Casio PV-S250 User manual

172

Chapter

16 Technical Reference

This section contains technical information about the PV Unit.

Date Formats

The following describes the date formats that can be set for the system (page 168).

Time Formats

The following describes the time formats that can be set for the system (page 168).

Format

M/D/Y

D/M/Y

Y/M/D

Description

Month/Day/Year. Example: Jan/31/2001

Day/Month/Year. Example: 31/Jan/2001

Year/Month/Day. Example: 2001/1/31

Format

12-hour

24-hour

Description

Represents time in two blocks, from midnight to 11:59am,

and from noon to 11:59pm.

Represents time as a single block, from 0:00 to 23:59. This

format is often referred to as “military time.”

173

Chapter 16 Technical Reference

Tool Bars

The PV Unit uses standard tool bars for data input and display. The following

shows typical examples of these toolbars, and describes the items that can appear

in each.

Data Input Tool Bar

• The above table shows all the buttons that can possibly appear in a data

input tool bar. Depending on mode and other factors, some of the tools

shown above may not be included in a data input tool bar.

Mode icon

Button

Mode icon

Description

Indicates the mode you are currently in.

Clears all characters in the entry (field) where the cursor

is located. In the Contacts Mode, pressing this button clears

the data from all the input fields for the data item (record)

you are inputting.

Pastes the current date and time as being kept by the main

clock at the current cursor location.

Displays a calculator.

Advances to the next screen.

Returns to the previous screen.

Saves input data and closes the input screen.

In the Quick-Memo Mode, tapping this button changes to

the list view.

Displays the pop up tool screen.

174

Data Display Tool Bar

• The above table shows all the buttons that can possibly appear in a data

display tool bar. Depending on mode and other factors, some of the

tools shown above may not be included in a data display tool bar.

Mode icon

Description

Indicates the mode you are currently in.

Displays a menu of other views that can be used to display

data.

In the Scheduler and Expense Manager modes, jumps to

today’s date as kept by the PV Unit’s built-in clock.

Advances to the next item.

Returns to the previous item.

Displays the new data input screen.

Returns to the list screen from a Contacts, Memo,

Expense Manager, and Quick-Memo mode data screen.

Changes to the data editing screen for the current data

item.

Displays the pop up tool screen.

Button

Mode icon

175

Chapter 16 Technical Reference

Keyboard Formats

The PV Unit provides you with a selection of keyboard formats.

QWERTY

This format is automatically selected when English,

Spanish, or Italian is set as the system language.

AZERTY

This format is automatically selected when French is

set as the system language.

QWERTZ

This format is automatically selected when German

is set as the system language.

Scheduler Mode Alarms

• When you set an alarm time for a Schedule, To Do, or Reminder item,

an alarm sounds for about 20 seconds when the alarm time is reached on

the date that is also specified for the data item.

• Alarms may fail to sound when battery power is low.

• Alarms are deleted automatically after the Scheduler alarm time is passed.

You cannot set an alarm time for a date and time that are already passed.

• Up to 100 Scheduler alarm times can be set at one time.

176

Input Limits

The following table shows the maximum number of characters that can be input

into various fields.

Resetting the PV Unit

Warning!

The following procedure erases all data stored in the memory of the PV Unit.

Perform this operation only when you want to delete all data and initialize the

settings of the PV Unit.

Remember - you should always keep copies of important data by writing it down,

or by transferring it to a personal computer.

Mode

Schedule

To Do

Reminder

Contacts

Memo

Expense

Manager

Password

Clipboard

Maximum Number of Characters

2,046

2,036

2,048

2,008

2,048

Entry (Field)

Description

Category

Item

Description

Amount

Payment Type

Expense Type

Description

–

177

Chapter 16 Technical Reference

1. Open the cover and touch the screen with the stylus to turn on power.

2. Use the stylus to press the RESET button on the back of the PV Unit.

RESET

➜

• If the above does not appear on the display when you press the RESET

button, slide the battery switch to the REPLACE BATTERIES position

and remove the battery compartment cover. Use the stylus to press the P

button and then replace the battery compartment cover. Slide the battery

switch back to the NORMAL OPERATION position and then press the

RESET button.

