D-Link DSL-2750U Manual

DSL-2750U Storage

Setup

POWER UP

your Business

Power Adapter Connection

Plug the 3-Pin Power Supply/ Lightning Protection unit into the wall

outlet and then connect the other end of it (12VDC IN)

LAN CONNECTION

POWER UP

your Business

POWER UP

your Business

LAN Connection

Connect the Ethernet LAN Cable to any (yellow) port on the Router

and connect the other end to the LAN port of the PC

CONNECTING TO THE

UNIT VIA WEB GUI

POWER UP

your Business

How to login to Unit using the Web GUI

1. Go to your Internet Explorer or Default Browser.

2. In your URL field, type the Default IP (10.0.0.2) of router.

3. A login page will appear and you will be prompted for a

Username and Password these are both “admin”

Connecting to the unit via Web GUI

Username: admin

Password: admin

Connecting to the unit via Web GUI

Storage

Setup

POWER UP

your Business

Setting up a USB external hard drive or flash

drive as a shared storage facility.

Notes:

· FAT 32 devices are limited to 32GB maximum and the file can’t be greater than 4GB,

· The below setup was done with an 1TB NTFS Mass Storage (the external drive should

however be self powered by the power supply that came with the external drive).

· Please make sure the unit is on the latest firmware. You can download the firmware

at ftp.dlinktech.co.za . If you are still unsure as to which firmware to download,

then simply e-mail your query to support@d-link.co.za or call the D-Link Africa

offices on +27 (0)12 661 2025/3

Setup:

· Go To Advanced, then Storage Service,

· Select Storage Device Info,

Note the volumeName of the stoage device.
