ComAp InteliDrive Lite User manual

Written by Jaroslav Juriga

Prague, Czech Republic

ComAp a.s., U Uranie 1612/14a,

170 00 Prague 7, Czech Republic

Tel: +420 246 012 111

E-mail: info@comap-control.com, www.comap-control.com Global Guide

InteliDrive Lite

&Telecom

Engine controller for pumps,

compressors and Telecom

applications

SW version 2.5.0

1 Document information 5

2 System overview 8

3 Applications overview 13

4 Installation and wiring 14

5 Controller setup 33

6 Troubleshooting 72

8 Technical data 87

9 Appendix 89

Table of contents

1 Document information 5

1.1 Clarification of Notation 5

1.2 About this guide 5

1.3 Legal notice 5

1.4 Document history 7

1.5 Language support 7

2 System overview 8

2.1 Warnings 8

2.2 General description 8

2.3 Configurability and monitoring 9

2.3.1 Open connection from LiteEdit 9

2.3.2 Open connection from web browser 10

2.3.3 Open connection from WinScope 11

3 Applications overview 13

4 Installation and wiring 14

4.1 Mounting 14

4.2 Package contents 15

4.2.1 Software package 15

4.2.2 Components 15

4.3 Terminal diagram and dimension 16

4.4 Extension plug-in modules 17

4.4.1 Extension plug-in modules installation 17

4.4.2 IL-NT AOUT8 17

4.4.3 IL-NT AIO 20

4.4.4 IL-NT IO1 21

4.4.5 IL-NT BIO8 22

4.5 Communication modules 22

4.5.1 IL-NT RS232 22

4.5.2 IL-NT RS232-485 23

4.5.3 IL-NT S-USB 23

4.5.4 IB-Lite 24

4.5.5 IL-NT GPRS 24

4.6 Remote modules 25

4.6.1 IL-NT RD (SW) 25

4.6.2 IL-NT RD software installation 26

4.6.3 IL-NT-RD Wiring 27

4.6.4 IGL-RA15 (EM2IGLRABAA,

EM2FPCRAEAA) 27

4.6.5 IB-NT 28

4.7 How to install 29

4.7.1 Grounding 29

4.7.2 Wiring 29

4.7.3 Power supply 30

4.7.4 Power supply fusing 30

4.7.5 Binary output protections 31

4.7.6 Magnetic pick-up 31

5 Controller setup 33

5.1 Analog inputs 33

5.1.1 Table of controller analog inputs 33

5.1.2 Table of analog inputs options 35

5.1.3 Connection of InteliDrive Lite analog

inputs 37

5.1.4 Current output transducers 38

5.1.5 Analog input extension measurement 38

5.2 Binary inputs and outputs 41

5.3 Analog outputs 42

5.3.1 Default analog output curves 43

5.4 Remote modules - CAN bus connection 43

5.4.1 Connection rules 43

5.5 Front panel elements 44

5.6 Init screens 46

5.6.1 Init screen 46

5.6.2 Firmware screen 46

5.6.3 Languages screen 46

5.6.4 User Interface screen 46

5.7 Display menus 47

5.7.1 Switching between User and Engineer

menus 47

5.8 How to select the engine mode? 47

5.9 How to view measured data? 47

ID-FLX Lite & Telecom Global Guide 2

5.10 How to view and edit setpoints? 47

5.10.1 How to change the display contrast? 48

5.10.2 How to check software revision? 48

5.10.3 How to check the serial number and

choose interface? 48

5.10.4 How to change language? 48

5.11 How to find active alarms? 48

5.12 How to list History records? 49

5.13 MEASUREMENT screens description 49

5.13.1 Main measure screen 49

5.13.2 InteliDrive Lite Analog inputs screens 50

5.13.3 IL-NT-AIO Analog inputs screen 50

5.13.4 InteliDrive Lite Binary inputs 50

5.13.5 InteliDrive Lite Binary outputs 50

5.13.6 IL-NT-BIO8 Binary inputs screen 51

5.13.7 IL-NT-IO1 Binary inputs screen 51

5.13.8 ECU State 51

5.13.9 ECU Values 52

5.13.10 Statistic 52

5.13.11 ECU AlarmList 52

5.13.12 Alarm list 53

5.14 Display screens and pages structure 54

5.15 Functions 55

5.15.1 Engine operation states 55

5.15.2 OFF mode 55

5.15.3 MAN mode 55

5.15.4 Start-stop sequence (simplified) 55

5.15.5 AUT mode 57

5.15.6 Engine without pickup operation 57

5.15.7 Engine timer 58

5.15.8 Protections 58

5.15.9 Engine RPM control in MAN mode 59

5.15.10 AUT mode: Engine load limitation –

overview 61

5.15.11 AUT mode: Engine regulation by

RPM control – overview 67

6 Troubleshooting 72

6.1 Alarm management 72

6.1.1 Sensor fail (Fls) 72

6.1.2 Warning (Wrn) 72

6.1.3 Cooldown (Cd) 72

6.1.4 Shut down (Sd) 73

6.1.5 List of possible alarms 73

6.2 History file 75

