Integration Note

Help us improve our technical communication. Let us know what you think

about the technical information in this document. Your feedback is valuable

and will help us structure future communications. Please send your

comments to: CompaqNT@compaq.com

March 2001

145Z-0301B-WWEN

Prepared by OS Integration

Engineering

Compaq Computer Corporation

Contents

Introduction..................................3

Requirements...............................3

Recommended

Requirements.............................3

Required Information..................4

Additional Information ................4

Required Components ...............4

Installation Instructions ..............7

Part 1: Installing Microsoft

SBS 2000...................................7

Part 2: Installing and

Configuring Modem and

Network Interface Controllers

with Microsoft SBS 2000 ..........12

Upgrade Considerations ...........13

In-place Upgrade......................13

Migration Upgrade....................14

Microsoft Windows 2000

Server Upgrade........................14

Appendix A–Compaq Web

Resources ..................................15

Appendix B-Microsoft Web

Resources ..................................15

Microsoft Small Business

Server 2000 Installation

Instructions for Compaq

Prosignia and ProLiant Servers

Abstract: This document provides instructions for installing the

Microsoft Small Business Server (SBS) 2000 software on specified

Compaq Prosignia and ProLiant servers.

The Microsoft SBS 2000 software may not supply the necessary

updated drivers for the following Compaq servers: Prosignia Server

720, Prosignia Server 740, ProLiant 400, ProLiant 800, ProLiant

1600, ProLiant ML330, ProLiant ML350, and ProLiant ML370. This

document provides systematic instructions to identify and to install

the necessary drivers, allowing successful completion of the

Microsoft SBS 2000 software installation. Also, provided in this

document are considerations for upgrading from Microsoft SBS 4.5

to Microsoft SBS 2000.

Note: This document describes the installation instructions for

Microsoft SBS 2000 only. For Microsoft SBS 4.0/4.0(a)/4.5

installation instructions, search the Compaq website for additional

white papers.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 2

145Z-0301B-WWEN

Notice

Compaq, the Compaq logo, NetFlex, ProLiant, ROMPaq, SmartStart, and StorageWorks are registered

United States Patent and Trademark Office.

ProSignia and SoftPaq are trademarks and/or service marks of Compaq Computer Corporation.

Microsoft, Windows, Windows NT, Windows NT Server and Workstation, Windows NT Enterprise

Edition, Microsoft SQL Server for Windows NT are trademarks and/or registered trademarks of Microsoft

Corporation.

Adobe, Acrobat, and the Acrobat logo are trademarks of Adobe Systems, Inc.

Other product names mentioned herein may be trademarks and/or registered trademarks of their respective

companies.

The information in this publication is subject to change without notice and is provided “AS IS” WITHOUT

WARRANTY OF ANY KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF THIS

INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT SHALL COMPAQ BE LIABLE FOR

ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE OR OTHER DAMAGES

WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS

PROFITS, BUSINESS INTERRUPTION OR LOSS OF BUSINESS INFORMATION), EVEN IF

COMPAQ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

The limited warranties for Compaq products are exclusively set forth in the documentation accompanying

such products. Nothing herein should be construed as constituting a further or additional warranty.

This publication does not constitute an endorsement of the product or products that were tested. The

configuration or configurations tested or described may or may not be the only available solution. This test

is not a determination or product quality or correctness, nor does it ensure compliance with any federal

state or local requirements.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers

Integration Note prepared by OS Integration Engineering

Second Edition (March 2001)

Document Number 145Z-0301B-WWEN

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 3

145Z-0301B-WWEN

Introduction

This document provides instructions for installing the Microsoft SBS 2000 on the following

Compaq servers:

•Prosignia Server 720

•Prosignia Server 740

•ProLiant 400

•ProLiant 800

•ProLiant 1600

•ProLiant ML330

•ProLiant ML350

•ProLiant ML370

These instructions do not apply to other Compaq server models.

Note: This document describes the installation instructions for Microsoft SBS 2000 only. For

Microsoft SBS 4.0/4.0(a)/4.5 installation instructions, search the Compaq website for additional

white papers.

Requirements

As with all new operating systems, there are certain recommended requirements to meet prior to

installation. The following sections detail the hardware and software requirements enforced by

the Microsoft SBS 2000 operating system.

Recommended Requirements

Table 1 and Table 2 list the recommended hardware and software requirements.

Table 1. Hardware requirements

√Hardware

Compaq Prosignia Server 720, Prosignia Server 740, ProLiant 400,

ProLiant 800, ProLiant 1600, ProLiant ML330, ProLiant ML350, or ProLiant

ML370 with a Pentium II 300 MHz or greater processor.

256-MB RAM minimum (384 or more RAM recommended)

Computer monitor, keyboard, and mouse

1 network interface controller (NIC)

Hard drive with at least 6 GB free space (formatted as NTFS)

1.44-MB diskette (floppy) drive

At least 1 blank diskette

CD-ROM drive

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 4

145Z-0301B-WWEN

Table 2. Software requirements

√Software

Microsoft SBS 2000

•5 CD-ROMs

Compaq SmartStart and Support Software CD-ROM (supplied with the

Compaq server)

For Prosignia Server 720 or ProLiant 400 only:

Must use 11 May 1999 ROM or later for SmartStart 4.80 (or later) support.

This ROM image can be downloaded from the Compaq Server Software

Download Center, commonly known as the Compaq Support Software

website, (http://www.compaq.com/support/files/server/us/index.html).

Required Information

Table 3 lists additional information you need to know for the installation.

Table 3. Information required for installation

√Information

Name of licensee for the Microsoft Small Business Server 2000 software

Name of your organization

Name of server

Name of domain

Product ID for the Microsoft SBS (see software packaging)

Additional Information

This section contains additional information about the installation.

Installing With or Without a Modem

The installation instructions contain information on installing Microsoft SBS 2000 for servers

configured with and without a modem.

Review Table 4 for additional minimum requirements if you plan to install the Microsoft SBS

2000 software on a Compaq Prosignia and ProLiant server with a modem. Refer to the Microsoft

SBS 2000 user documentation for the services that will be available with various modem types.

Table 4. Additional requirements if you have a modem

√Additional Minimum Requirements

Driver for modem (supplied by the modem manufacturer)

Area code and phone number for telephone line(s) connected to modem(s)

Required Components

Compaq Support Paq (CSP) for Microsoft Windows 2000, also referred to as the CSP for

Windows 2000, is required for the Microsoft SBS 2000 software installation. This section

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 5

145Z-0301B-WWEN

provides two sets of instructions to obtain individual components or the complete CSP for

Windows 2000 bundle.

Using Compaq Server Download Center to Create Compaq Support Paq for

Microsoft Windows 2000 Components

If you use the Compaq Server Software Download Center to create Compaq Support Paq (CSP)

for Microsoft Windows 2000 components, refer to the procedures included in Table 5.

Note: The instructions provided in Table 5 detail procedures for creating the necessary storage

component. You may also want to extract the driver for your network interface controller (NIC) if

Microsoft SBS 2000 does not contain the base drivers for it. NIC drivers are accessible via the

Network category link presented in step 2.

Table 5. Creating CSP for Windows 2000 components

√Procedures Steps

Downloading and

creating CSP for

Windows 2000 Smart

Components from the

Compaq website

1. Go the Compaq Server Software Download Center by accessing this

URL: http://www.compaq.com/support/files/server/us/index.html.

2. Select your server(s) from the Family drop-down list box, select

Microsoft Windows 2000 from the Operating System drop-down list

box, and click the Go button.

This procedure takes you to the Locate page, listing the available

software by categories.

3. Click the Storage category link.

4. Select the Smart Component (driver) for the primary storage controller

used in your server by clicking the software version link listed in the

Current Version column next to the desired Smart Component.

This procedure takes you to the Download page, listing the

enhancements, fixes, and installation information.

5. Click the Download button to download the file.

6. Execute the appropriate storage component after the download

completes.

7. Select the option to Extract the driver to a temporary directory on your

server, and then close the Compaq Package Setup window. Go to this

temporary directory.

8. Execute the FLOPPY.BAT file to create the boot diskette containing

the appropriate driver files.

9. Return to the Compaq Server Software Download Center once the

Microsoft SBS 2000 installation completes and download the

complete CSP for Windows 2000 bundle onto your server by following

these steps:

a. Repeat step 2.

b. Click the Bundles (Drivers and Agents) category link.

c. Select the Compaq Support Paq for Microsoft Windows 2000

bundle by clicking the software version link listed in the Current

Version column next to the bundle name.

