COOPER LIGHTING - LUMARK®
INDUSTRIAL
534 COOPER LIGHTING
DIMENSIONS
• Mounting hub is tapped
with an opening for 3/4"
conduit. Ballast cover is
easily removed for easy
wiring and installation
• The heavy-duty, spun
aluminum housing is
finished in a white
polyester powder coat
standard. Other finish
colors available
• Compact Fluorescent
electronic ballast in
1 or lamp configuration
provides up to four (4)
switch level control or
optional dimming
ballast. Compact
Fluorescent ballast are
electronic, universal
voltage 120-277V, less
than 10% harmonic
distortion, with minimum
starting temperature of
0°C for 32, 42W and
-30°C (-22°F) for 60 and
120W
• Compact Fluorescent
sockets are rotary lock
high temperature PBT
material and incorporate:
32W GX24q3 or 42W
GX24q4. 60 and 120W
is a 2G8
• Available with high-
efficiency 22" prismatic
acrylic refractor or 22"
high-reflectance white
spun aluminum reflector
• Optional drop bottom
and conical bottom
refractor or safety glass
bottom door
• Approximate net weight:
37 lbs. (16.82 kgs.)
DESCRIPTION
The AXIO Series Luminaire
offers unmatched photometric
performance with an updated
housing style. A wide range of
lamp, ballast and optical
choices gives the DP series
unmatched flexibility and
performance capabilities.
U.L. listed and CSA certified
for damp location standard.
The AXIO Series is perfect for
school gymnasiums, multi-
purpose rooms, retail stores,
auto showrooms, and
manufacturing assembly
areas.
DP
AXIO
192-360W
Compact Fluorescent
COMPACT FLUORESCENT
HIGH-BAY INDUSTRIAL
LUMINAIRE
NOTES: 1 Specify voltage with emergency ballast, plug or MWS options. 2Add as suffix in the order shown. 3Non-switched products provided with standard 3' cord
and NEMA plug (120V-L5-15P, 208V-L6-15P, 240V-L6-15P, 347V-L37-20P, AND 480V-L8-20P). Dual and Triple switching available with cord and plug option in 120
or 277V only. “TS” switching (120V-L21-20P and 277V-L22-20P), “DS” switching (120V-L15-20P and 277V-L16-20P). Consult your Cooper Lighting representative
for wiring and circuit details. 4Marked ballast leads pulled out of housing for easy identification. Pendant mount only. Not available with cord and plug options.
5Specified for lamp to ship with order. Lamp is shipped separate from luminaire. Lamp is Cooper designated product based on luminaire requirements.
6Order separately. 7Wire guards and lens enclosures should be used for any application needing additional protection such as gymnasiums. 8Add as suffix in
the order shown. 9Specifications and dimensions subject to change without notice.
22" [559mm]
Maximum Height is
27 7/8" [708mm]
Drop Bottom Adds
3 1/2" to Overall Height
ORDERING INFORMATION
SAMPLE NUMBER: PLDP-PC22-3/120-E-LL
Lamp Type
PL=Compact
Fluorescent
Series
DP=AXIO Series
Refractor Type
PC22=22"
Prismatic
Acrylic
SC22=22" Spun
Aluminum
White
Lamp Wattage
6/32=(6) 32W Triple Tube
8/32=(8) 32W Triple Tube
6/42=(6) 42W Triple Tube
8/42=(8) 42W Triple Tube
4/60=(4) 60W PLH
3/120=(3) 120W PLH
Voltage
120V
208V
240V
277V
E=Electronic
(120-277V)
Options &
Accessories
(See Below)
Options 2
PC3=3' Cord with NEMA Plug (No Switching) 3
PC3/4C=3' Cord with NEMA Plug (Dual Switching) 3
PC3/5C=3' Cord with NEMA Plug (Triple Switching) 3
C3=3' Cord with No Plug. Must be used with FH-1
or FL-1 (No Switching) 3
FH-1=Fixture Hook
FL-1=Fixture Loop
SCF=3' Aircraft Safety Cable
CF/EM=External Battery Backup 4
DS=Dual Switching 3
TS=Triple Switching 3
QS=Quad Switching 3
I42EB=Internal 42W Emergency Ballast
LL=Lamps Included 5
Accessories 6
FH-1=Fixture Hook
FL-1=Fixture Loop
PC3=3' Cord with NEMA Plug 3
CB22=Conical Bottom Lens for 22" Refractor
DB22=Drop Lens for 22" Refractor
WGD22=Wire Guard for PD or PC 22" Refractor (Not compatible with SGB22) 7
WG22/SGB=Wire Guard with Glass Lens for Refractor (Available for PD or PC only)7
SGB22=Safety Glass Bottom for PD 22" Refractor (Not compatible with WG22) 7
FWG22/WDB=Full Wire Guard for use with DB22 Drop Lens and PD 22 Refractor 7
Lamp
Refractor Wattage
90°C
25°C *
40°C
Supply
Wire (Min.)
Ambient
Environment
DP 192-360W
NOTES: * 3/120W PL-H Lamps.