6.2.1 Record structure 75

6.3 Diagnostic messages read from ECU 76

6.3.1 List of ECU diagnostic codes 77

6.4 Tier 4 diagnostic codes 78

7 Communication 80

7.1 Direct cable connection 80

7.2 Remote connection 81

7.2.1 Internet connection 81

7.2.2 AirGate connection 81

7.2.3 Modem connection 82

7.3 Modbus connection 82

7.3.1 Modbus step by step 82

7.4 ECU engine support 83

7.5 Choosing the ECU to configure 83

7.6 ECU Analog inputs 85

7.7 Tier 4 engines support 85

8 Technical data 87

9 Appendix 89

9.1 Controller objects 90

9.1.1 List of controller objects types 90

9.1.2 Setpoints 91

9.1.3 Values 182

9.1.4 Logical binary inputs 184

9.1.5 Logical binary outputs 194

9.2 Extension modules 222

9.2.1 IL-NT RS232 (optional card) 223

9.2.2 IL-NT RS232/485 (optional card) 223

9.2.3 IL-NT S-USB (optional card) 223

9.2.4 IB-Lite (optional card) 223

9.2.5 IL-NT GPRS (optional card) 224

9.2.6 IL-NT AOUT8 (optional card) 224

9.2.7 IL-NT AIO (optional card) 224

ID-FLX Lite & Telecom Global Guide 3

9.2.8 IL-NT IO1 (optional card) 225

9.2.9 IL-NT BIO8 (optional card) 225

9.2.10 IGL-RA15 (Remote Annunciator) 225

ID-FLX Lite & Telecom Global Guide 4

ID-FLX Lite & Telecom Global Guide 5

1 Document information

1.1 Clarification of Notation 5

1.2 About this guide 5

1.3 Legal notice 5

1.4 Document history 7

1.5 Language support 7

1.1 Clarification of Notation

Note: This type of paragraph calls the reader’s attention to a notice or related theme.

IMPORTANT: This type of paragraph highlights a procedure, adjustment etc., which can cause a

damage or improper function of the equipment if not performed correctly and may not be clear at

first sight.

Example: This type of paragraph contains information that is used to illustrate how a specific function

works.

1.2 About this guide

This manual contains important instructions for ID-FLXLite controllers family that shall be followed during

installation and maintenance of the ID-Lite engine controllers.

This manual describes ID-FLXLite application examples for single engine applications.

This manual provides general information how to install and operate ID-Lite controller.

This manual is intended for operators of engines, for engine control panel builders or for everybody who is

concerned with installation, operation and maintenance of the engine applications.

1.3 Legal notice

This End User's Guide/Manual as part of the Documentation is an inseparable part of ComAp’s Product and

may be used exclusively according to the conditions defined in the “END USER or Distributor LICENSE

AGREEMENT CONDITIONS – COMAP CONTROL SYSTEMS SOFTWARE” (License Agreement) and/or in

the “ComAp a.s. Global terms and conditions for sale of Products and provision of Services” (Terms) and/or in

the “Standardní podmínky projektů komplexního řešení ke smlouvě o dílo, Standard Conditions for Supply of

Complete Solutions” (Conditions) as applicable.

ComAp’s License Agreement is governed by the Czech Civil Code 89/2012 Col., by the Authorship Act

121/2000 Col., by international treaties and by other relevant legal documents regulating protection of the

intellectual properties (TRIPS).

The End User and/or ComAp’s Distributor shall only be permitted to use this End User's Guide/Manual with

ComAp Control System Registered Products. The Documentation is not intended and applicable for any other

purpose.

Official version of the ComAp’s End User's Guide/Manual is the version published in English. ComAp reserves

the right to update this End User's Guide/Manual at any time. ComAp does not assume any responsibility for its

use outside of the scope of the Terms or the Conditions and the License Agreement.

ID-FLX Lite & Telecom Global Guide 6

Licensed End User is entitled to make only necessary number of copies of the End User's Guide/Manual. Any

translation of this End User's Guide/Manual without the prior written consent of ComAp is expressly prohibited!

