Case Study ALPINE DAYBED User manual
ALPINE DAYBED
ASSEMBLY INSTRUCTIONS
x 12
1 ½ Hex Screws
x 1
3⁄8 Allen Wrench
x 2 Spars
x 1 platform
x 1 canvas spring cover
x 1 backrest
Lay both of the spars on their backs
with the feet facing away from you.
Align the holes on the backrest with the holes on the spars.
Insert screws into the holes and loosely tighten.
Once all the screws are in the holes
tighten fully in a diagonal pattern.
Flip the spars and backrest upright onto the feet.
1 5 8 4
3 7 6 2
Align the holes on the platform with the holes on the spars.
Insert the screws into the holes in the order shown above and loosely tighten.
Once all the screws are in the holes
tighten fully in the order shown above.
Done!
To attach the canvas spring cover, slide
the elastic over the corners of the metal
frame containing the springs.