This procedure takes you to the Download page, listing the

enhancements, fixes, and installation information for all Smart

Components that comprise the CSP for Windows 2000 bundle.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 6

145Z-0301B-WWEN

√Procedures Steps

Downloading and

creating CSP for

Windows 2000 Smart

Components from the

Compaq website

(continued)

d. Click Download All Components.

10. Execute the CSP for Windows 2000 to update your operating system

with the latest Compaq drivers, agents, services, and utilities (go to

the specified download directory and double-click SETUP.EXE).

Using SmartStart Release 4.70 or Later to Create and Install CSP for

Windows 2000 Components

If you use Compaq SmartStart and Support Software CD-ROM Release 4.70 or later to create and

install the CSP for Windows 2000, refer to the procedures included in Table 6 and Table 7

respectively.

Table 6. Creating Compaq CSP for Windows 2000 using SmartStart release 4.70 CD-ROM or later

√Procedures Steps

Creating storage driver

diskette using the

SmartStart and Support

Software CD-ROM

Note: You are only required to create the driver diskette for your primary

storage controller and network interface controller (NIC) if the Microsoft

SBS 2000 media does not contain the base driver.

1. Insert the SmartStart and Support Software CD-ROM into the CD-

ROM drive on a Microsoft Windows operating system.

2. Select the I Agree check box and click OK.

3. Select to Exit when the System Utilities interactive window appears.

4. Open Windows Explorer and explore the SmartStart and Support

Software CD-ROM contents.

5. Go to the CPQSUPSW\NTCSP directory and open the

BP0000XX.TXT file (where XX represents the bundle number).

6. Review “Section 3: Component Usage” of the text file to determine the

required Smart Component package for installing the driver for the

primary storage controller in your server.

7. Close the BP0000XX.TXT file once you have determined the

appropriate Smart Component and execute this Smart Component

from the same directory.

8. Select the option to Extract the driver to a temporary directory on your

server, and then close the Compaq Package Setup window. Go to this

temporary directory.

9. Execute the FLOPPY.BAT file to create the boot diskette containing

the appropriate driver files.

10. Set aside the diskette created for use during the installation of

Microsoft SBS 2000.

Note: You may also want to extract the driver for your NIC if Microsoft

SBS 2000 does not contain the base drivers for it.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 7

145Z-0301B-WWEN

Table 7. Installing CSP for Windows 2000 using SmartStart 4.70 release CD-ROM or later

√Procedures Steps

Installing the CSP for

Windows 2000 from the

SmartStart and Support

Software CD-ROM

1. Insert the SmartStart and Support Software CD-ROM into the CD-

ROM drive once Microsoft SBS 2000 installation completes.

2. Select the I Agree check box and click OK.

3. Select to install the Compaq Support Paq and click OK when the

System Utilities interactive window appears. This action launches the

Compaq Remote Development Utility.

4. Select the Install button on the Compaq Remote Deployment Utility to

install all the components applicable to your server.

Installation Instructions

The installation instructions are comprised of two parts: (1) installing Microsoft SBS 2000, and

(2) installing and configuring modem and network interface controllers (NIC) with Microsoft

SBS 2000. Each part divides the procedures into tasks, providing detailed information and check

boxes to guide you through the installation process.

Part 1: Installing Microsoft SBS 2000

This section provides the steps you must perform to begin the Microsoft SBS 2000 installation.

The procedures detailed in Table 8 guide you through the necessary steps if you choose to install

without a modem or with a modem.

Note: The following steps assume that you have already created the driver diskette from the

CSP for Windows 2000 components for your primary storage controller. If you have not created

the diskette, refer to the procedures listed in Table 6. Creating Compaq CSP for Windows 2000

using SmartStart release 4.70 CD-ROM or later.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 8

145Z-0301B-WWEN

Table 8. Initial Microsoft SBS installation procedures

√Procedures Steps

Task 1:

Starting the

installation

At the Compaq server on which you want to install Microsoft SBS 2000, complete

these procedures:

1. Insert the SmartStart and Support Software CD-ROM into the CD-ROM drive.

Note: A SmartStart and Support Software CD-ROM came with your server.

You can order a later version from here:

http://www.compaq.com/products/servers/smartstart/index.html.

2. Select your language preference when the first interactive window appears.

The Regional Settings window appears.

3. Click Next.

The System Settings Summary window appears.

4. Click Continue.

The License Agreement window appears.

5. Click I Agree. Then, click OK.

6. Select Manual Configuration under Installation Path. Then, click Begin.

7. Expand the Microsoft tree on the Operating System Selection page.

8. Highlight Microsoft Server 2000. Then, click Next.

9. Click Continue when the Operating System Selection Summary window

appears.

The system restarts. After the system restarts, the System Partition

Installation Utility automatically runs. The system then displays:

Formatting Temporary Swap Partition

After this process completes, the SmartStart and Support Software CD-ROM

restarts at the Diskette Builder window.

10. Click Next to continue the SmartStart process.

11. Click Continue on the Manual Path window.

12. Remove the Compaq SmartStart CD-ROM when prompted and insert the

SBS 2000 CD-ROM #1 and click OK, click Continue to start the installation of

SBS 2000.

13. Do one of the following:

•For ProLiant ML330, ProLiant ML350 (with D02 ROM), and ProLiant

ML370, press the F6 key as soon the starting setup message appears

during the text mode setup; just after booting to the Microsoft SBS 2000

CD-ROM (to specify additional devices). Then, go to step 14.

•For Prosignia Server 720, Prosignia Server 740, ProLiant 400, ProLiant

800, ProLiant 1600, and ProLiant ML350 (with D04 ROM), go to step 20.

•If your server contains a Compaq Array Controller as the primary boot

controller and the driver does not reside on the SBS 2000 CD-ROM, press

the F6 key as soon as the setup message appears during the text mode

setup. Then, go to step 14.

14. Press S to specify your controller.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 9

145Z-0301B-WWEN

√Procedures Steps

Task 1:

Starting the

installation

(continued)

15. Insert the appropriate storage driver diskette created from the CSP for

Windows 2000 for your primary storage controller, when prompted for the

Manufacturer-supplied hardware support disk.

16. Press Enter.

17. Highlight the controller that is your primary boot controller, then press Enter.

18. Press Enter to continue. (It is not necessary to install additional devices.)

19. Press Enter to load the Microsoft device drivers.

20. Press Enter to set up Windows 2000.

21. Press C.

22. Review the Windows 2000 Licensing Agreement and press F8 if you agree.

Task 2:

Choosing disk

carving options

1. Do the following when the partition screen appears:

•Highlight the unpartitioned space and press the Ckey to create a partition.

Then

Use the backspace key to delete the currently displayed number.

Then, type at least 6000 (or greater).

Press Enter to create the partition.

Highlight the New (Unformatted) partition and press Enter to setup

Windows 2000.

Select Format the partition using NTFS file system.

Press Enter to continue.

The setup process formats the partition.

The setup program copies files to the hard drive.

2. Press Enter to restart your server after the copying process completes.

Task 3:

Installing the

operating system

After the system restarts, the Microsoft Small Business Server 2000 operating

system installation automatically starts.

1. Verify the settings on the Regional Settings window and click Next.

2. Supply licensee name and organization on the Personalize Your Software

window and click Next.

Note: At this point, you can change the default computer (server) name and

the default domain.

3. Change the default computer (server) name and enter the administrator

password, if desired.

4. Click Next.

5. Review the components pre-selected on the Windows 2000 Components

window and click Next.

6. Enter your area code and telephone number, if your server contains a

modem, and click Next.

Note: If your server configuration does not include a modem or your modem

driver does not reside on the Microsoft SBS 2000 CD-ROM, you will not

receive a prompt for modem information. You can install the modem after the

installation of Microsoft SBS 2000 by referring to Task 4:

Installing and configuring modem drivers section of this integration note.

7. Enter the Date, Time, and Time Zone on the Date and Time Settings window,

and then click Next.

Microsoft Small Business Server 2000 Installation Instructions for Compaq Prosignia and ProLiant Servers 10

145Z-0301B-WWEN

√Procedures Steps

Task 3:

Installing the

operating system

(continued)

8. Select Typical Settings or Custom Settings when prompted with the

Networking Settings windows and click Next. If you select Custom Settings,

refer to the Microsoft SBS 2000 documentation to complete the Custom

Settings interview options.

Note: If your network interface controller driver does not reside on the

Microsoft SBS 2000 CD-ROM, you will need to select provide the network

card driver from your network card manufacturer. If you plan to add the

network interface controller after Microsoft SBS 2000 installation, refer to

Table 9.

The installation of Microsoft SBS 2000 continues until you are prompted with

the Completing the Windows 2000 Setup Wizard.

9. Remove the SBS 2000 CD-ROM #1 and click Finish to restart your server.

10. Login to your operating system and re-insert the SBS 2000 CD-ROM #1.

The Microsoft Small Business Sever 2000 Setup Window prompt appears.

11. Highlight and click Set Up Small Business Server to begin the Post

Operating System portion of the installation after you determine a plan for

your installation.

Note: Refer to the Microsoft SBS 2000 documentation for help on Planning

your installation.

12. Click Next on the Welcome to the Microsoft SBS 2000 Setup Wizard window.

The Suite Requirements window appears if your system meets all the

requirements to install Microsoft SBS 2000.

13. Follow these procedures based on the listed conditions:

•If your system does not meet all the requirements, click Cancel to exit this

portion of setup. Take corrective action by adding required hardware

and/or reconfigure your base operating system. To take corrective action,

connect necessary components or make modifications, select Back, and

select Next to re-evaluate system.

•If you system meets all the requirements, click Next.

The License Agreement appears.

14. Review the License Agreement. If you agree, select the I agree radio button

and click Next.

15. Verify the Name, Organization, and Computer Name on the Product

Identification window. Then enter the 25-digit key for your Small Business

Server CD-ROM and your Microsoft Outlook CD-ROM. Click Next.

The Automatic Logon Information window prompts you for your password if

you would like Setup to log you on automatically after the system restarts.

16. Select your preference and click Next.

17. Fill out your address information on the Company Information window and

click Next.

18. Fill out your telephone information on the Telephony Information window and

click Next.

Note: You need to enter this information even if you do not have a modem

installed.

Other manuals for ProLiant 400

This manual suits for next models

Table of contents

Other Compaq Server manuals

Compaq

Compaq T5720 - Thin Client General instructions

Compaq

Compaq ProSignia 200 6/233 Operating and safety instructions

Compaq

Compaq BL20p - HP ProLiant - 512 MB RAM Operating and safety instructions

Compaq

Compaq TruCluster Server AA-RHGWC-TE User manual

Compaq

Compaq ProSignia 500 Instruction Manual

Compaq

Compaq AlphaServer ES45 1B User manual

Compaq

Compaq 195294-001 - ProLiant - ML370R User manual

Compaq

Compaq ProLiant 5500 Operating and safety instructions

Compaq

Compaq 108164-003 - ProLiant - 800 User manual

Compaq

Compaq ProLiant ML350 (G2) User manual

Compaq

Compaq DS20E - AlphaStation - 1 GB RAM User manual

Compaq

Compaq DL760 - ProLiant - 1 GB RAM Installation guide

Compaq

Compaq ProLiant 8500 Installation and operation manual

Compaq

Compaq ProLiant 4500 Manual

Compaq

Compaq 231027-002 - ProLiant - DL320R01 Quick reference guide

Compaq

Compaq T5720 - Thin Client Installation guide

Compaq

Compaq 307560-001 - ProLiant - 2500R User manual

Compaq

Compaq ProLiant DL380 Generation 2 Manual

Compaq

Compaq 108164-003 - ProLiant - 800 Quick start guide

Compaq

Compaq CL380 - ProLiant - 256 MB RAM Safety guide

Compaq

Compaq DL320 - ProLiant - G3 Operating and safety instructions

Compaq

Compaq 2500 - ProLiant - 64 MB RAM Manual

Compaq

Compaq DL360 - ProLiant - Photon Manual

Compaq

Compaq AlphaServer GS60E User manual

Popular Server manuals by other brands

HP AlphaServer ES47 Cli reference manual

Dell

Dell PowerEdge R410 Getting started

PowerNAS

PowerNAS CMA quick start guide

Supero

Supero FatTwin F617R3-FT user manual

MSI

MSI P1-109N-L70 user manual

Dell

Dell PowerEdge XE9640 Installation and service manual

Dell

Dell PS4100 Hardware

EtroVISION

EtroVISION EV3151 user manual

NEC

NEC Express5800/T110j System configuration guide

HP ProLiant Gen9 user guide

Dell

Dell PowerEdge 3YPMN Getting started guide

iRobo

iRobo IPC2U user manual

Nortel

Nortel 1000 Con?guration guide user manual

Asus

Asus AP7500 Hardware reference guide

Avid Technology

Avid Technology AirSpeed 5000 manual

HP Integrity rx2600 overview

Milestone

Milestone Husky IVO 350T Getting started

Planet

Planet NAS-7410 user manual
