Canon PIXMA MX860 series User manual

Setting Up Your MX860 In

Default Mode (Tel Priority Mode)

WithoutAn Answering Machine

DSL/Cable Modem Connection

Connecting The Phone Lines

NextPrevious

Fax to Phone Line Connection

NextPrevious 3

Before

Hand Set

(Phone)

(Existing Phone Cord)

Wall jack

DSL/Cable

Modem P

(Existing Phone Cord)

After

(Phone Cord included with

Canon printer)

(Existing Phone Cord)

Wall jack DSL/Cable

Modem

Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 4

(Existing Phone Cord)

Hand Set

(Phone)

(Existing Phone Cord)

Wall Jack

DSL/Cable

Modem P

•Plug the provided phone cord into the DSL/Cable Modem

(Phone Cord included

with Canon printer)

Fax to Phone Line Connection

NextPrevious 5

(Existing Phone Cord)

Wall jack

DSL/Cable

Modem P

(Phone Cord included

with Canon printer)

Hand Set

(Phone)

•Plug the provided phone cord into the “L” jack in the rear of the

multifunction

Fax to Phone Line Connection

NextPrevious 6

(Existing Phone Cord)

Wall jack

DSL/Cable

Modem P

(Phone Cord included

with Canon printer)

Hand Set

(Phone)

•Remove the white plug (D) from the upper jack

Fax to Phone Line Connection

NextPrevious 7

(Existing Phone Cord)

Wall jack

DSL/Cable

Modem P

(Phone Cord included

with Canon printer)

Hand Set

(Phone)

•Plug the second phone cord into the “telephone” jack located on the

rear of the multifunction

Fax to Phone Line Connection

NextPrevious 8

(Existing Phone Cord)

Wall jack

DSL/Cable

Modem P

(Phone Cord included

with Canon printer)

Hand Set

(Phone)

•Plug the existing phone cord into the phone

Setting Up The Receive Mode

NextPrevious

Step 1

Turn on the MX860 by pressing the

ON button.

Step 2

Press the FAX button.

NextPrevious 10