Even if the prior written consent from ComAp is acquired, ComAp does not take any responsibility for the

content, trustworthiness and quality of any such translation. ComAp will deem a translation equal to this End

User's Guide/Manual only if it agrees to verify such translation. The terms and conditions of such verification

must be agreed in the written form and in advance.

For more details relating to the Ownership, Extent of Permitted Reproductions Term of Use of the

Documentation and to the Confidentiality rules please review and comply with the ComAp’s License

Agreement, Terms and Conditions available on www.comap-control.com.

Security Risk Disclaimer

Pay attention to the following recommendations and measures to increase the level of security of ComAp

products and services.

Please note that possible cyber-attacks cannot be fully avoided by the below mentioned recommendations and

set of measures already performed by ComAp, but by following them the cyber-attacks can be considerably

reduced and thereby to reduce the risk of damage. ComAp does not take any responsibility for the actions of

persons responsible for cyber-attacks, nor for any damage caused by the cyber-attack. However, ComAp is

prepared to provide technical support to resolve problems arising from such actions, including but not limited to

restoring settings prior to the cyber-attacks, backing up data, recommending other preventive measures against

any further attacks.

Warning: Some forms of technical support may be provided against payment. There is no legal or factual

entitlement for technical services provided in connection to resolving problems arising from cyber-attack or

other unauthorized accesses to ComAp's Products or Services.

General security recommendations and set of measures

1. AccessCode

• Change the AccessCode BEFORE the device is connected to a network.

• Use a secure AccessCode – ideally a random string of 8 characters containing lowercase, uppercase letters

and digits.

• For each device use a different AccessCode.

2. Password

• Change the password BEFORE the device enters a regular operation.

• Do not leave displays or PC tools unattended if an user, especially administrator, is logged in.

3. Controller Web interface

• The controller web interface at port TCP/80 is based on http, not https, and thus it is intended to be used only

in closed private network infrastructures.

• Avoid exposing the port TCP/80 to the public Internet.

4. MODBUS/TCP

• The MODBUS/TCP protocol (port TCP/502) is an instrumentation protocol designed to exchange data

between locally connected devices like sensors, I/O modules, controllers etc. From it’s nature it does not

contain any kind of security – neither encryption nor authentication. Thus it is intended to be used only in closed

private network infrastructures.

• Avoid exposing the port TCP/502 to the public Internet.

5. SNMP

ID-FLX Lite & Telecom Global Guide 7

• The SNMP protocol (port UDP/161) version 1,2 is not encrypted. Thus it is intended to be used only in closed

private network infrastructures.

• Avoid exposing the port UDP/161 to the public Internet.

1.4 Document history

Revision number SW version Date Author

12 2.5.0 3.2.2019 Lukáš Bečka

11 2.5.0 11.10.2019 Lukáš Bečka

10 2.3.0 4.10.2019 Lukáš Bečka

9 2.3.0 17.4.2019 Lukáš Bečka

8 2.3.0 28.3.2019 Lukáš Bečka

7 2.3.0 25.3.2019 Petr Weinfurt

6 2.3.0 13.3.2018 Petr Weinfurt

5 2.2.0 19.1.2016 Petr Weinfurt

4 2.1.0 9.11.2015 Zdeněk Rojka

3 1.9.0 17.12.2014 Jaroslav Juriga

2 1.8.0 13.5.2014 Jaroslav Juriga

1 1.7.0 5.5.2013 Jaroslav Juriga

Note: ComAp believes that all information provided herein is correct and reliable and reserves the right to

update at any time. ComAp does not assume any responsibility for its use unless otherwise expressly

undertaken.

1.5 Language support

ID-Lite controllers support different languages. In default setting of controller are accessible two languages

English, which isn’t possible remove and Chinese. In the controller is possible to substitute Chinese language

by next language via LiteEdit (see the table below). These languages are possible modify via Translator tool in

LiteEdit.

Following language code pages are supported:

Code page Language Windows code

0 West European languages Windows 1252

134 Chinese GB 2312

161 Greek Windows 1253

162 Turkish Windows 1254

177 Hebrew Windows 1255

204 Russian Windows 1251

238 East European languages Windows 1250

6back to Document history

ID-FLX Lite & Telecom Global Guide 8

2 System overview

2.1 Warnings 8

2.2 General description 8

2.3 Configurability and monitoring 9

6back to Table of contents

2.1 Warnings

ID-Lite controller can be remotely controlled. In case of the work on the engine check, that nobody can remotely

start the engine.

