-233-0000 (MTNL & BSNL Toll Free) or

+91-832-2885700 (GSM, CDMS & Others)

E-Mail Address: - [email protected], [email protected]

Website: - www.dlink.co.in

Indonesia, Malaysia, Singapore and Thailand:

Tel: +62-21-5731610 (Indonesia)

Tel: 1800-882-880 (Malaysia)

Tel: +65 6501 4200 (Singapore)

Tel: +66-2-719-8978/9 (Thailand)

24/7, for English Support Only

http://www.dlink.com.sg/support/

e-mail: [email protected]

Korea:

Tel: +82-2-2028-1815

Monday to Friday 9:00am to 6:00pm

http://www.d-link.co.kr

e-mail: [email protected]

New Zealand:

Tel: 0800-900-900

24/7(24Hrs, 7days a week) technical support

http://www.dlink.co.nz

e-mail: [email protected]

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Egypt:

Tel: +202-2919035 or +202-2919047

Sunday to Thursday 9:00am to 5:00pm

http://support.dlink-me.com

Email: [email protected]

Iran:

Te: +98-21-88880918,19

Saturday to Thursday 9:00am to 5:00pm

http://support.dlink-me.com

Email : [email protected] & [email protected]

Israel:

Magshimim 20, Petach Tikva 49348

Website: www.dlink.co.il

Main Tel: 972-3-9215173

Customer Support Tel: 972-3-9212886

Pakistan:

Tel: +92-21-4548158 or +92-21-4548310

Monday to Friday 10:00am to 6:00pm

http://support.dlink-me.com

E-mail: [email protected]

South Africa and Sub Sahara Region:

Tel: +27-12-665-2165

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South Africa Time

http://www.d-link.co.za

Turkey:

Tel: +90-212-2895659

Monday to Friday 9:00am to 6:00pm

http://www.dlink.com.tr

e-mail: [email protected]

U.A.E and North Africa:

Tel: +971-4-4278127 (U.A.E)

Sunday to Thursday 9.00AM to 6.00PM GMT+4

Web: http://www.dlink-me.com

E-mail: [email protected]

Saudi ARABIA (KSA):

Telephone : +966 01 217 0008

Facsimile : +966 01 217 0009

e-mail: [email protected]

Saturday to Wednesday 9.30AM to 6.30PM

Thursdays 9.30AM to 2.00 PM
