OWNER’S GUIDE

OPERATION & INSTALLATION

CARRIER RECREATIONAL VEHICLE

AIR CONDITIONER

HEAT PUMP UNIT FOR DUCTED SYSTEM

A FEW WORDS ABOUT YOUR NEW AIR CONDITIONING UNIT 2

ELECTRICAL DATA 2

OPERATING INSTRUCTIONS 4

CEILING UNIT DISPLAY 4

REMOTE CONTROL DESCRIPTIONS 5

REMOTE CONTROL PREPARATION 7

UNIT OPERATION 8

ENERGY SAVING TIPS 9

INSTALLATION INSTRUCTIONS 9

CEILING ASSEMBLY FRAME INSTALLATION REQUIREMENTS 9

SUPPLY DUCTING AND REGISTERS 10

PREPARATION AND POSITIONING THE ROOF TOP UNIT 12

CEILING ASSEMBLY FRAME PREPARATION AND MOUNTING 13

COMPLETING THE INSTALLATION 17

TROUBLESHOOTING 18

NORMAL MAINTENANCE PROCEDURES 19

PART DIAGRAM 20

CONTENTS

○○ ○ ○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

“

Important!!!

You must register your product either:

Online at

www.airv.carrier.com

Mail in the completed paper form supplied with your product.

OWNER’S GUIDE -

A FEW WORDS ABOUT YOUR NEW

AIR CONDITIONING UNIT

Thank you for choosing the Air V, Carrier Recreational Vehicle Air Conditioner, for your comfort needs.

You can feel confident in your selection because the same pride in craftsmanship and engineering knowledge

that goes into Carrier equipment to cool the Astrodome in Texas, the famous Sistine Chapel in Rome,

the Washington DC Halls of Congress and thousands of other installations worldwide has gone

into the construction of your unit.

In addition to cooling the room, your Carrier heat pump unit will also heat, filter and dehumidify the room’s air.

In heating mode, the heat pump will shut down at conditions which would cause outdoor coil freeze up, generally

near freezing temperatures.

The Air V air conditioners quietly give you maximum cooling and heating comfort.

Now you can “ Feel Carrier’s Comfort” !

This manual is designed to help you with all the information you need for installing, operating and maintaining your

new unit. In addition, this contains many comforts and technological features your unit offers. Take a few minutes to

discover how to get the most in cooling or heating comfort and economic operation from your new Air V.

Please keep this manual handy for future reference, and be sure to send in your warranty card.

You can also contact us by the internet web site,

www.airv.carrier .com .

ELECTRICAL DATA

Allwiringmustcomply withlocal andnational electricalcodes. Allwiring mustbe installedby qualifiedelectricians.

If you have any questions about the following instructions, contact a qualified electrician.

Check the available power supply and resolve any wiring problems BEFORE installing and operating this unit.

This roof mount heat pump is designed to operate from a 115V AC, 60Hz, 1 Phase power supply.

The unit nameplate is located on the left side of the condenser orifice that is on the rear of the basepan. The

wiring diagrams are located on the cover of the control box. The ceiling assembly unit wire diagrams are

located on the control box cover of ceiling panel frame.

Note the unit’s model, serial number, and the ceiling assembly serial number.

Record this information on the front cover of this manual.

Bottom View after Installation with Grille Removed

(Information of Serial Number Location)

CEILING ASSEMBLY FRAME

SERIAL NUMBER OF

CEILING UNIT

(SIDE OF CONTROL BOX)

SERIAL NUMBER

OF UPPER UNIT

BOTTOM OF

UPPER UNIT

CAUTIONS COMPRESSOR DELAYFUNCTION

WARNING DISCONNECT POWER SUPPLY

BEFORE REMOVE OF CONTROL PANEL.

OWNER’S GUIDE - 3

Schematic Diagram of Ceiling Unit

And

•

Standard Unit (99-00468-06, -07)

•

Low Profile Unit (99-00468-13)

SCHEMATIC DIAGRAM of Upper Unit

OWNER’S GUIDE -

햲TIMER(Orange): When the unit is in reservation on/off timer mode, an orange light will be displayed.

햳UNIT ON(Green): When the unit is switched on by the remote control or the emergency button,

a green light will be displayed.

햴AUXILIARY HEAT (Red) : if the outdoor ambient temperature or the outdoor coil temperature is down at conditions

which would cause outdoor coil freeze up in the heat pump mode, the control will automatically select the

FURNACE operation and the ‘AUX.HEA’LED (a red light) will be displayed. The unit will return to the Heat pump

operation and the ‘AUX.HEAT’ LED will turn off when both the outdoor ambient temperature and the outdoor coil

temperature are above 43°F. If your vehicle dose not contain a furnace, and the control automatically selects

the FURNACE operation in the Heat pum mode, the system will shut down until the control returns to the Heat

Pump operation.

햵HEAT EMERGENCY button : Can be used when the remote control is lost or inoperative. When the remote control

is lost, damaged or the battery is discharged, the HEAT EMERGENCY button can be used to run the unit.

• Press the HEAT EMERGENCY button when in the off mode condition.

- The unit operates automatically according to the room temperature in the heating operation.

• The setting conditions of heat emergency operation are as follows:

- Operation mode: HEAT - Preset temperature: 73°F

- Fan Speed: AUTO - Timer mode: Disable

햶COOL EMERGENCY button: also can be used when the remote control is lost or inoperative. When the remote

control is lost, damaged or the battery is discharged, the COOL EMERGENCY button can be used to run the unit.

• Press the COOL EMERGENCY button when in the off mode condition.

- The unit operates automatically according to the room temperature in the cooling operation.

• The setting conditions of cool emergency operation are as follows:

- Operation mode: COOL - Preset temperature: 75°F

- Fan Speed: AUTO - Timer mode: Disable

IMPORTANT

Defrost Operation : When the outdoor coil is frosted in the heating mode, the indoor blower and outdoor fan will

be turned off while the compressor will turn on to remove the frost on the outdoor coil. The defrost mode stops in

10minutes or when the defrosting process is completed. When the power is off, the defrost operation is automati-

cally conducted depends on the frost accumulation on the outdoor coil.

OPERATING INSTRUCTIONS

CEILING UNIT DISPLAY

Room Air Thermistor

OWNER’S GUIDE - 5

Names and Functions of the Buttons

1. On/Off Button

2. Mode Selector Button

3. Fan Speed Selector Button

4. On Timer Button

5. Temperature Selector Buttons

6. Off Timer Button

1 2

MODE SELECTOR BUTTON - Press this button to

select the desired mode. In COOL mode, the unit

will run at the normal cooling mode. In DRY mode,

the microcomputer of the unit controls the fan

motor and makes the unit automatically cycle on

and off according to the room temperature. This

enables the moisture to be removed more

efficiently. In FAN mode, only the fan will operate

at the selected fan speed and circulate the room

air. In HEAT mode, the unit will run at the normal

heat pump mode. And in FURN. mode, the unit

will run at the normal furnace mode (This

is a user optional function.).

ON/OFF BUTTON - If you press this button, the unit

will begin operation. (You can hear receiving

beeps twice.) Press the button again, and opera-

tion stops. (You can hear a receiving beep.) If you

press this button immediately after turning off the

unit, the compressor will not operate for 3 minutes

to prevent overloading.

REMOTE CONTROL DESCRIPTIONS

FAN

SPEED

ON/OFF

MODE

FURN.

COOL

DRY

FAN

HEAT

AUTO

LOW

HIGH

TEMP.

TIMER

OFF

TIMER

OFFON

TEST MODE

: Installer can operate the unit anytime regardless of temperature by pushing Emergency Button

(COOL or HEAT) more than 5 seconds continuously after installing the unit. (This function is only used by

servicemen to test the unit operation.)

Refrigerant Compressor Time Delay

: The air conditioning system is equipped with a time delay on the

compressor during the start of the cooling cycle. This time delay may be up to 3 minutes at the time of start up.

햷REMOTE CONTROL SIGNAL RECEIVER

If you want to stop the emergency operation, push the EMERGENCY button again or operate

the remote control.

NOTE

OWNER’S GUIDE -

Indicates the selected operating mode.

Lights up when the signal from the remote control is transmitted. The receiving beep is heard from the unit.

Indicated the selected temperature.

Indicates the selected or remaining time of the ON TIMER and OFF TIMER modes.

Indicates the selected fan speed.

Indicates the selected timer mode, namely, ON TIMER or OFF TIMER mode.

OFF TIMER BUTTON - When the unit is turned on,

press the OFF TIMER button to select the desired

time, in hours, for the unit to turn off.

TEMPERATURE SELECTOR BUTTONS - If you set

the desired room temperature, then the unit will

maintain the room temperature at the set

temperature.In COOLmode, ifthe roomtempera-

ture is higher than setting, the compressor will be

automatically turned on to provide a cooling

effect. If the room temperature is lower than the

setting, the compressor will be automatically

turned off to stop cooling operation. However, the

fan will continue to circulate air even if the com-

pressor is turned off. In HEAT mode, if the room tem-

perature is lower than setting, the compressor will

be automatically turned on to provide a heat-

ing effect. If the room temperature is higher than

the setting, the compressor will be automatically

turned off the stop heating operation. However,

the fan will continue to circulate air even if the

compressor is turned off.

AUTO

FURN.

ON OFF

TIMER

COOL

DRY

FAN

HEAT

LOW

HIGH

3 4

ON TIMER BUTTON - When the unit is turned off,

press the ON TIMER button to select the desired

time, in hours, for the unit to turn on.

FAN SPEED SELECTOR BUTTON - Press this but-

ton to select the desired fan speed of HIGH, LOW

or AUTO in turn, and the fan will operate at the

selected fan speed. If you select “ AUTO”, the fan

speed will be controlled by the microcomputer of

the unit.

Remote Control Display

OWNER’S GUIDE - 7

Replacing Batteries

•Do not fit used batteries or batteries of different type. Such use may cause the unit to malfunction.

•Changing batteries should be done after turning off the unit.

•The average battery life during normal use is one year approximately.

•When the air conditioner does not operate normally after replacing the batteries, remove the batteries,

refit them and repress the RST button after 5 seconds.

NOTE

Signal Receiving

Use the remote control where its signal can reach the receiver of the air conditioner.

- You can hear the beeping sound from the unit in the remote control operation, which indicates that

the signal is received.

Remove the cover of the battery compartment at the back of the remote control by sliding it out.

Remove the old batteries and insert the new batteries. The remote control uses two alkaline batteries.

(1.5V, LR03x2)

Press the RST button with a sharp object to reset the remote control before closing the cover of the battery

compartment.

•The air conditioner will not operate if curtains, doors or other materials block the signals from the remote control to

the unit.

•If the infrared signal receiver on the unit is exposed to direct sunlight, the air conditioner may not work properly.

Draw the curtains to avoid direct sunlight.

•Avoid spilling liquid onto the remote control or dropping it. This can cause deformation, dislocation and malfunction.

•A mounting bracket for the remote control is supplied with the unit. Install the mounting bracket on the wall by

using two sharp point wood screws and/or double sided tape attached on the back of the bracket. This prevents

the remote control from being lost.

CAUTION

REMOTE CONTROL PREPARATION

OWNER’S GUIDE -

UNIT OPERATION

GENERAL OPERATION

ON/OFF button

Press button and the COOL operation is indicated.

- Receiving beeps are heard.

- The green UNIT ON lamp of the indoor unit display illuminates.

MODE button

Press this button to select the desired operation.

COOL DRY FAN HEAT FURN.

FAN SPEED button

Press this button to select the desired fan speed.

HIGH LOW AUTO

ON TIMER button

To set the desired ON time from setting time, continue to depress and release this button.

1hr 2hr 3hr 4hr 5hr 6hr 7hr 8hr 9hr 10hr 11hr 12hr cancel

This ON TIMER can be set only in OFF mode.

TEMPERATURE ( ) buttons

Press this button to set the desired temperature. (63°F~90°F)

- To decrease the desired room temperature, keep to depress or continue to depress and release button.

- To increase the desired room temperature, keep to depress or continue to depress and release button.

OFF TIMER button

To set the desired OFF time from setting time, continue to depress and release this button.

1hr 2hr 3hr 4hr 5hr 6hr 7hr 8hr 9hr 10hr 11hr 12hr cancel

This OFF TIMER can be set only in ON mode.

PROCEDURE

OWNER’S GUIDE - 9

Moving parts can cause personal injury. Be careful when test-running the unit.

Do not operate the unit with exterior cover removed.

WARNING

BEFORE INSTALLATION

Select the temperature setting that suits your comfort needs and leave it at that chosen setting.

Keep the unit’s air filters clean. (See the Normal Maintenance Procedures section of this manual on page 19.)

During extreme outdoor temperatures, the heat gain of the vehicle may be reduced by:

- parking the vehicle in a shaded area

- keeping the windows and doors closed

- avoiding the use of heat producing appliances

- using window shades (binds and/or curtains)

For a more permanent solution to reduce the high heat gain, window awnings and/or window glass tinting

should be considered.

When using the heating system, the heat loss of the vehicle may be reduced by:

- parking the vehicle in a sunny area

- keeping the windows and doors closed

- avoiding the use of heat absorbing appliances

Test run the unit with proper power supply outlet. Refer to the Operating Instructions section in this Owner’s Guide.

Make sure all the controls operate correctly then disconnect the power supply of the unit.

Telescoping Divider # Range

71DC6A3006 (supplied) 3.25”~ 4.25”

71DC6A3005 2.0”~ 2.75”

71DC6A3007 5.0”~ 6.0”

1 2

Provided with the ceiling assembly frame is a tele-

scoping divider assembly which is used to sepa-

rate the warm return air from the cold supply air.

The telescoping divider size is determined by mea-

suring the ceiling cavity depth. (the measurement

from the ceiling to the roof)

The ceiling assembly frame must be installed over

the roof opening. The ceiling assembly frame bolts

to the bottom of the roof top unit. Compression of

the framed ceiling cavity between the roof top

unit and the ceiling assembly frame is what holds

both components in place.

CEILING ASSEMBLY FRAME INSTALLATION REQUIREMENTS

ENERGY SAVING TIPS

INSTALLATION INSTRUCTIONS

Other manuals for Air V

Table of contents

Other Carrier Air Conditioner manuals

Carrier

Carrier 73X Operating instructions

Carrier

Carrier WeatherExpert 48JC04 User manual

Carrier

Carrier 42XPF User manual

Carrier

Carrier 53KLE-H SERIES User manual

Carrier

Carrier 48FC Series User manual

Carrier

Carrier 73ACA051T User manual

Carrier

Carrier 48VL Instruction Manual

Carrier

Carrier WeatherMaker 48TC 06 User manual

Carrier

Carrier 38GL...G User manual

Carrier

Carrier VisionAire User manual

Carrier

Carrier AIR COOLED CONDENSING UNIT 38EH Instructions and recipes

Carrier

Carrier Xpower 40KQM User manual

Carrier

Carrier 38BRC User manual

Carrier

Carrier 48VG-A User manual

Carrier

Carrier 42QTD024713GE User manual

Carrier

Carrier PREFERRED 577E A Series User manual

Carrier

Carrier 42HQE009(012) User manual

Carrier

Carrier WeatherMaker 50TC07 Series User manual

Carrier

Carrier 42NQV025H User manual

Carrier

Carrier 50A020 User manual

Carrier

Carrier 50TJ016 Dimensions and installation guide

Carrier

Carrier 42C Series Operation manual

Carrier

Carrier 48SD User manual

Carrier

Carrier 52S series Assembly instructions

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual
