Costway TQ10082 User manual
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Folding Poker Table
TQ10082
USER’S MANUAL
Before You Start
General Warnings:
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can lead to
a danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please use this product with caution. The use of this product requires superb skills
to avoid accidents to the user or others due to a fall or collision.
Please wear suitable protective equipment during use, e.g. protective helmet,
gloves, knee pads, elbow pads etc.
Warnings:
Attention! Use it with protective equipment.
Attention! Not use it in the traffic.
Attention! The product is not suitable for the children under 3 years.
Please read all instructions carefully and keep it for future reference.
02
Safety Alert:
Contains small parts, not suitable for
children under 36 months!
Maximum Load: 66 lbs/30 kg
Please read and understand this manual before use!
This manual contains important information, please keep it for future
reference. Before using for the first time, please charge the battery
for at least 4-6 hours, but not more than 10 hours.
Safety Alert: This stroller must be assembled by an adult.
ASpecifications
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or re-chargeable
batteries.
Only use the battery(ies) specified by the manufacturer.
Only use the charger(s) specified by the manufacturer.
The battery is replaceable.
03
Specifications
Battery
Charger In-put
Motor
Suitable age
Charging time
Maximum load
Car size
Package size
Speed
6V4.5Ah*1
6V500MA
RS380SP 6V (380#) 25W RPM12000*2
37-95 months
6-10 hours
66 lbs/30 kg For one person only
26*26*18.7”/66.5*66.5*47.6 cm
26*8.8*26”/66.5*66.5*47.6 cm
2-2.5miles/h, 3-6Km/h
Battery Safety Alert
● Non-rechargeable batteries cannot be charged;
● The rechargeable battery can only be charged under adult
supervision;
● Different types of batteries or old and new batteries cannot
be mixed;
● The battery should be inserted with the correct polarity;
● The power terminals must not be short-circuited;
● Exhausted batteries should be removed from the toy
04
B
Spare parts list
2
3
13
1
4
56
7
8
9
10 11 12
Number Name Image Quantity
Cushiong screw1 1
Head stock2 1
Backrest3 1
05
Seat4 1
Wheel5 2
Motor6 2
Body7 1
Universal wheel8 2
Rear axle9 1
Fixed piece10 2
Gasket11 2
M8 machine screw12 2
M4*14 screw13 20
06
CSafety Alert
To prevent accidents
● The vehicle must be under adult supervision. Always be within
the sight of an adult when in use.
● When driving a vehicle, you should wear a protective helmet,
must wear shoes, must sit in the seat.
● Ensure that your child is driving the vehicle in a safe driving
environment, home, garden or playground.
● The maximum load-bearing capacity of this car is 66 lbs/30 kg,
and it is limited to one person.
● It is forbidden to drive this vehicle in unsafe areas, such as
public transportation roads.
Warning
● Contains small parts, not suitable for children under 36 months
● The product must be assembled by an adult!
● The assembly contains potentially dangerous sharp edges or
sharp points!
WARNING :
To reduce the risk of injury, adult supervision is required. Never use
in roadways, near motor vehicles, on or near steep inclines or steps,
swimming pools or other bodies of water, always wear shoes, and
never allow more than one rider.
RISK OF FIRE. Do not bypass. Replace only with 5A protector.
CHOKING HAZARD—Small parts. Not for children under 3 yrs.
07
08
D
Wheels Assembly
As the picture shows:
1. Turn the body over and install the motor(Plug in the motor connection wire
pair according to the wire color and embed it in the body hole.)
2. Insert the wheels into the rear axle, follow the gasket, and tighten it with a
M8 machine screw. The other wheel is the same way.
As the picture shows:
Put the two universal wheels into the slots and, choose the M4*14 screws to
tight into the car body.
09
EFront Faucet and Backrest Assembly
1. Connect the wire from the head stock with the car body according to their
same color.
2. Insert the head stock into the car body according to the slot.
3. Tighten it with car body with the M4*14 screws.
4. Insert the backrest into the back position, and fix it with M4*14 screws.
10
Battery Connection and
Cushion Installation F
As shown in the figure, please connect the power wire according to their
same color, before tight the seat with the cushion screw!
Insert the seat into the slot as shown in the picture.
1 and 2: car front and rear switch, two forwards at the same time according
to move the car forward; two forwards at the same time according to move
the car backward; the separate handle controls left and right turns
separately.
3: for the player, can play songs alone and can also use the tool to
outsourcing
outsourcing
4: the car power supply
5: the light switch (optional)
12
4
5
3