To be sure:

Disconnect remote control via RS232 line,

Disconnect input REM START/STOP or

Disconnect output STARTER

Note: Because of large variety of ID-Lite parameters setting, it is not possible to describe all combination.

Some of ID-Lite functions are subject of changes depend on SW version.

The data in this manual only describes the product and are not warranty of performance or characteristic.

Note: SW and HW must be compatible (e.g. ID-FLXLite firmware and ID-FLXLite hardware) otherwise the

function will be disabled. If wrong software is uploaded the message HARDWARE INCOMPATIBLE appears

on the controller screen.

In the case of using Boot load (jumper) programming – close Boot jumper, follow instruction in LiteEdit and

upload correct software.

2.2 General description

The key feature of ID-Lite is its easy-to-use operation and installation. Predefined configurations for typical

applications are available as well as user-defined configurations for special applications.

ID-Liteis a comprehensive controller for single engines with extended support of electronic engines and plug-in

modules.

ID-Lite controllers are equipped with a powerful graphic display showing icons, symbols and bar-graphs for

intuitive operation, which sets, together with high functionality, new standards in engine controls.

ID-Lite provides gas engine support without ventilation.

Controller supports WebSupervisor system. This system enables engine fleet and assets management as well

as pure monitoring. Visit www.comap-control.com and www.websupervisor.net for more details about

WebSupervisor.

The key features are:

ECU support - for singlespeed and allspeed engines e.g. Cummins, Volvo, JohnDeer etc.

Flexibility - with our extension modules e.g. IL-NT AIO, IL-NT BIO8 etc.

Communication - via communication modules e.g. IL-NT-GPRS, IB-Lite, IL-NT-S-USB and PCtools Web

ID-FLX Lite & Telecom Global Guide 9

Server, WebSupervisor, InteliMonitor etc.

Process logic – active control of engine, history log, configuration-no programming.

2.3 Configurability and monitoring

ID-Lite is using as configuration, monitoring and controlling tool LiteEdit software. For simple configuration,

monitoring and controlling can be used InteliMonitor.

ID-Lite controller also supports remote monitoring and control via internet, AirGate or cellular network

connection. For this remote control are used web tools WebSupervisor and Web Server.

2.3.1 Open connection from LiteEdit

PC tool LiteEdit is used for monitoring, programming and configuration of ID-FLXLite controllers.

1. Go to menu Connection and select the type of connection you desire.

2. Enter controller address and further information depending on the selected connection type.

ID-FLX Lite & Telecom Global Guide 10

3. You will see the Control window and you can continue with configuration of Setpoint, inputs, outputs etc.

Note: For detail description of LiteEdit and InteliMonitor PC tools see LiteEdit Reference Guide,InteliMonitor

Reference Guide and InteliDrive Communication Guide.

2.3.2 Open connection from web browser

It is possible to connect from a web browser to ID-Lite controllers, mounted with IB-Lite module (or IB-NT with

specific conditions) and connected to internet.

1. Open web browser

2. Enter IP address from controller IBLite IP Addr (page 105)

3. Access verification page appears

Other manuals for InteliDrive Lite

This manual suits for next models

Table of contents

Other ComAp Controllers manuals

ComAp

ComAp InteliSys NTC BaseBox Use and care manual

ComAp

ComAp InteliLite NT MRS19 User manual

ComAp

ComAp InteliLite 4 MRS16 Manual

ComAp

ComAp InteliDrive Lite User manual

ComAp

ComAp IG-NT GC User manual

ComAp

ComAp InteliDrive DCU Marine User manual

ComAp

ComAp InteliNano NT MRS User manual

ComAp

ComAp InteliLite NT AMF Series User manual

ComAp

ComAp InteliNano NT MRS User manual

ComAp

ComAp InteliDrive Mobile User manual

ComAp

ComAp InteliDrive DCU Marine User manual

ComAp

ComAp InteliCompact NT Manual

ComAp

ComAp InteliATS NT PWR User manual

ComAp

ComAp IM-NT-BTB Manual

ComAp

ComAp InteliCompact NT User manual

ComAp

ComAp intelilite nt amf20 User manual

ComAp

ComAp IG-NT User manual

ComAp

ComAp InteliLite 9 User manual

ComAp

ComAp InteliSys SPI Use and maintenance manual

ComAp

ComAp InteliGen 200 Manual

ComAp

ComAp IG-NT User manual

ComAp

ComAp IGS-NT Series User manual

ComAp

ComAp InteliSys NT Programming manual

ComAp

ComAp IG-NT User manual

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

ABB

ABB ACS580-01 drives Hardware manual

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual
