D-Link DWL-P50 User manual

DWL-P50

Power Over

Ethernet Adapters

and speciﬁcations subject to change without notice.

About DWL-P50

Check Your Package Contents

DWL-P50 Power Over Ethernet Adapter

Female-to-Female Power Connector

Ethernet (CAT5 UTP/Straight Through) Cable

If any of the above items are missing, please contact your reseller.

The DWL-P50 Power Over Ethernet (POE) Adapters are designed to work with

D-Link PoE switches to deliver power over Ethernet to D-Link wireless Access

Point, IP Camera and IP phone, which didn’t support PoE. This allows you to place

those D-Link devices virtually anywhere in a building where power outlets are not

available. DWL-P50 Unit splits the data and DC power apart form D-Link PoE switch

and then supplies them to D-Link wireless Access Point, IP Camera and IP phone.

(Please refer appendix A for DWL-P50 compatibility with D-Link products )

Warning: Please follow the

instructions in this guide carefully.

Connecting these adapters

incorrectly may result in damage

to you network devices.

Connecting The DWL-P50

P+DATA IN:connect a CAT

5 RJ-45 straight- through

cable from PoE switch.

Use the Voltage Selector to set the DC output to 5V(11.5W) or 12V(12W)

depending upon your Network device’s power speciﬁcations.

Voltage Selector:used to

select DC 5V (11.5W) or

12V (12W)

LAN OUT:connect a CAT

5 RJ-45 straight- through

cable to an Ethernet

enabled device.

DC OUT:supplies 5V or

12V of power. Using the

included power cable,

connect to your Ethernet

enabled device’s power.

Use a CAT 5, 5e, or 6 UTP/STP straight-through Ethernet cable

Select voltage that your device requires before connect

power cable to power receptor. Incorrect voltage selection

may damage product.

Connecting The DWL-P50

Connect a Cat 5 Ethernet cable from the PoE port of switch (For example:

1~8 port of D-Link DES-1316) to the “P+DATA IN” of DWL-P50

Connect the provided Cat 5 Ethernet cable from DWL-P50 “LAN

OUT” to the RJ-45 LAN port of the Network Device.

Insert the Female-to-Female Power cable into “DC OUT” and the power

receptor of the Network Device. The Power LED of the Network Device

should light up.

Connecting The DWL-P50(continued)

Installation is complete! Your Network Device should have power and

data, and function normally.

Features

. IEEE 802.3af compatible.

. Optional output 5VDC or 12VDC.

. No Software Required and Operating System Independent.

. Work with D-Link PoE switches DES-1316 to provide Wireless AP, Internet

Camera, IP Phone or Equivalent 5VDC or 12VDC System.

Speciﬁcations

. Voltage

. Output: 5VDC or 12VDC

. Power Output

. Output: 11.5W(5VDC) or 12W(12VDC)

. Ethernet

. Connector: RJ-45

. Data Rate: 10/100Mbps

. Cable: TIA/EIA - 568, Category 5

. Dimensions

. 8.09 x 5.2 x 2.8cm

. Weight

. 80grams

. Temperature

. Operating: 0°C to 40°C (32°F to 104°F)

. Storage: -40°C to 70°C (-40°F to 158°F)

. Humidity

. Operation: 10%-80% RH

. Storage: 5% ~ 90% RH

Technical Support

You can ﬁnd software updates and user documentation on the D-Link websites.

If you require product support, we encourage you to browse our FAQ section on

the Web Site before contacting the Support line. We have many FAQ’s which

we hope will provide you a speedy resolution for your problem.

For Customers within

The United Kingdom & Ireland:

D-Link UK & Ireland Technical Support over the Internet:

http://www.dlink.co.uk

ftp://ftp.dlink.co.uk

D-Link UK & Ireland Technical Support over the Telephone:

08456 12 0003 (United Kingdom)

+1890 886 899 (Ireland)

Lines Open

8.00am-10.00pm Mon-Fri

10.00am-7.00pm Sat & Sun

For Customers within Canada:

D-Link Canada Technical Support over the Telephone:

1-800-361-5265 (Canada)

Mon. to Fri. 7:30AM to 9:00PM EST

D-Link Canada Technical Support over the Internet:

http://support.dlink.ca

email: [email protected]