3. Tap the center of each of the four cross marks as they appear on the

screen.

• The contrast adjustment screen appears next.

4. Tap Hor Jto adjust the contrast of the display, and then tap OK.

5. In response to the message that appears, tap Yes to reset the PV Unit and

clear all memory contents, or No to abort the reset procedure without

doing anything.

6. If you tapped Yes in the above step, a second confirmation message

appears. Tap Yes to reset the PV Unit and clear all memory contents, or

No to abort the reset procedure without doing anything.

• Tapping Yes in the above step starts the actual reset procedure.

RESET

button

178

7. After the reset procedure is complete, tap the button next to the language

you want to select as the system language.

8. Tap Set to change to the pop up tool screen.

9. Check the time setting and correct it if necessary (page 166).

• Following are the initial settings of the PV Unit after you perform the

RESET operation.

Main clock: Clock 1

London

Jan/1/2001

12:00 am

12-hour format

Clock 2: New York

Daily Alarm: 12:00 pm

Sound: Daily Alarm off, all others on

Character input: CAPS off

Euro Conversion Rate Presets

Country

Germany

France

Italy

Spain

Netherlands

Belgium

Portugal

Austria

Finland

Ireland

Luxembourg

Rate (for 1 euro)

1.95583

6.55957

1936.27

166.386

2.20371

40.3399

200.482

13.7603

5.94573

0.787564

40.3399

Currency Code

DEM

FRF

ITL

ESP

NLG

BEF

PTE

ATS

FIM

IEP

LUF

Decimal Places

179

Chapter 16 Technical Reference

Storage Capacity

The memory capacity of the PV-S450 is 4-Mbyte (2-Mbyte for the PV-S250).

The following shows the number of items that can be stored.

Scheduler

Approximately 32,000 items (24,400 for the PV-S250) with 20-character

description.

Approximately 27,320 items (12,200 for the PV-S250) with 60-character

description.

Contacts

Approximately 32,000 items (24,400 for the PV-S250), under the following

conditions.

8-character name

10-character home phone number

10-character home fax number

20-character home address

Approximately 18,210 items (8,130 for the PV-S250), under the following

conditions.

8-character name

10-character business phone number

10-character business fax number

40-character business address

20-character company name

20-character department

20-character position

Memo

Approximately 3,210 items (1,430 for the PV-S250), 1,024-character memos.

Expense Manager

Approximately 27,320 items (12,200 for the PV-S250), under the following

conditions.

10-character description

Expense type and payment type set

Quick-Memo

Approximately 1,300 items (580 for the PV-S250).

180

(space)

”

’

(

)

–

;

[

]

—

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

–

{

}

‹

ﬁ

›

ﬂ

•

Auto Sort Sequence

The following table shows the sequence used for alphabetical data sorts.

181

Chapter 16 Technical Reference

Abidjan

Abu Dhabi

Acapulco

Accra

Addis Ababa

Adelaide

Aden

Al Manamah

Algiers

Alice Springs

Amman

Amsterdam

Anchorage

Andorra

Ankara

Antananarivo

Asuncion

Athens

Atlanta

Auckland

Azores

Baghdad

Baltimore

Bangkok

Barcelona

Basel

Beirut

Belgrade

Bergen

Berlin

Birmingham

Bismarck

Bogota

Boise

Bonn

Boston

Brasilia

Brazzaville

Brisbane

Broken Hill

Brussels

Bucharest

Budapest

Buenos Aires

Cairo

Calcutta

Canberra

Cape Town

Caracas

Casablanca

Cayenne

Chatham Island

Cheyenne

Chicago

Cincinnati

Cleveland

Colombo

Conakry

Copenhagen

Dakar

Dallas

Damascus

Dar es Salaam

Darwin

Delhi

Denver

Detroit

Dhaka

Dubai

Dublin

Dusseldorf

Edmonton

Fernando de

Noronha

Fort Worth

–0:00

+ 4:00

– 6:00

–0:00

+ 3:00

+ 9:30

+ 3:00

+ 1:00

+ 9:30

+ 2:00

+ 1:00

– 9:00

+ 1:00

+ 2:00

+ 3:00

– 4:00

+ 2:00

– 5:00

+12:00

– 1:00

+ 3:00

– 5:00

+ 7:00

+ 1:00

+ 2:00

+ 1:00

– 6:00

– 5:00

– 7:00

+ 1:00

– 5:00

– 3:00

+ 1:00

+10:00

+ 9:30

+ 1:00

+ 2:00

+ 1:00

– 3:00

+ 2:00

+ 5:30

+10:00

+ 2:00

– 4:00

–0:00

– 3:00

+12:45

– 7:00

– 6:00

– 5:00

+ 6:00

–0:00

+ 1:00

–0:00

– 6:00

+ 2:00

+ 3:00

+ 9:30

+ 5:30

– 7:00

– 5:00

+ 6:00

+ 4:00

–0:00

+ 1:00

– 7:00

– 2:00

– 6:00

Frankfurt

Freetown

G.M.T.

Geneva

Georgetown

Guam

Guatemala City

Hamburg

Hannover

Hanoi

Havana

Helena

Helsinki

Hermosillo

Hong Kong

Honolulu

Houston

Indianapolis

Istanbul

Jacksonville

Jakarta

Jeddah

Jerusalem

Johannesburg

Kabul

Kampala

Kansas City

Karachi

Kathmandu

Khabarovsk

Khartoum

Kingston

Kinshasa

Kuala Lumpur

Kuwait

La Paz

+ 1:00

–0:00

+ 1:00

– 4:00

+10:00

– 6:00

+ 1:00

+ 7:00

– 5:00

– 7:00

+ 2:00

– 7:00

+ 8:00

–10:00

– 6:00

– 5:00

+ 2:00

– 5:00

+ 7:00

+ 3:00

+ 2:00

+ 4:30

+ 3:00

– 6:00

+ 5:00

+ 5:45

+10:00

+ 2:00

– 5:00

+ 1:00

+ 8:00

+ 3:00

– 4:00

City Name

Time

Difference

City Name

Time

Difference

City Name

Time

Difference

City Name List

Other manuals for PV-S250

This manual suits for next models

Table of contents

Other Casio PDA manuals

Casio

Casio PV-250X User manual

Casio

Casio PV-250X User manual

Casio

Casio PV-100 User manual

Casio

Casio PV-750 Plus Instruction and safety manual

Casio

Casio SF-R10 User manual

Casio

Casio Palm-size PC User manual

Casio

Casio PV-100 User manual

Casio

Casio Cassiopeia EM-500 User manual

Casio

Casio PV-250X User manual

Casio

Casio PV-S250 User manual

Casio

Casio PALM User manual

Casio

Casio IT-10 Series User manual

Casio

Casio PV-750 Plus User manual

Casio

Casio PV-750 Plus Use and care manual

Casio

Casio PV-100 User manual

Casio

Casio DC-7800RS Troubleshooting guide

Casio

Casio CASSIOPEIA PA-2400W Mounting instructions

Casio

Casio PV-250X User manual

Casio

Casio CASSIOPEIA IT-2000D User manual

Casio

Casio Cassiopeia Pocket PC User manual

Casio

Casio PV-S250 User manual

Casio

Casio DX-500BR Troubleshooting guide

Casio

Casio SF-4300R Troubleshooting guide

Casio

Casio PV-S250 User manual

Popular PDA manuals by other brands

SPOT

SPOT SPOT user guide

Palm

Palm handheld Getting started guide

Winmate

Winmate E500QK user guide

Getac

Getac PS236 Specifications

Sharp

Sharp CE-1600P Operation manual

HTC

HTC PHAR100 user manual

Mindeo

Mindeo M40 Reference manual

Acer

Acer n30 manual

ASCOM

ASCOM 9D24 EX brochure

Unitech

Unitech PA520BTNF user manual

HandHeld

HandHeld Nautiz X3 user manual

Sharp

Sharp TM-20 Software guide

Atid

Atid AT870 quick guide

AML

AML M7225 user guide

Audiovox

Audiovox Maestro Quick start card

Unitech

Unitech PT630 Programming reference guide

PSC

PSC Falcon 4220 installation guide

Datalogic

Datalogic ELF quick start guide
