Creative BLASTERAXX AXX 200 User manual

THE INTELLIGENT WIRELESS

SOUND SYSTEM

Master Volume/

VoiceFX Preset Indicator

Rear microphones

Call Button/

VoiceFX

Scroll UP

Noise Reduction/

Siren ON/OFF

Voice Focus

ON/OFF

SBX Pro

Studio/

VoiceFX

ON/OFF

Mic Mute/

VoiceFX

Scroll DOWN

Speaker

Mute

YOUR AXX 200 AT A GLANCE

Micro-USB

Port

Headphone

Jack

USB

Charging Port

NFC

Mic On/Mute

Voice Recording

MicroSD Slot

Megaphone

Power/

Bluetooth

Play/Pause

Next Track/

Next Folder

Previous Track/

Previous Folder

Voice Playback

Shuffle/

Repeat All

Port Tube

for enhanced

bass

Aux/

Mic Jack

Power/

Bluetooth

button

lPower On – Press once

lStandby – Press once

when powered on

lWake up from Standby –

Press again

Bluetooth

pairing –

Press and hold 2 sec

lPower Off – Press and

hold 5 sec

Your AXX 200 comes with a Super Megaphone feature

Grab attention using

the Super Megaphone

function! Be the center

of attention when you

amplify your voice with

the Super Megaphone.

After use, be

sure to slide

the Megaphone

switch back to

the middle to

deactivate it.

The Super Megaphone even has a Push-to-talk Mode

Here’s how you do it!

1Switch on the Super Megaphone.

2Speak into the

rear microphones.

Place microphones

close to your mouth to

minimize feedback.

Here’s how you do it!

Just slide and hold the switch while speaking

into the rear microphones.

Amplify your voice

on-the-ﬂy with the Super

Megaphone Push-to-talk

mode. This is great for a

quick shout out to a crowd.

Mode

Push-to-talk Mode

Megaphone Switch

DID YOU KNOW? Super Megaphone

1Switch on the Super Megaphone

(see pg 3).

2Tap SBX to activate .

3Select a preset effect.

4Speak into the rear microphones.

Scroll up Scroll down

DID YOU KNOW?

Morphing your voice is effortless with the AXX 200

Here’s how you do it!

VoiceFX lets you modify your voice with various fun

effects. Once you’ve tried it, you’ll never want to

sound boring again. And you don’t even need to be

connected to a computer or a mobile device!

Each segment level of the

Volume Slider represents a

VoiceFX effect.

When VoiceFX is turned

on, the segments in the

Volume Slider light up for

3 seconds to indicate the

active VoiceFX preset. After

3 seconds, it will go back to

displaying the volume level.

Orc

Female

Male

Munchkin

Scrappy Kid

Unstable

Robot

Echo

VoiceFX

DID YOU KNOW?

App and software let you choose up to 17 VoiceFX characters

Get up to 17 different VoiceFX characters when you use the Sound Blaster Central mobile

application or the Sound BlasterAxx Control Panel software for PC/Mac.

To use the Sound Blaster Central mobile application,

simply connect your smart device to the AXX 200 via

Bluetooth

or NFC.

Download the Sound Blaster

Central app now!

When your AXX 200 is connected

to a computer, use the

Sound BlasterAxx Control Panel

instead to select the different

VoiceFX options.

Visit www.creative.com/

support to download

the Sound BlasterAxx

Control Panel.

VoiceFX

DID YOU KNOW?

Your AXX 200 has a built-in music player

Besides streaming music from

your smart device wirelessly

via

Bluetooth

, the AXX 200 can

also play audio ﬁles from a

microSD card with the built-in

music player.

Here’s how you do it!

1Insert a microSD card.

2Press PLAY.

Skip tracks (in Repeat All mode):

Press or during playback.

Skip folders:

Press and hold or during playback.

Press or when playback is stopped.

You can play WMA, WAV or

MP3 ﬁles.

lThe AXX 200 supports

microSD or microSDHC

cards up to 32GB.

lMusic playback is not

possible when an external

audio device is connected

to the AUX jack.

lAAC ﬁles are not supported

by the built-in player.

However, you can stream

playback of AAC ﬁles from

your smart device via

Bluetooth

lSee Organizing audio ﬁles

on microSD card using

a computer, pg 19 in the

User’s Guide (available

online).

microSD Card

Music Player

DID YOU KNOW?

The AXX 200 also features Karaoke on-the-go!

Bring out your inner diva

with Karaoke on-the-go!

Simply play your favorite

song and sing along. It is so

convenient, you can enjoy

Karaoke anytime, anywhere.

For better audio

reproduction, turn off

Voice Focus.

Here’s how you do it!

1Choose a music source.

2Switch on the Super Megaphone.

3Sing into the rear microphones.

microSD Card

Karaoke Anywhere

DID YOU KNOW?

Recording your voice or singing is made easy with AXX 200

If you need to make a voice recording or

even a song demo on-the-ﬂy, the AXX 200

is all you need! The AXX 200 comes with 4

high-quality microphones that deliver an all

round 360° voice pick-up, making it ideal

for accurate voice recording. Just insert a

microSD card, and you’re ready to go.

Here’s how you do it!

1Insert a microSD card.

2Make sure the microphones

are turned on.

3Press REC .

Audio recording is saved in WAV

format in the VOICE folder.

lFor recording, a Class 4 microSD/

microSDHC card is recommended.

lIt is a good practice to use a new

microSD card for recording.

lThe default recording sampling

rate is at 16 kHz. This is designed

to record longer voice recording

sessions (e.g. meetings) and avoid

large ﬁle sizes. You can switch to

48 kHz, which is ideal for shorter,

higher quality Karaoke music

recording (see User’s Guide, pg 40).

lSimultaneous audio playback and

recording on a microSD card is not

supported.

lPlayback of recordings always start

with the latest recording, followed by

the ﬁrst recording and then the next

in sequential order.

The pulsing Mic Mute

button indicates that

recording is ongoing.

Stop recording:

Press REC again. A low pitched

“toot” is heard. The Mic Mute

button continues to pulse until the

recording is completely saved.

Playback recording:

Press REC to

playback recorded audio

in the VOICE folder. The Mic Mute

button blinks rapidly.

Skip recording:

Press or during playback.

Start recording after you

hear a “beep”.

Voice Recording/Playback

DID YOU KNOW?

You can easily call for attention

The AXX 200’s built-in

siren feature is sure to

put you at the center

of attention when you

activate it. So if you need

to alert others quickly,

sound the siren!

Here’s how you do it!

1Switch on the Super Megaphone.

2Activate the siren.

Tap twice: Trigger continuous siren

Tap again: Deactivate siren

lDisable the siren

through the

Sound BlasterAxx

Control Panel under

Advanced Features (see

User’s Guide, pg 39).

lLeaving the siren on for

a long period of time

may prematurely wear

out the speaker drivers.

Switch off the siren

when not in use.

The siren feature was not designed, manufactured, or

sold for use in emergencies. Creative is not liable for

any loss of or damage to life, health or property as a

result of the use of this product feature.

Siren

DID YOU KNOW?

The dual-purpose battery powers your AXX 200 and also charges

your external device!

Here’s how you do it!

In Standby mode, only

the middle LED lights up.

To check the battery level,

press POWER once.

In On mode, the three white

LEDs light up according

to the battery level of your

AXX 200.

Dual-Purpose Battery

l While charging, the AXX 200 does not go into

Standby mode.

lFor optimal charging, it is recommended to

keep the volume low while the AXX 200 is

being charged, or when charging an external

device (e.g.: phone, MP3 player, etc.).

lWhen turned on, some external devices

require a higher charging rate than battery

banks can typically provide. For the quickest

charging time, turn off your external device

before charging it.

lLithium ion battery life may suffer when it is

constantly fully depleted or overexerted at

low voltage. It is a good practice to keep the

battery well charged.

lWhen the battery is low while playing at loud

volumes, the ampliﬁer will intelligently and

automatically adjust the volume to a lower

and appropriate level so as to extend the

battery life.
