Commax DRC-4Y User manual
•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.
Color Door Camera DRC-4Y
User Manual
1
1.Introduction................................................... 2
2.Cautions ....................................................... 3
3. Overview....................................................... 4
4. Installation..................................................... 5
5. Package contents ......................................... 6
6. Specification ................................................. 7
Contents
2
The model number is located on the bottom. Please record the serial number in the space provided below.
Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.
Model No. Serial No.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
This symbol is intended to alert the use of uninsulated “dangerous Voltage” within the product that may cause the insufficient
magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the use to the presence of important operating and maintenance(servicing) instructions in the
literature accompanying the appliance.
CAUTION: To reduce the risk of electric shock, do not remove cover (or back cover) no user-
serviceable part inside. Refer service to the service personnel
caution
Risk of electric shock
do not open
1. Introduction
3
2. Cautions
▲
Do not install it to extremely
hot or cold places.
▲
Do not install it under humid
environment.
▲
Do not install it to the
flickering place.
▲
Do not install it to the place
where it will be exposed to oil
and gas.
If used at a place where the
temperature is higher than
40 ℃ or lower than -10 ℃,
it may cause deterioration of
image quality or failure.
Pay attention to the
ventilation, especially when
installing in a hot place.
Installing in a humid place will
cause deterioration of the lens
and cause low quality image.
Malfunctions may occur in high
illumination changing areas,
such as unstably flickering
lightings.
Malfunctions may occur
when oil or gas permeate
to the products.
4
①
②
Microphone : It delivers voice from a visitor
③
Camera Lens : Transferring image
※It should be kept clean
④Speaker : It delivers voice to a visitor
⑤Call Button : Call a residence
⑥
⑦
⑧
⑨
Door Release Connection Terminal
Monitor Connection Terminal
olume Control (1.2~1.5mm [ - ] driver available)
Wall Bracket
3. O er iew
LED & Illumination Sensor : Offer clear image at night
5
1. Fix a bracket on a wall with screws
2.
Connect wire #1, 2, 3, 4 on the back side of a door camera with a monitor as shown in
[FIG-2] (#1 : OICE, #2 : GND, #3 : DC12 , #4 : IDEO)
3. Put a door camera unit into a wall bracket
4. Wire door release connection terminal as shown in [FIG-2]
5. Tighten a screw at the bottom side of a door camera. [FIG-1]
4. Installation
SCREW GH1T 4*18(2EA)
Monitor Cable
Door Release Cable
Door Release
SCREW BHM M3*6(1EA)
Power Source
6
5. Package contents
7
92(W) x 150(H) x 35(D)
Model No.
Rated Voltage
Wiring
Video Transmission Standard
Sensor Type
Transmission
Minimum Illumination
LED
Effective Viewing Angle
Operating Temperature
Weight (g)
Dimension (mm)
Installation between a Door
camera and a monitor(TIV Cable)
Wiring
12V (Supplied from monitor)
4 wires (polarity) to a monitor
2 wires (non-polarity) to a electric door lock
NTSC or PAL STANDARD.
C-MOS(COLOR / 0.52 megapixel)
Full Duplex
0.1 Lux (within 300mm)
Embedded LED (night working)
98°
-10°C (tested up to -40°C)~ +40°C
186g
Diameter(pie) Ø
0.5
Ø
0.65
Ø
0.8
Ø
1
Distance(meter)
28m 50m 70m 115m
6. Specification
DRC-4Y
8
Memo
Printed In Korea / 2019.04.105
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133
Web site : www.commax.com
